Nissan Murano. Manual - part 1470





WCS-102

< PRECAUTION >

PRECAUTIONS

"SEAT BELT PRE-TENSIONER"

INFOID:0000000009721390

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIR BAG” and
“SEAT BELT” of this Service Manual.

WARNING:

Always observe the following items for preventing accidental activation.
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision that would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see “SRS AIR BAG”.

• Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-

vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

Always observe the following items for preventing accidental activation.
• When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the

ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with
a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing
serious injury.

• When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the

battery, and wait at least 3 minutes before performing any service.

FOR MEXICO : Precautions for Removing of Battery Terminal

INFOID:0000000010088581

•  When removing the 12V battery terminal, turn OFF the ignition

switch and wait at least 30 seconds.
NOTE:
ECU may be active for several tens of seconds after the ignition
switch is turned OFF. If the battery terminal is removed before ECU
stops, then a DTC detection error or ECU data corruption may
occur.

•  For vehicles with the 2-batteries, be sure to connect the main bat-

tery and the sub battery before turning ON the ignition switch.
NOTE:
If the ignition switch is turned ON with any one of the terminals of
main battery and sub battery disconnected, then DTC may be
detected.

•  After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC.

NOTE:
The removal of 12V battery may cause a DTC detection error.

SEF289H

WT-1

SUSPENSION

C

D

F

G

H

I

J

K

L

M

SECTION

WT

A

B

WT

N

O

P

CONTENTS

ROAD WHEELS & TIRES

PRECAUTION ...............................................

3

PRECAUTIONS ...................................................

3

FOR USA AND CANADA ............................................

3

FOR USA AND CANADA : Precaution for Supple-
mental Restraint System (SRS) "AIR BAG" and
"SEAT BELT PRE-TENSIONER" ............................
..

3

FOR MEXICO  ..............................................................

3

FOR MEXICO : Precaution for Supplemental Re-
straint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER" .................................................
..

3

Precautions for Removing of Battery Terminal  .........

4

Service Notice and Precautions for TPMS  ................

4

Service Notice and Precautions for Road Wheel ......

4

PREPARATION ............................................

5

PREPARATION ...................................................

5

Special Service Tool  .................................................

5

Commercial Service Tool  ..........................................

5

SYSTEM DESCRIPTION  ..............................

6

COMPONENT PARTS  ........................................

6

Component Parts Location ........................................

6

Component Description .............................................

6

BCM ..........................................................................

6

Tire Pressure Sensor  ................................................

7

Tire Pressure Receiver  .............................................

7

Information Display  ...................................................

7

SYSTEM ..............................................................

8

System Description  ...................................................

8

DIAGNOSIS SYSTEM (BCM)  .............................

9

COMMON ITEM  ...........................................................

9

COMMON ITEM : CONSULT Function (BCM -
COMMON ITEM) .....................................................
..

9

AIR PRESSURE MONITOR  ......................................

10

AIR PRESSURE MONITOR : CONSULT Function
(BCM - AIR PRESSURE MONITOR)  ......................

10

ECU DIAGNOSIS INFORMATION ..............

13

BCM ...................................................................

13

List of ECU Reference .............................................

13

WIRING DIAGRAM  ......................................

14

TIRE PRESSURE MONITORING SYSTEM ......

14

Wiring Diagram ........................................................

14

BASIC INSPECTION  ...................................

17

DIAGNOSIS AND REPAIR WORK FLOW  .......

17

Work Flow ................................................................

17

ADDITIONAL SERVICE WHEN REPLACING
BCM ...................................................................

19

Description ...............................................................

19

Work Procedure .......................................................

19

TIRE PRESSURE SENSOR WAKE UP OP-
ERATION ...........................................................

20

Description ...............................................................

20

Work Procedure .......................................................

20

TIRE PRESSURE SENSOR ID REGISTRA-
TION ..................................................................

21

Description ...............................................................

21

Work Procedure .......................................................

21

DTC/CIRCUIT DIAGNOSIS  .........................

23

C1704, C1705, C1706, C1707 LOW TIRE
PRESSURE .......................................................

23

Description ...............................................................

23

DTC Logic ................................................................

23

Diagnosis Procedure  ...............................................

23

C1708, C1709, C1710, C1711 TIRE PRES-
SURE SENSOR .................................................

25

WT-2

DTC Logic ...............................................................

25

Diagnosis Procedure  ..............................................

25

C1716, C1717, C1718, C1719 TIRE PRES-
SURE SENSOR  .................................................

28

DTC Logic ...............................................................

28

Diagnosis Procedure  ..............................................

28

C1729 VEHICLE SPEED SIGNAL  ....................

29

Description ..............................................................

29

DTC Logic ...............................................................

29

Diagnosis Procedure  ..............................................

29

C1734 BCM ........................................................

30

DTC Logic ...............................................................

30

Diagnosis Procedure  ..............................................

30

TIRE PRESSURE RECEIVER  ...........................

32

Component Function Check  ...................................

32

Diagnosis Procedure  ..............................................

32

LOW TIRE PRESSURE WARNING LAMP  .......

34

Component Function Check  ...................................

34

Diagnosis Procedure  ..............................................

34

POWER SUPPLY AND GROUND CIRCUIT  .....

35

Diagnosis Procedure  ..............................................

35

SYMPTOM DIAGNOSIS  .............................

36

TPMS .................................................................

36

Symptom Table  ......................................................

36

LOW TIRE PRESSURE WARNING LAMP
DOES NOT TURN ON  .......................................

39

Description ..............................................................

39

Diagnosis Procedure  ..............................................

39

LOW TIRE PRESSURE WARNING LAMP
DOES NOT TURN OFF  .....................................

40

Description ..............................................................

40

Diagnosis Procedure  ..............................................

40

LOW TIRE PRESSURE WARNING LAMP
BLINKS ..............................................................

41

Description ..............................................................

41

Diagnosis Procedure ...............................................

41

ID REGISTRATION CANNOT BE COMPLET-
ED ......................................................................

42

Description ..............................................................

42

Diagnosis Procedure ..............................................

42

NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ............................

43

NVH Troubleshooting Chart ....................................

43

PERIODIC MAINTENANCE  .......................

44

ROAD WHEEL ...................................................

44

Adjustment ..............................................................

44

REMOVAL AND INSTALLATION ..............

46

ROAD WHEEL TIRE ASSEMBLY  ....................

46

Exploded View  ........................................................

46

Removal and Installation .........................................

46

Inspection ................................................................

46

TIRE PRESSURE SENSOR  ..............................

48

Exploded View  ........................................................

48

Removal and Installation .........................................

49

TIRE PRESSURE RECEIVER ...........................

51

Removal and Installation .........................................

51

SERVICE DATA AND SPECIFICATIONS
(SDS) ..........................................................

52

SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................

52

Road Wheel  ............................................................

52

Tire Air Pressure  .....................................................

52

PRECAUTIONS

WT-3

< PRECAUTION >

C

D

F

G

H

I

J

K

L

M

A

B

WT

N

O

P

PRECAUTION

PRECAUTIONS

FOR USA AND CANADA

FOR USA AND CANADA : Precaution for Supplemental Restraint System (SRS) "AIR
BAG" and "SEAT BELT PRE-TENSIONER"

INFOID:0000000010069718

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIR BAG” and
“SEAT BELT” of this Service Manual.

WARNING:

Always observe the following items for preventing accidental activation.
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision that would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see “SRS AIR BAG”.

• Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-

vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

Always observe the following items for preventing accidental activation.
• When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the

ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with
a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing
serious injury.

• When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the

battery, and wait at least 3 minutes before performing any service.

FOR MEXICO

FOR MEXICO : Precaution for Supplemental Restraint System (SRS) "AIR BAG" and
"SEAT BELT PRE-TENSIONER"

INFOID:0000000010069719

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this
Service Manual.

WARNING:

Always observe the following items for preventing accidental activation.
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision that would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see “SRS AIR BAG”.

• Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-

vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:















содержание   ..  1468  1469  1470  1471   ..
