BCS
INSPECTION AND ADJUSTMENT
BCS-5
< BASIC INSPECTION >
C
D
E
F
G
H
I
J
K
L
B
A
O
P
N
4.
OPERATION CHECK
Confirm that each function controlled by BCM operates normally.
>> WORK END
CONFIGURATION (BCM) : Configuration list
INFOID:0000000009722429
CAUTION:
Thoroughly read and understand the vehicle specification. ECU control may not operate normally if
the setting is not correct.
EXCEPT FOR MEXICO
⇔
: Items which confirm vehicle specifications
MANUAL SETTING ITEM
NOTE
Items
Setting value
AV C/U
WITH
⇔
WITHOUT
• WITH: With navigation system
• WITHOUT: Without navigation system
AUTO BACK DOOR
WITH
⇔
WITHOUT
• WITH: With automatic back door system
• WITHOUT: Without automatic back door system
AUTO LIGHT
WITH
⇔
WITHOUT
—
DTRL
WITH
⇔
WITHOUT
• WITH: With daytime running light system
• WITHOUT: Without daytime running light system
RAIN SENSOR
WITH
⇔
WITHOUT
—
THEFT ALM AREA
WITHOUT
⇔
MODE2
• WITHOUT: Without vehicle security system
• MODE2: With vehicle security system
Key Fob Type
MODE7
⇔
MODE9
• MODE7: With automatic back door system
• MODE9: Without automatic back door system
AUTO SETTING ITEM
NOTE
Items
Setting value
BATTERY SAVER FUNCTION
MODE3
—
Trunk/Glass Hatch select
Glass Hatch
Even on a vehicle without glass hatch. It displays “Glass
Hatch”.
TRANSIT MODE
WITH
—
ACC BAT SAVE FUNC
MODE2
—
TR OPEN SW (INT)
MODE1
—
H/L BULB
DEFAULT
—
FR FOG LAMP
WITH
—
RR FOG LAMP
WITH
Even on a vehicle without rear fog lamp. It displays “WITH”.
DI LMP VARIAT
MODE2
—
LIGHT RECOG
MODE7
TRANSMISSION
AT with ABS
—
REAR WIPER
WITH
—
HAZARD SW TYPE
MODE1
—
TR CANCEL SW
WITHOUT
—
BCM AC CONTROL
MODE1
—
TRUNK ACT OUTPUT
MODE2
—
TPMS WITH
—
TIRE PRESSURE
230kPa
—
