TROUBLE DIAGNOSIS

BRC-69

[ESP/TCS/ABS]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

RR RH OUT SOL

(ON/OFF)

–

×

×

–

Rear RH wheel outlet sole-
noid valve (ON/OFF) status is
displayed.

FR RH IN SOL

(ON/OFF)

–

×

×

–

Front RH wheel inlet solenoid
valve (ON/OFF) status is dis-
played.

FR RH OUT SOL

(ON/OFF)

–

×

×

–

Front RH wheel outlet sole-
noid valve (ON/OFF) status is
displayed.

RR LH IN SOL

(ON/OFF)

–

×

×

–

Rear LH wheel inlet solenoid
valve (ON/OFF) status is dis-
played.

RR LH OUT SOL

(ON/OFF)

–

×

×

–

Rear LH wheel outlet solenoid
valve (ON/OFF) status is dis-
played.

USV [FL-RR]
(ON/OFF)

–

–

×

–

Primary-side switch-over
solenoid valve (ON/OFF) sta-
tus is displayed. (USV)

USV [FR-RL]
(ON/OFF)

–

–

×

–

Secondary-side switch-over
solenoid valve (ON/OFF) sta-
tus is displayed. (USV)

HSV [FL-RR]

(ON/OFF)

–

–

×

–

Primary-side switch-over
solenoid valve (ON/OFF) sta-
tus is displayed. (HSV)

HSV [FR-RL]

(ON/OFF)

–

–

×

–

Secondary-side switch-over
solenoid valve (ON/OFF) sta-
tus is displayed. (HSV)

V/R OUTPUT
(ON/OFF)

–

–

×

–

Actuator relay operation sig-
nal (ON/OFF) status is dis-
played.

M/R OUTPUT
(ON/OFF)

–

–

×

–

Motor relay activation signal
(ON/OFF) status is displayed.

VDC FAIL SIG

(ON/OFF)

–

–

×

–

ESP fail signal (ON/OFF) sta-
tus is displayed.

TCS FAIL SIG

(ON/OFF)

–

–

×

–

TCS fail signal (ON/OFF) sta-
tus is displayed.

ABS FAIL SIG
(ON/OFF)

–

–

×

–

ABS fail signal (ON/OFF) sta-
tus is displayed.

EBD FAIL SIG
(ON/OFF)

–

–

×

–

EBD fail signal (ON/OFF) sta-
tus is displayed.

FLUID LEV SW

(ON/OFF)

–

–

×

–

Brake fluid level warning
switch (ON/OFF) status is dis-
played.

SNOW MODE SW

(ON/OFF)

–

–

×

–

“OFF” is displayed.

BST OPER SIG

(ON/OFF)

–

–

×

–

“OFF” is displayed.

CAN COMM

(OK/NG)

–

–

–

×

CAN communication signal
(OK/NG) status is displayed.

Data Monitor Item (Unit)

Data Monitor item selection

Remarks

ECU INPUT

SIGNALS

MAIN

SIGNALS

SELECTION

FROM
MENU

CAN DIAG
SUPPORT

MNTR

BRC-70

[ESP/TCS/ABS]

TROUBLE DIAGNOSIS

×

: Applicable

–: Not applicable

ACTIVE TEST
Procedure

CAUTION:

●

Do not perform active test while driving the vehicle.

●

Make sure that completely bleed air from the brake system.

●

The active test cannot be performed with the ABS warning lamp on.

1.

Connect the CONSULT-II connector to the vehicle-side data link connector and start the engine.

2.

Touch “START (NISSAN BASED VHCL)” on the display.

CAN CIRC 1
(ON/ UNKWN)

–

–

–

×

CAN communication signal
(OK/UNKWN) status is dis-
played.

CAN CIRC 2
(OK/ UNKWN)

–

–

–

×

CAN CIRC 3
(OK/ UNKWN)

–

–

–

×

CAN CIRC 4
(OK/ UNKWN)

–

–

–

×

CAN CIRC 5
(ON / UNKWN)

–

–

–

×

CAN CIRC 6
(ON / UNKWN)

–

–

–

×

M MODE SIG

(ON/OFF)

–

–

×

–

“OFF” is displayed.

OD OFF SW
(ON/OFF)

–

–

×

–

“OFF” is displayed.

EBD SIGNAL
(ON/OFF)

–

–

×

–

EBD operation (ON/OFF) sta-
tus is displayed.

ABS SIGNAL
(ON/OFF)

–

–

×

–

ABS operation (ON/OFF) sta-
tus is displayed.

TCS SIGNAL

(ON/OFF)

–

–

×

–

TCS operation (ON/OFF) sta-
tus is displayed.

VDC SIGNAL
(ON/OFF)

–

–

×

–

ESP operation (ON/OFF) sta-
tus is displayed.

Data Monitor Item (Unit)

Data Monitor item selection

Remarks

ECU INPUT

SIGNALS

MAIN

SIGNALS

SELECTION

FROM
MENU

CAN DIAG
SUPPORT

MNTR

MBIB0233E

TROUBLE DIAGNOSIS

BRC-71

[ESP/TCS/ABS]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

3.

Touch “ABS” and “ACTIVE TEST”.

4.

The test item selection screen is displayed.

5.

Touch necessary test item.

6.

Touch “START” with “MAIN SIGNALS” line inverted.

7.

The active test screen is displayed.

PBR385C

SFIA0365E

SFIA0366E

SFIA0367E

SFIA0368E

BRC-72

[ESP/TCS/ABS]

TROUBLE DIAGNOSIS

Solenoid Valve

1.

Select each test items without “(ACT)” for the ABS function
active test, and with “(ACT)” for the ESP/TCS function active
test.

2.

Touch “UP”, “KEEP”, and “DOWN” or “UP”, “ACTUATOR UP”,
and “ACTUATOR KEEP”. And check that the solenoid valves
operate as the “Solenoid Valve Operation Chart”. Refer to

BRC-

72, "Solenoid Valve Operation Chart"

.

Solenoid Valve Operation Chart

*: ON for 1 to 2 seconds after the touch, and then OFF

NOTE:

●

If the active test is performed with the brake pedal depressed, the pedal stroke may be changed. This is a
normal condition.

●

“TEST STOP” is displayed 6 seconds after the operation start.

●

After “TEST STOP” is displayed, to perform the test again, repeat the step 6 of the operation procedure.

ESP OFF Indicator Lamp

Touch “ ON ” and “ OFF” on the “VDC WARNING LAMP” screen to check that ESP OFF indicator lamp oper-
ates as follows.

SFIA0366E

Operation

Without “(ACT)”

With “(ACT)”

UP

KEEP

DOWN

UP

ACTUA-
TOR UP

ACTUA-

TOR KEEP

FR RH SOL
FR RH ABS SOLE-
NOID (ACT)

FR RH IN SOL

OFF

ON

ON

OFF

OFF

OFF

FR RH OUT SOL

OFF

OFF

ON*

OFF

OFF

OFF

USV [FR-RL]

OFF

OFF

OFF

OFF

ON

ON

HSV [FR-RL]

OFF

OFF

OFF

OFF

ON*

OFF

FR LH SOL
FR LH ABS SOLE-
NOID (ACT)

FR LH IN SOL

OFF

ON

ON

OFF

OFF

OFF

FR LH OUT SOL

OFF

OFF

ON*

OFF

OFF

OFF

USV [FL-RR]

OFF

OFF

OFF

OFF

ON

ON

HSV [FL-RR]

OFF

OFF

OFF

OFF

ON*

OFF

RR RH SOL
RR RH ABS SOLE-
NOID (ACT)

RR RH IN SOL

OFF

ON

ON

OFF

OFF

OFF

RR RH OUT SOL

OFF

OFF

ON*

OFF

OFF

OFF

USV [FL-RR]

OFF

OFF

OFF

OFF

ON

ON

HSV [FL-RR]

OFF

OFF

OFF

OFF

ON*

OFF

RR LH SOL
RR LH ABS SOLE-
NOID (ACT)

RR LH IN SOL

OFF

ON

ON

OFF

OFF

OFF

RR LH OUT SOL

OFF

OFF

ON*

OFF

OFF

OFF

USV [FR-RL]

OFF

OFF

OFF

OFF

ON

ON

HSV [FR-RL]

OFF

OFF

OFF

OFF

ON*

OFF

FRONT SOLENOID
FRONT ABS SOLE-
NOID (ACT)

FR RH IN SOL

OFF

ON

ON

OFF

OFF

OFF

FR RH OUT SOL

OFF

OFF

ON

OFF

OFF

OFF

FR LH IN SOL

OFF

ON

ON

OFF

OFF

OFF

FR LH OUT SOL

OFF

OFF

ON

OFF

OFF

OFF

REAR SOLENOID
REAR ABS SOLE-
NOID (ACT)

RR RH IN SOL

OFF

ON

ON

OFF

OFF

OFF

RR RH OUT SOL

OFF

OFF

ON

OFF

OFF

OFF

RR LH IN SOL

OFF

ON

ON

OFF

OFF

OFF

RR LH OUT SOL

OFF

OFF

ON

OFF

OFF

OFF
