EM-154
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*: Total indicator reading
Main Bearing
INFOID:0000000009718021
MAIN BEARING
Main journal diameter. “Dm” grade
Standard
Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W
Grade No. X
Grade No. Y
Grade No. 4
Grade No. 7
59.975 - 59.974 (2.3612 - 2.3612)
59.974 - 59.973 (2.3612 - 2.3611)
59.973 - 59.972 (2.3611 - 2.3611)
59.972 - 59.971 (2.3611 - 2.3611)
59.971 - 59.970 (2.3611 - 2.3610)
59.970 - 59.969 (2.3610 - 2.3610)
59.969 - 59.968 (2.3610 - 2.3609)
59.968 - 59.967 (2.3609 - 2.3609)
59.967 - 59.966 (2.3609 - 2.3609)
59.966 - 59.965 (2.3609 - 2.3608)
59.965 - 59.964 (2.3608 - 2.3608)
59.964 - 59.963 (2.3608 - 2.3607)
59.963 - 59.962 (2.3607 - 2.3607)
59.962 - 59.961 (2.3607 - 2.3607)
59.961 - 59.960 (2.3607 - 2.3606)
59.960 - 59.959 (2.3606 - 2.3606)
59.959 - 59.958 (2.3606 - 2.3605)
59.958 - 59.957 (2.3605 - 2.3605)
59.957 - 59.956 (2.3605 - 2.3605)
59.956 - 59.955 (2.3605 - 2.3604)
59.955 - 59.954 (2.3604 - 2.3604)
59.954 - 59.953 (2.3604 - 2.3603)
59.953 - 59.952 (2.3603 - 2.3603)
59.952 - 59.951 (2.3603 - 2.3603)
Pin journal diameter. “Dp” grade
Standard
Grade No. 0
51.968 - 51.974 (2.0460 - 2.0462)
Grade No. 1
51.962 - 51.968 (2.0457 - 2.0460)
Grade No. 2
51.956 - 51.962 (2.0445 - 2.0457)
Center distance “r”
40.66 - 40.74 (1.6008 - 1.6039)
Taper (Difference between “A” and “B”)
Limit
0.002 (0.0001)
Out-of-round (Difference between “X” and “Y”)
0.002 (0.0001)
Crankshaft runout [TIR*]
Standard
Less than 0.05 (0.0020)
Limit
0.10 (0.0039)
Crankshaft end play
Standard
0.10 - 0.25 (0.0039 - 0.0098)
Limit
0.30 (0.0118)
SEM645
SBIA0535E
