CVT FLUID
TM-615
< PERIODIC MAINTENANCE >
[CVT: RE0F10G]
C
E
F
G
H
I
J
K
L
M
A
B
TM
N
O
P
34. Select “Data Monitor” in “TRANSMISSION” using CONSULT.
35. Select “CONFORM CVTF DETERIORTN”.
36. Select “Erase”.
37. Perform air bleeding of electric oil pump. Refer to
38. Stop the engine.
Adjustment
INFOID:0000000010245673
CAUTION:
• During adjustment of the CVT fluid level, check CONSULT so that the oil temperature may be main-
tained from 35 to 45
°
C (95 to 113
°
F).
• During adjustment of the CVT fluid level, check that the engine speed is maintaining 500 rpm.
• Use caution when looking into the drain hole as there is a risk of dripping fluid entering the eye.
1.
Check that the selector lever is in the “P” position, then completely engage the parking brake.
2.
Start the engine.
3.
Adjust the CVT fluid temperature to be approximately 40
°
C (104
°
F).
NOTE:
The CVT fluid is largely affected by temperature. Therefore be sure to use CONSULT and check the
“FLUID TEMP” under “TRANSMISSION” in “Data Monitor” while adjusting.
4.
While depressing the brake pedal, shift the selector lever to the entire position from “P” to “D”, and shift it
to the “P” position.
NOTE:
Hold the lever at each position for 5 seconds.
5.
Lift up the vehicle.
6.
Check that there is no CVT fluid leakage.
7.
Remove the overflow plug
from converter housing.
8.
Install the charging pipe set (KV311039S0) (A) into the overflow
plug hole.
CAUTION:
Tighten the charging pipe by hand.
9.
Install the ATF changer hose (B) to the charging pipe.
CAUTION:
Press the ATF changer hose all the way onto the charging
pipe until it stops.
10. Fill approximately 0.5 liter (1/2 lmp qt) of the CVT fluid.
11. Remove the ATF changer hose from the charging pipe, and
check that the CVT fluid drains out from the charging pipe. If it
does not drain out, perform charging again.
CAUTION:
Perform this work with the vehicle idling.
12. When the flow of CVT fluid slows to a drip, remove the charging pipe from the converter housing.
13. Tighten the overflow plug to the specified torque. Refer to
.
CAUTION:
Never reuse O-ring.
Recommended fluid and fluid capacity
: Refer to
MA-59, "Fluids and Lubricants"
: Vehicle front
JSDIA3714ZZ
JSDIA3713ZZ
