AV-196

< DTC/CIRCUIT DIAGNOSIS >

[WITH NAVIGATION]

U111D SIDE CAMERA LH IMAGE SIGNAL CIRCUIT

RHD models without BSW

4.

Check continuity between around view monitor control unit harness connector and ground.

LHD models with BSW

LHD models without BSW

RHD models with BSW

RHD models without BSW

Is inspection result normal?

YES

>> GO TO 2.

NO

>> Repair harness or connector.

2.

CHECK VOLTAGE SIDE CAMERA LH POWER SUPPLY

1.

Connect around view monitor control unit connector and door mirror (passenger side) connector.

2.

Turn ignition switch ON.

3.

Check voltage between around view monitor control unit harness connector and ground.

LHD models with BSW

M102

62

D98

7

Existed

64

8

Around view monitor control

unit

Door mirror (passenger

side)

Continuity

Connector

Terminals

Connector

Terminals

M24

33

D98

8

Existed

34

7

Around view monitor control

unit

Ground

Continuity

Connector

Terminal

M102

56

Not existed

Around view monitor control

unit

Ground

Continuity

Connector

Terminal

M24

30

Not existed

Around view monitor control

unit

Ground

Continuity

Connector

Terminal

M102

62

Not existed

Around view monitor control

unit

Ground

Continuity

Connector

Terminal

M24

34

Not existed

Around view monitor control unit

Standard voltage

Reference voltage

(Approx.)

Connector

Terminal

(+)

(

−

)

Terminal

M102

56

58

5.0 - 9.0 V

6.0 V

AV

U111D SIDE CAMERA LH IMAGE SIGNAL CIRCUIT

AV-197

< DTC/CIRCUIT DIAGNOSIS >

[WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

LHD models without BSW

RHD models with BSW

RHD models without BSW

Is inspection result normal?

YES

>> GO TO 3.

NO

>> Replace around view monitor control unit. Refer to

AV-268, "Removal and Installation"

.

3.

CHECK CONTINUITY CAMERA IMAGE SIGNAL CIRCUIT

1.

Turn ignition switch OFF.

2.

Disconnect around view monitor control unit connector and door mirror (passenger side) connector.

3.

Check continuity between around view monitor control unit harness connector and door mirror (passenger
side) harness connector.

LHD models with BSW

LHD models without BSW

RHD models with BSW

Around view monitor control unit

Standard voltage

Reference voltage

(Approx.)

Connector

Terminal

(+)

(

−

)

Terminal

M24

30

29

5.0 - 9.0 V

6.0 V

Around view monitor control unit

Standard voltage

Reference voltage

(Approx.)

Connector

Terminal

(+)

(

−

)

Terminal

M102

62

64

5.0 - 9.0 V

6.0 V

Around view monitor control unit

Standard voltage

Reference voltage

(Approx.)

Connector

Terminal

(+)

(

−

)

Terminal

M24

34

33

5.0 - 9.0 V

6.0 V

Around view monitor control

unit

Door mirror (driver side)

Continuity

Connector

Terminals

Connector

Terminals

M102

59

D3

16

Existed

60

15

Around view monitor control

unit

Door mirror (driver side)

Continuity

Connector

Terminals

Connector

Terminals

M24

31

D3

15

Existed

32

16

Around view monitor control

unit

Door mirror (passenger

side)

Continuity

Connector

Terminals

Connector

Terminals

M102

65

D98

16

Existed

66

15

AV-198

< DTC/CIRCUIT DIAGNOSIS >

[WITH NAVIGATION]

U111D SIDE CAMERA LH IMAGE SIGNAL CIRCUIT

RHD models without BSW

4.

Check continuity between around view monitor control unit harness connector and ground.

LHD models with BSW

RHD models without BSW

RHD models with BSW

RHD models without BSW

Is inspection result normal?

YES

>> GO TO 4.

NO

>> Repair harness or connector.

4.

CHECK CAMERA IMAGE SIGNAL

1.

Connect around view monitor control unit connector and door mirror (passenger side) connector.

2.

Turn ignition switch ON.

3.

Check signal between around view monitor control unit harness connector terminals.

Around view monitor control

unit

Door mirror (passenger

side)

Continuity

Connector

Terminals

Connector

Terminals

M24

35

D98

15

Existed

36

16

Around view monitor control

unit

Ground

Continuity

Connector

Terminals

M102

59

Not existed

60

Around view monitor control

unit

Ground

Continuity

Connector

Terminals

M24

31

Not existed

32

Around view monitor control

unit

Ground

Continuity

Connector

Terminals

M102

65

Not existed

66

Around view monitor control

unit

Ground

Continuity

Connector

Terminals

M24

36

Not existed

35

AV

U111D SIDE CAMERA LH IMAGE SIGNAL CIRCUIT

AV-199

< DTC/CIRCUIT DIAGNOSIS >

[WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

LHD models with BSW

LHD models without BSW

RHD models with BSW

RHD models without BSW

Is inspection result normal?

Around view monitor control unit

Reference value

Connector

Terminal

(+)

(

−

)

Terminal

M102

59

60

Around view monitor control unit

Reference value

Connector

Terminal

(+)

(

−

)

Terminal

M24

32

31

Around view monitor control unit

Reference value

Connector

Terminal

(+)

(

−

)

Terminal

M102

65

66

Around view monitor control unit

Reference value

Connector

Terminal

(+)

(

−

)

Terminal

M24

36

35

JSNIA0834GB

JSNIA0834GB

JSNIA0834GB

JSNIA0834GB
