Nissan Primera P12. Manual - part 48
AUDIO
AV-35
C
D
E
F
G
H
I
J
L
M
A
B
AV
Removal and Installation of Audio Unit
EKS009JC
1.
Remove screws (4) and remove ashtray.
2.
Remove screws (4) and remove bracket.
Removal and Installation of Door Speaker
EKS009JD
1.
Remove door finisher.
●
Refer to EI section in P12 ESM (SM2E00-1P12E0E).
2.
Remove screws (3) and remove speaker.
Removal and Installation of Front Pillar Tweeter
EKS009JE
1.
Remove front pillar garnish.
●
Refer to EI section in P12 ESM (SM2E00-1P12E0E).
2.
Insert a clip remover or similar tool between the clip and front pil-
lar, then remove the front-pillar tweeter.
NOTE:
●
Remove the clip together with the front-pillar tweeter.
●
If it will not come off, break the clip and remove the front-pillar
tweeter.
CAUTION:
If clips were broken when removing front pillar tweeters,
attach new clips before reinstalling to vehicle.
SKIA0310E
SKIA0001E
SKIA1613E
