FRONT FENDER DLK-273 < REMOVAL AND INSTALLATION > [TYPE 1] C D E F G H I J L M A B DLK N O P 2. Disengage fixing pawls according to the numerical order 1 → 3 indicated by arrows as shown in the figure, and then remove front fender cover. CAUTION: When performing the procedure after removing fender cover, protect the lower of windshield glass INSTALLATION Note the following item, and then install in the reverse order of removal. CAUTION: Install so that there is no clearance between windshield and cowl top cover. : Pawl : Vehicle front JMKIB3008ZZ |
