DAS WASHER PUMP DAS-161 < REMOVAL AND INSTALLATION > [DRIVER ASSISTANCE SYSTEM] C D E F G H I J K L M B N P A WASHER PUMP Exploded View INFOID:0000000010727965 Removal and Installation INFOID:0000000010727966 REMOVAL 1. Remove the front fender protector RH. Refer to EXT-35, "FENDER PROTECTOR : Removal and Installa- 2. Disconnect the harness connector from the rear camera washer pump and then remove the rear camera washer tube . 3. Remove the rear camera washer pump from washer tank. 4. Remove the packing from washer tank seal. INSTALLATION Installation is in the reverse order of removal. CAUTION: Add water to the top of washer tank inlet after installing. Check that no leaks exist. 1. Washer pump (Front / rear washer) 2. Packing 3. Rear camera wash- 4. Washer tank : Vehicle front AWOIA0072ZZ : Vehicle front JMLIA4858ZZ |
