LAN-100 [CAN] CAN SYSTEM (TYPE 26) Combination Meter Circuit Check EKS00B72 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the negative battery cable. 3. Check terminals and connector of combination meter for damage, bend and loose connection. (meter side OK or NG OK >> GO TO 2. NG >> Repair terminal or connector. 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect combination meter connector. 2. Check resistance between combination meter harness connec- OK or NG OK >> Replace combination meter. NG >> Repair harness between smart entrance control unit and combination meter. 43 (L) – 44 (R) : Approx. 108 – 132 Ω PKIA0823E |
