STR-18

< WIRING DIAGRAM >

STARTING SYSTEM

JRBWD1456GB

DIAGNOSIS AND REPAIR WORK FLOW

STR-19

< BASIC INSPECTION >

C

D

E

F

G

H

I

J

K

L

M

A

STR

N

P

O

BASIC INSPECTION

DIAGNOSIS AND REPAIR WORK FLOW

Work Flow

INFOID:0000000010430894

DETAILED FLOW

NOTE:
If any malfunction is found, immediately disconnect the battery cable from the negative terminal.

CAUTION:

For models with stop/start system, erase the starter operation counter when the starter motor connec-
tor is disconnected. Refer to

ECH-120, "Work Procedure"

 (HR engine),

ECK-146, "Work Procedure"

(K9K engine),

EC9-155, "Work Procedure"

 (R9M engine) or

ECM-203, "Work Procedure"

 (MR16DDT

engine).

1.

CHECK ENGINE TYPE

Check the vehicle information.

>> GO TO 2.

2.

CHECK ENGINE START

Crank the engine and check that the engine starts.

Does the engine start?

YES

>> GO TO 3.

NO

>> GO TO 4.

3.

CHECK THAT THE STARTER MOTOR STOPS

Check that the starter motor stops after starting the engine.
Does the starter motor stop?

YES

>> INSPECTION END

NO-1

>> Type 1: Replace starter motor.

NO-2

>> Type 2: Replace magnetic switch.

4.

CHECK THE ENGINE SPEED WITH CRANKING

Check that the engine runs at cranking.
Does engine turn by cranking?

YES

>> GO TO 5.

NO

>> GO TO 6.

5.

CHECK THE ENGINE SPEED WITH CRANKING

Check that the engine speed is not low at cranking.

Does engine turn normally?

YES

>> Check ignition/fuel system.

NO

>> Check charge condition, corrosion and connection condition of the battery. Refer to

PG-147,

"Work Flow WITHOUT STOP/START SYSTEM"

.

6.

CHECK STARTER MOTOR ACTIVATION

Check that the starter motor runs at cranking.
Does starter motor turn?

Type

Engine

1

HR engine

K9K engine

R9M engine

MR16DDT engine

2

MR20DD engine

STR-20

< BASIC INSPECTION >

DIAGNOSIS AND REPAIR WORK FLOW

YES-1 >> Type 1: Replace starter motor.
YES-2 >> Type 2: GO TO 7.
NO

>> GO TO 8.

7.

CHECK STARTER MOTOR UNIT

1.

Remove starter motor.

2.

Check that the gear shaft of starter motor rotates.

Does gear shaft turn?

YES

>> Check pinion clutch. Refer to

STR-29, "MR20DD : Inspection"

.

NO

>> Check reduction gear, armature and gear shaft.

8.

CHECK POWER SUPPLY CIRCUIT

Check the following conditions.
• Fuse and fusible link
• Charge condition, corrosion and connection condition of the battery. Refer to

PG-147, "Work Flow WITH-

OUT STOP/START SYSTEM"

.

Are these inspection results normal?

YES

>> GO TO 9.

NO

>> Repair as needed.

9.

CHECK STARTING SYSTEM WIRING

Check the following.
• “B” terminal circuit. Refer to

STR-21, "Diagnosis Procedure"

.

• “S” terminal circuit. Refer to

STR-23, "Diagnosis Procedure"

.

Are these inspection results normal?

YES-1 >> Type 1: Replace starter motor.
YES-2 >> Type 2: GO TO 10.
NO

>> Repair as needed.

10.

CHECK MAGNETIC SWITCH OPERATION SOUND

Check that a magnetic switch operation sound can be heard when the ignition switch is set at the starting posi-
tion.

Does magnetic switch operation sound occur?

YES

>> GO TO 11.

NO

>> Replace magnetic switch.

11.

PINION AND RING GEAR ENGAGEMENT CHECK

Check condition of pinion and ring gear mesh.

Is the inspection result normal?

YES

>> GO TO 13.

NO

>> GO TO 12.

12.

CHECK STARTER MOTOR UNIT

Check the following.
• Adjust pinion movement. Refer to

STR-29, "MR20DD : Inspection"

.

• Check pinion moving mechanism.
• Check ring gear.
Are these inspection results normal?

YES

>> INSPECTION END

NO

>> Repair or replace, if necessary.

13.

CHECK STARTER MOTOR UNIT

Check that the starter motor runs when connecting the positive terminal (12 V) to starter motor terminal M and
the negative terminal (ground) to starter motor body.
Does the starter motor run?

YES

>> Replace magnetic switch.

NO

>> Repair starter motor.

B TERMINAL CIRCUIT

STR-21

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

A

STR

N

P

O

DTC/CIRCUIT DIAGNOSIS

B TERMINAL CIRCUIT

Diagnosis Procedure

INFOID:0000000010430895

CAUTION:

• Perform diagnosis under the condition that engine cannot start by the following procedure.
- Remove fuel pump fuse.
- Crank or start the engine (where possible) until the fuel pressure is released.
• For models with stop/start system, erase the starter operation counter when the starter motor con-

nector is disconnected. Refer to

ECH-120, "Work Procedure"

 (HR engine),

ECK-146, "Work Proce-

dure"

 (K9K engine),

EC9-155, "Work Procedure"

 (R9M engine) or

ECM-203, "Work Procedure"

(MR16DDT engine).

1.

CHECK “B” TERMINAL CIRCUIT 1

1.

Turn ignition switch OFF.

2.

Check that starter motor “B” terminal connection is clean and tight.

3.

Check voltage between starter motor “B” terminal and ground.

Except for MR engine

For MR engine

Is the inspection result normal?

YES

>> GO TO 2.

NO-1

>> For models with stop/start system: GO TO 4.

NO-2

>> For models without stop/start system: Check harness between battery and starter motor for open

circuit.

2.

CHECK BATTERY CABLE CONNECTION STATUS (VOLTAGE DROP TEST)

1.

Shift selector lever to “P” or “N” position. (CVT models)
Keep depressing clutch pedal fully. (M/T models)

2.

Check voltage between battery positive terminal and starter motor “B” terminal.

Except for MR engine

For MR engine

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Check harness between the battery and the starter motor for poor continuity.

(+)

(–)

Voltage (Approx.)

Starter motor

Connector

Terminal

F105

2 Ground

Battery

voltage

(+)

(–)

Voltage (Approx.)

Starter motor

Connector

Terminal

E70

2 Ground

Battery

voltage

(+)

(–)

Condition

Voltage (Approx.)

Starter motor

Connector

Terminal

Battery positive terminal

F105

2

When the ignition switch

is in START position

Less than

 0.5 V

(+)

(–)

Condition

Voltage (Approx.)

Starter motor

Connector

Terminal

Battery positive terminal

E70

2

When the ignition switch

is in START position

Less than

 0.5 V
