DIAGNOSIS SENSOR UNIT

B0097–11

C-PILLAR SAT SEN RH

SRC-56, "DTC Description"

B0097–23

B0097–24

B0097–25

B0097–28

B0097–81

B0097–86

B0097–88

B0097–93

B0099–11

SATELLITE SENSOR

SRC-58, "DTC Description"

B0099–23

B0099–24

B0099–25

B0099–28

B0099–81

B0099–86

B0099–88

B0099–93

B00D2–04

PASS A/B ON INDCTR CIRC

SRC-60, "DTC Description"

B00D2–11

B00D2–12

B00D2–13

B00D2–15

B00D5–04

PASS A/B ON INDCTR CIRC

SRC-62, "DTC Description"

B00D5–11

B00D5–12

B00D5–13

B00D5–15

B00DF–52

PASS A/B DEACT SW

SRC-64, "DTC Description"

B1400–00

CONTROL UNIT

SRC-66, "DTC Description"

B1401–00

B1402–00

B1403–00

B1404–00

B1405–00

B1406–00

CONTROL UNIT

SRC-68, "DTC Description"

B1407–00

B1408–00

B1409–00

B1410–00

DTC

Diagnostic item

Reference page

DIAGNOSIS SENSOR UNIT

SRC-21

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

I

J

K

L

M

A

B

SRC

N

O

P

B1411–00

CONTROL UNIT

SRC-70, "DTC Description"

B1412–00

B1413–00

B1414–00

B1415–00

B1416–00

CONTROL UNIT

SRC-72, "DTC Description"

B1417–00

B1418–00

B1419–00

B1420–00

B1421–00

FRONTAL COLLISION

SRC-74, "DTC Description"

B1422–00

SIDE COLLISION

SRC-75, "DTC Description"

B1425–00

REAR COLLISION

SRC-76, "DTC Description"

B1426–00

AIRBAG DISPOSAL DETECT

SRC-77, "DTC Description"

B1427–54

CONFIG SETTING

SRC-78, "DTC Description"

B1427–55

B142A–16

IGNITION VOLTAGE

SRC-79, "DTC Description"

B142A–17

B1430–09

PRE-TEN FRONT LH

SRC-81, "DTC Description"

B1430–11

B1430–12

B1430–13

B1430–1A

B1431–09

PRE-TEN FRONT RH

SRC-83, "DTC Description"

B1431–11

B1431–12

B1431–13

B1431–1A

B1432–09

PRE-TEN FRONT LH 2

SRC-85, "DTC Description"

B1432–11

B1432–12

B1432–13

B1432–1A

B1433–09

PRE-TEN FRONT RH 2

SRC-87, "DTC Description"

B1433–11

B1433–12

B1433–13

B1433–1A

DTC

Diagnostic item

Reference page

SRC-22

< WIRING DIAGRAM >

SRS AIR BAG SYSTEM

WIRING DIAGRAM

SRS AIR BAG SYSTEM

Wiring Diagram

INFOID:0000000010688455

JRHWC2026GB

SRS AIR BAG SYSTEM

SRC-23

< WIRING DIAGRAM >

C

D

E

F

G

I

J

K

L

M

A

B

SRC

N

O

P

JRHWC2027GB
