SHIFT POSITION INDICATOR CIRCUIT

SHIFT POSITION INDICATOR CIRCUIT

Description

INFOID:0000000009719525

• TCM sends position indicator signals to combination meter via CAN communication line.
• The selector lever position is indicated on the shift position indicator.

Component Function Check

INFOID:0000000009719526

1.

CHECK SHIFT POSITION INDICATOR

CAUTION:

Always drive vehicle at a safe speed.
1.

Start engine.

2.

Check that correct selector lever position (“P”, “R”, “N”, “D”, “L”) is displayed as selector lever is moved
into each position.

Is the inspection result normal?

YES

>> INSPECTION END

NO

>> Go to

TM-106, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000009719527

1.

CHECK INPUT SIGNALS

With CONSULT

1.

Start engine.

2.

Select “RANGE” in “Data Monitor” and read out the value.

3.

Check that correct selector lever position (“P”, “R”, “N”, “D”, “L”) is displayed as selector lever is moved
into each position.

Is the inspection result normal?

YES

>> INSPECTION END

NO-1 (CVT position indicator does not indicate “L” when selector lever is moved into “L”.)>>Check  the  fol-

lowing.

• Check overdrive control switch. Refer to

TM-114, "Description"

.

• Check CVT main system (Fail-safe function actuated).
- Perform “Self Diagnostic Results” in “TRANSMISSION”.

NO-2 (The actual gear position changes, but the shift position indicator is not indicated.)>>Perform

“Self

Diagnostic Results” in “TRANSMISSION”.

NO-3 (The actual gear position and the indication on the shift position indicator do not coincide.)>>Perform

“Self Diagnostic Results” in “TRANSMISSION”.

NO-4 (Only a specific position or positions is/are not indicated on the shift position indicator.)>>Check

the

combination meter. Refer to

MWI-35, "CONSULT Function (METER/M&A)"

.

SHIFT LOCK SYSTEM

TM-107

< DTC/CIRCUIT DIAGNOSIS >

[CVT: RE0F09B]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

SHIFT LOCK SYSTEM

Description

INFOID:0000000009719528

Component

Function

Shift lock solenoid

It operates according to the signal from the stop lamp switch and
moves the lock lever.

Lock lever

It moves according to the operation of the shift lock solenoid and
performs the release of the shift lock.

Detent rod

It links with the selector button and restricts the selector lever
movement.

Park position switch

It detects that the selector lever is in “P” position.

Shift lock release button

It moves the lock lever forcibly.

TM-108

< DTC/CIRCUIT DIAGNOSIS >

[CVT: RE0F09B]

SHIFT LOCK SYSTEM

Wiring Diagram - CVT SHIFT LOCK SYSTEM -

INFOID:0000000009719529

JRDWC0476GB

SHIFT LOCK SYSTEM

TM-109

< DTC/CIRCUIT DIAGNOSIS >

[CVT: RE0F09B]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

JRDWC1702GB
