Nissan Murano. Manual - part 1185
RF-124
< REMOVAL AND INSTALLATION >
SUNSHADE
Removal and Installation
INFOID:0000000009719706
REMOVAL
1.
Remove the headlining. Refer to
INT-30, "SUNROOF : Removal and Installation"
2.
Remove the sunshade cover.
• Remove the sunroof brackets (LH/RH).
• Remove the screw, and then sunshade cover.
3.
Remove the front sunshade and rear sunshade.
Remove it to the lower part while pushing a front sunshade (1)
and rear sunshade (2) to the arrow direction of the figure.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
Be careful not to release the spring when installing the sunshade.
7.
Sunshade cover
8.
Rear sunshade
: Always replace after every disassembly.
JMKIA1910ZZ
