CONDENSER HA-127 < REMOVAL AND INSTALLATION > [QR25DE] C D E F G H J K L M A B HA N O P CONDENSER Exploded View INFOID:0000000011006127 CONDENSER CONDENSER : Removal and Installation INFOID:0000000011006128 CAUTION: Perform lubricant return operation before each refrigeration system disassembly. However, if a large 113, "Perform Lubricant Return Operation" REMOVAL 1. Use a refrigerant collecting equipment (for HFC-134a) to discharge the refrigerant. Refer to 2. Removal apron bracket. Refer to EXT-15, "Removal and Installation" . 3. Removal air guide. Refer to the following. DLK-574, "QR25DE : Exploded View" (WITH INTELLIGENT KEY SYSTEM) • DLK-878, "QR25DE : Exploded View" (WITHOUT INTELLIGENT KEY SYSTEM) Condenser upper bracket RH Refrigerant pressure sensor O-ring Condenser lower bracket RH Condenser & liquid tank assembly Condenser lower bracket LH Condenser upper bracket LH : Always replace after disassembly. : N·m (kg-m, ft-lb) JMIIA3360GB |
