LU-6 [YD.] ENGINE OIL 6. Start engine and check for oil leakage. Changing Engine Oil EBS00SJC WARNING: ● Be careful not to burn yourself, as the engine oil is hot. ● Prolonged and repeated contact with used engine oil may 1. Put vehicle horizontally. 2. Warm up engine, and check for oil leakage from engine compo- 3. Stop engine and wait for 10 minutes. 4. Remove drain plug and oil filler cap. 5. Drain oil and refill with new engine oil. ● API grade CF- 4. ● Refer to MA-15, "RECOMMENDED FLUIDS AND LUBRI- Oil capacity (Approximate): ● The refill capacity depends on the oil temperature and drain time. Use these specifications for reference CAUTION: ● Be sure to clean drain plug and install with new washer. ● The refill capacity depends on the oil temperature and drain time. Use these specifications for 6. Warm up engine and check area around drain plug and oil filter for oil leakage. 7. Stop engine and wait for 10 minutes. 8. Check oil level. Oil pressure switch: : 13 - 17 N·m (1.4 - 1.7 kg-m, 10 - 12 ft-lb) PBIC0933E Drain and refill With oil filter change 5.2 (4-5/8 Imp qt) Without oil filter change 4.9 (4-3/8 Imp qt) Dry engine (engine overhaul) 6.3
(5-1/2 Imp qt) Oil pan drain plug: : 29 - 39 N·m (3.0 - 4.0 kg-m, 22 - 29 ft-lb) SBIA0122E |
