BRAKE CONTROL SYSTEM

BRC-57

< WIRING DIAGRAM >

[WITH ESP]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

JRFWC1350GB

BRC-58

< WIRING DIAGRAM >

[WITH ESP]

BRAKE CONTROL SYSTEM

JRFWC1351GB

BRAKE CONTROL SYSTEM

BRC-59

< WIRING DIAGRAM >

[WITH ESP]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

JRFWC1352GB

BRC-60

< BASIC INSPECTION >

[WITH ESP]

DIAGNOSIS AND REPAIR WORK FLOW

BASIC INSPECTION

DIAGNOSIS AND REPAIR WORK FLOW

Work Flow

INFOID:0000000010428737

DETAILED FLOW

1.

INTERVIEW FROM THE CUSTOMER

Clarify customer complaints before inspection. First of all, perform an interview utilizing

BRC-61, "Diagnostic

Work Sheet"

 and reproduce the symptom as well as fully understand it. Ask customer about his/her complaints

carefully. Check symptoms by driving vehicle with customer, if necessary.

CAUTION:

Customers are not professional. Never guess easily like “maybe the customer means that...,” or “
maybe the customer mentions this symptom”.

>> GO TO 2.

2.

CHECK SYMPTOM

Reproduce the symptom that is indicated by the customer, based on the information from the customer
obtained by interview. Also check that the symptom is not caused by fail-safe mode. Refer to

BRC-49, "Fail-

Safe"

.

CAUTION:

When the symptom is caused by normal operation, fully inspect each portion and obtain the under-
standing of customer that the symptom is not caused by a malfunction.

>> GO TO 3.

3.

PERFORM THE SELF-DIAGNOSIS

With CONSULT

1.

Turn the ignition switch OFF

 ON.

CAUTION:

Be sure to wait of 10 seconds after turning ignition switch OFF or ON.

2.

Repeat step 1 two or more times.

3.

Perform self-diagnosis for “ABS”.

Is DTC detected?

YES

>> Record or print self-diagnosis results and freeze frame data (FFD). GO TO 4.

NO

>> GO TO 6.

4.

RECHECK THE SYMPTOM

With CONSULT

1.

Erase self-diagnostic results for “ABS”.

2.

Turn the ignition switch OFF

 ON

 OFF.

CAUTION:

Be sure to wait of 10 seconds after turning ignition switch OFF or ON.

3.

Perform DTC confirmation procedures for the error-detected system.
NOTE:
If some DTCs are detected at the some time, determine the order for performing the diagnosis based on

BRC-52, "DTC Inspection Priority Chart"

.

Is any DTC detected?

YES

>> GO TO 5.

NO

>> Check harness and connectors based on the information obtained by interview. Refer to

GI-41,

"Intermittent Incident"

.

5.

REPAIR OR REPLACE ERROR-DETECTED PART

1.

Repair or replace error-detected parts.

2.

Reconnect part or connector after repairing or replacing.

3.

When DTC is detected, erase self-diagnostic result for “ABS”.
