OPERATION

EC-869

< SYSTEM DESCRIPTION >

[R9M]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

OPERATION

AUTOMATIC SPEED CONTROL DEVICE (ASCD)

AUTOMATIC SPEED CONTROL DEVICE (ASCD) : Switch Name and Function

INFOID:0000000010935580

SWITCHES AND INDICATORS

SET SPEED RANGE

ASCD system can be set the following vehicle speed.

SWITCH OPERATION

SPEED LIMITER

SPEED LIMITER : Switch Name and Function

INFOID:0000000010935581

SWITCHES AND INDICATORS

NOTE:
Shared with ASCD switch.

CRUISE indicator

CANCEL switch

ACCL/RES switch

COAST/SET switch

Speed limiter MAIN Switch

ASCD MAIN switch

On the combination meter

On the steering wheel

JSBIA5014ZZ

Minimum speed (Approx.)

Maximum speed (Approx.)

40 km/h (25 MPH)

170 km/h (105 MPH)

Item

Function

CANCEL switch

Cancels the cruise control driving.

ACCL/RES switch

• Resumes the set speed.
• Increases speed incrementally during cruise control driving.

COAST/SET switch

• Sets desired cruise speed.
• Decreases speed incrementally during cruise control driving.

ASCD MAIN switch

Master switch to activate the ASCD system.

JSBIA5018ZZ

EC-870

< SYSTEM DESCRIPTION >

[R9M]

OPERATION

SET SPEED RANGE

Speed limiter system can be set the following vehicle speed.

SWITCH OPERATION

OIL CONTROL SYSTEM

OIL CONTROL SYSTEM : Switch Name and Function

INFOID:0000000010935582

SWITCHES AND INDICATORS

SWITCH OPERATION

RESET OPERATION

CAUTION:

When an alert was displayed, change the engine oil, and reset the engine oil data.
1.

Turn ignition switch ON.

2.

On information display, select “Settings” >> “Maintenance” >> “Service”.

Speed limiter indicator

CANCEL switch

ACCL/RES switch

COAST/SET switch

Speed limiter MAIN Switch

ASCD MAIN switch

On the combination meter

On the steering wheel

Minimum speed (Approx.)

Maximum speed (Approx.)

30 km/h (20 MPH)

180 km/h (115 MPH)

Item

Function

CANCEL switch

Cancels the speed limiter control.

ACCL/RES switch

• Resumes the set speed.
• Increases the set speed incrementally.

COAST/SET switch

• Sets desired speed.
• Decreases the set speed incrementally.

Speed limiter MAIN switch

Master switch to activate the speed limiter system.

Combination meter

Steering

Information display

Enter/Up/Down switch

Back switch

Display switch

JSBIA5023ZZ

Item

Function

Steering switch

Refer to

MWI-82, "Switch Name and Function"

.

OPERATION

EC-871

< SYSTEM DESCRIPTION >

[R9M]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

3.

Press “ENTER” switch until “YES/NO” is appeared.

4.

Select “YES”.

5.

Check that “– – –” is displayed.

STOP/START SYSTEM

STOP/START SYSTEM : Switch Name and Function

INFOID:0000000010935583

SWITCHES AND INDICATORS

SWITCH OPERATION

NOTE:
If stop/start OFF switch turn ON when stop/start system is operating, stop/start system is canceled and engine
restart.

Stop/start indicator lamp

Stop/start OFF switch

On the combination meter

Lower instrument panel (driver side)

JSBIA3803ZZ

Item

Function

Stop/start OFF switch

When the switch is pressed, switch indicator (LED) turns ON and the stop/start
system can be deactivated.

EC-872

< SYSTEM DESCRIPTION >

[R9M]

HANDLING PRECAUTION

HANDLING PRECAUTION

Precaution for Stop/Start System

INFOID:0000000010935584

PRECAUTIONS FOR STOP/START SYSTEM OPERATION

The operation of the stop/start system needs to satisfy various conditions. For details of the conditions, refer to

EC-848, "STOP/START SYSTEM : System Description (M/T models)"

 (M/T models),

EC-856, "STOP/START

SYSTEM : System Description (CVT models)"

 (CVT models).

The stop/start system may not operate under the conditions listed below:
• After restarting the engine, the vehicle is repeatedly stopped and started at a low speed due to traffic con-

gestion.

• When driving the vehicle repeatedly back and forth at a low speed due to parallel parking.
• When the intelligent key is not authenticated. (In this case, the KEY warning lamp built in the combination

meter blinks.)

• The battery is deteriorated. (High discharge rate.)
• A battery other than the stop/start system-specific battery is used.
• Ambient temperature is extremely low.

HANDLING PRECAUTIONS

• When engine restart conditions are satisfied during the electric parking brake operation, ECM performs the

engine restart after the completion of the electric parking brake operation. This may cause delay in engine
restart, compared with a usual engine restart.
For a smooth engine restart under the stop/start system operating condition, restart the engine before
releasing the parking brake.

• To use the stop/start system, the vehicle needs to recognize the status of battery. For this reason, the stop/

start system may not be activated immediately after battery change.

• (For M/T only) When restarting the vehicle under stop/start system operating condition, continue depressing

the clutch pedal until the restart completes.
