MWI-102

< ECU DIAGNOSIS INFORMATION >

COMBINATION METER

30

(LG)

Ground

Manual mode signal

Input

Ignition

switch

ON

Selector lever manual mode
position

0 V

Other than the above

12 V

31

(SB)

Ground

Non-manual mode signal

Input

Ignition

switch

ON

Selector lever manual mode
position

12 V

Other than the above

0 V

32

(BG)

Ground

Manual mode shift up sig-
nal

Input

Ignition

switch

ON

Selector lever  UP operation

0 V

Other than the above

12 V

33

(BR)

Ground

Manual mode shift down
signal

Input

Ignition

switch

ON

Selector lever  DOWN oper-
ation

0 V

Other than the above

12 V

36

(GR)

17

(BG)

Illumination control switch
signal (+)

Input

Ignition

switch

ON

Illumination control switch
(+) is  pressed

0 V

Other than the above

4.8 V

37

(V)

17

(BG)

Illumination control switch
signal (

)

Input

Ignition

switch

ON

Illumination switch control (-)
is  pressed

0 V

Other than the above

4.8 V

38

(G)

Ground

Vehicle speed signal
(8-pulse)

Output

Ignition

switch

ON

Speedometer operated
[When vehicle speed is ap-
prox. 25 MPH (40 km/h)]

NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).

39

(W)

Ground

Vehicle speed signal
(2-pulse)

Output

Ignition

switch

ON

Speedometer operated
[When vehicle speed is ap-
prox. 25 MPH (40 km/h)]

NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).

41

(L)

Ground

CAN-H

42

(P)

Ground

CAN-L

43

(W)

Ground

Illumination control signal

Output

Ignition

switch

ON

Lighting switch 1ST position

12 V

Lighting switch OFF position

0 V

44

(LA/

B)

Ground

Fuel level sensor ground

Ignition

switch

ON

0  V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output

JSNIA0012GB

JSNIA0015GB

MWI

COMBINATION METER

MWI-103

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

*1: With stop/start system
*2: Without stop/start system
*3: The inspection of 1/4 is not required.

Fail-Safe

INFOID:0000000010714999

The combination meter activates the fail-safe control if CAN communication with each unit is malfunctioning.

45

(LA/

G)

Ground

Battery power supply

Input

Ignition

switch

OFF

Battery voltage

46

(V)

*1

(LA/

BR)

*

2

Ground

Ignition signal

Input

Ignition

switch

ON

12  V

47

(SB)

Ground

AV communication signal
(H)

48

(LG)

Ground

AV communication signal
(L)

49

(Y)

50

(BG)

Oil level sensor signal

Input

Ignition

switch

ON

MWI-126, "Component Inspec-

tion"

50

(BG)

Ground

Oil level sensor ground

Ignition

switch

ON

0  V

51

(LA/

L)

44

(LA/B)

Fuel level sensor signal

Input

Ignition

switch

ON

Fuel gauge indi-
cation position

Full

Less than 93

3/4

140

1/2

186

1/4

*3

1/8

255

Empty

More than 278

52

(B)

Ground

Ground

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output

Function

Specifications

Speedometer

Reset to zero by suspending communication.

Tachometer

Engine coolant temperature gauge

• When reception time of an abnormal signal is 60 seconds or

less, the last value received.

• When reception time of an abnormal signal is more than 60

seconds, reset to zero.

Illumination control

When suspending communication, changes to nighttime mode.

MWI-104

< ECU DIAGNOSIS INFORMATION >

COMBINATION METER

Information display

Odo/trip meter

An indicated value is maintained at communications blackout.

Shift position indicator

The display turns OFF by suspending communication.

Chassis control display

The display turns no effect by suspending communication.

4WD torque distribution display

The gauge displays 0% by suspending communication.

Trip com-
puter

Current fuel consump-
tion

The last result calculated during normal condition is indicated.

Average fuel consump-
tion

Average vehicle speed

Distance to empty

ECO pedal guide

The indicator turns OFF by suspending communication.

Warning/
Indicator

4WD warning

The display turns ON by suspending communication.

Chassis control warning

Other than the above

The display turns OFF by suspending communication.

Buzzer

The buzzer turns OFF by suspending communication.

Warning lamp/indicator lamp

ABS warning lamp

The lamp turns ON by suspending communication.

VDC warning lamp

Brake warning lamp

Electric power steering warning lamp

Malfunction indicator lamp (MIL) (yel-
low)

SRS air bag warning lamp

Brake system warning lamp

FEB warning lamp

Low tire pressure warning lamp

The lamp turns ON after flashing for 2 minutes.

Electric parking brake indicator lamp

The lamp blinking caused by suspending communication.

High beam indicator lamp

The lamp turns OFF by suspending communication.

VDC OFF indicator lamp

Turn signal indicator lamp

Front fog lamp indicator lamp

Rear fog lamp indicator lamp

Position lamp indicator lamp

Charge warning lamp

ECO mode indicator lamp

4WD indicator lamp

LOCK indicator lamp

Dipped beam indicator lamp

hill descent control indicator lamp

Water-in-fuel-filter warning lamp

Glow indicator lamp

Malfunction indicator lamp (MIL) (red)

High beam assist indicator lamp

hill start assist indicator lamp

Function

Specifications

MWI

COMBINATION METER

MWI-105

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

DTC Inspection Priority Chart

INFOID:0000000010715000

If multiple DTCs are detected simultaneously, check them one by one depending on the following DTC inspec-
tion priority chart.

DTC Index

INFOID:0000000010715001

Priority

Detected items (DTC)

1

• U1000: CAN COMM CIRCUIT
• U1010: CONTROL UNIT (CAN)

2

• B2205: VEHICLE SPEED
• B2267: ENGINE SPEED
• B2268: WATER TEMP
• B2321: OIL LEV SEN OPEN
• B2322: OIL LEV SEN SHORT
• B2323: ILLUMINATION OUTPUT CIRCUIT

DTC

CONSULT display

Refer to

U1000

CAN COMM CIRCUIT

MWI-121, "DTC Description"

U1010

CONTROL UNIT (CAN)

MWI-122, "DTC Description"

B2205

VEHICLE SPEED

MWI-123, "DTC Description"

B2267

ENGINE SPEED

MWI-124, "DTC Description"

B2268

WATER TEMP

MWI-125, "DTC Description"

B2321

OIL LEV SEN OPEN

MWI-126, "DTC Description"

B2322

OIL LEV SEN SHORT

MWI-126, "DTC Description"

B2323

ILLUMINATION OUTPUT CIRCUIT

MWI-128, "DTC Description"
