ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
BRC-53
< ECU DIAGNOSIS INFORMATION >
[WITH ESP]
C
D
E
G
H
I
J
K
L
M
A
B
BRC
N
O
P
DTC Index
INFOID:0000000010427934
5
• C1101 RR RH SENSOR-1
• C1102 RR LH SENSOR-1
• C1103 FR RH SENSOR-1
• C1104 FR LH SENSOR-1
• C1105 RR RH SENSOR-2
• C1106 RR LH SENSOR-2
• C1107 FR RH SENSOR-2
• C1108 FR LH SENSOR-2
• C1108 FR LH SENSOR-2
• C1113 G SENSOR
• C1120 FR LH IN ABS SOL
• C1121 FR LH OUT ABS SOL
• C1122 FR RH IN ABS SOL
• C1123 FR RH OUT ABS SOL
• C1124 RR LH IN ABS SOL
• C1125 RR LH OUT ABS SOL
• C1126 RR RH IN ABS SOL
• C1127 RR RH OUT ABS SOL
• C1142 PRESS SEN CIRCUIT
• C1143 ST ANG SEN CIRCUIT
• C1145 YAW RATE SENSOR
• C1146 SIDE G SEN CIRCUIT
• C1160 DECEL G SEN SET
• C1164 CV 1
• C1165 CV 2
• C1197 VACUUM SENSOR
• C1198 VACUUM SEN CIR
• C1199 BRAKE BOOSTER
• C119A VACUUM SEN VOLT
6
• C1155 BR FLUID LEVEL LOW
Priority
Detected item (DTC)
DTC
Display Item
VDC warning
lamp
ABS warning
lamp
Brake warning
lamp
Refer to
C10D7
PARKING BRAKE SYSTEM
ON
ON
ON
C1101
RR RH SENSOR-1
ON
ON
OFF
C1102
RR LH SENSOR-1
ON
ON
OFF
C1103
FR RH SENSOR-1
ON
ON
OFF
C1104
FR LH SENSOR-1
ON
ON
OFF
C1105
RR RH SENSOR-2
ON
ON
OFF
C1106
RR LH SENSOR-2
ON
ON
OFF
C1107
FR RH SENSOR-2
ON
ON
OFF
C1108
FR LH SENSOR-2
ON
ON
OFF
C1109
BATTERY VOLTAGE [ABNOMAL]
ON
ON
ON
C1109
BATTERY VOLTAGE [ABNOMAL]
ON
ON
ON
C1110
CONTROLLER FAILURE
ON
ON
ON
C1113
G SENSOR
ON
ON
OFF
C1115
ABS SENSOR [ABNORMAL SIGNAL]
ON
ON
OFF
C1116
STOP LAMP SW
ON
ON
OFF
C1120
FR LH IN ABS SOL
ON
ON
ON
C1121
FR LH OUT ABS SOL
ON
ON
ON
C1122
FR RH IN ABS SOL
ON
ON
ON
C1123
FR RH OUT ABS SOL
ON
ON
ON
