PREPARATION

FAX-7

< PREPARATION >

[2WD]

C

E

F

G

H

I

J

K

L

M

A

B

FAX

N

O

P

PREPARATION

PREPARATION

Special Service Tool

INFOID:0000000009717890

The actual shapes of Kent-More tools may differ from those of special service tools illustrated here.

Tool number
(Kent-More No.)
Tool name

Description

KV40107300
(

—

)

Boot band crimping tool

Installing boot band

KV40107500
(

—

)

Drive shaft attachment

Removing drive shaft

KV38107900
(

—

)

Protector
a: 32 mm (1.26 in) dia.

Installing drive shaft

ST35271000
(

—

)

Drift
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.

Installing support bearing

ST17130000
(

—

)

Drift
a: 32 mm (1.26 in) dia.
b: 60 mm (2.36 in) dia.

Removing support bearing

ZZA1229D

ZZA1230D

PDIA1183J

ZZA0701D

ZZA0836D

FAX-8

< PREPARATION >

[2WD]

PREPARATION

Commercial Service Tool

INFOID:0000000009717891

Tool name

Description

Power tool

Loosening bolts and nuts

PBIC0190E

FRONT WHEEL HUB AND KNUCKLE

FAX-9

< PERIODIC MAINTENANCE >

[2WD]

C

E

F

G

H

I

J

K

L

M

A

B

FAX

N

O

P

PERIODIC MAINTENANCE

FRONT WHEEL HUB AND KNUCKLE

Inspection

INFOID:0000000009717892

MOUNTING INSPECTION

Make sure that the mounting conditions (looseness, backlash) of each component and component conditions
(wear, damage) are normal.

WHEEL BEARING INSPECTION

• Move wheel hub and bearing assembly in the axial direction by hand. Make sure there is no looseness of

wheel bearing.

• Rotate wheel hub and bearing assembly and make sure there is no unusual noise or other irregular condi-

tions. If there is any of irregular conditions, replace wheel hub and bearing assembly.

Standard

Axial end play

: Refer to

FAX-29, "Wheel Bearing"

.

FAX-10

< PERIODIC MAINTENANCE >

[2WD]

FRONT DRIVE SHAFT

FRONT DRIVE SHAFT

Inspection

INFOID:0000000009717893

• Check drive shaft mounting point and joint for looseness and other damage.
• Check boot for cracks and other damage.

CAUTION:

Replace entire drive shaft assembly when noise or vibration occurs from drive shaft.
