DAS-26

< SYSTEM DESCRIPTION >

[DRIVER ASSISTANCE SYSTEM]

SYSTEM

• Drift warning may not operate normally depending on the surrounding conditions, etc.

DAS

OPERATION

DAS-27

< SYSTEM DESCRIPTION >

[DRIVER ASSISTANCE SYSTEM]

C

D

E

F

G

H

I

J

K

L

M

B

N

P

A

OPERATION

LDW

LDW : Switch Name and Function

INFOID:0000000010416794

LDW : Menu Displayed by Pressing Each Switch

INFOID:0000000010416795

INDICATOR LAMP AND WARNING LAMP

DISPLAY AND WARNING

JMOIA0070GB

No.

Switch name

Description

1.

LDW setting display
(Combination meter setting display)

Turns LDW system ON/OFF

JMOIA0071GB

No.

Display item

Description

1.

LDW ON indicator

Indicates that the LDW system is ON

2.

LDW display “Lane”
(Speaker icon)

Indicates that the LDW system is ON

DAS-28

< SYSTEM DESCRIPTION >

[DRIVER ASSISTANCE SYSTEM]

OPERATION

NOTE:
After the operating conditions of warning are satisfied, the warning continues until the vehicle speed reaches
approximately 55 km/h (34 MPH). Refer to

DAS-15, "LDW : System Description"

.

BSW

BSW : Switch Name and Function

INFOID:0000000010416792

Vehicle condition/ Driver's operation

Action

LDW ON indi-

cator

Indication on the combination

meter

Buzzer

Less than Ap-
prox. 55 km/h
(34 MPH)

Close to lane marker

No action

ON

White

OFF

Approx. 60
km/h (37
MPH) or more

Close to lane marker

Warning

• Buzzer sounds
• Warning lamp

blinks (orange)

ON

OFF (orange) Blink

Short con-

tinuous

beeps

• Close to lane marker
• Turn signal ON (Deviate

side)

No action

ON

White

OFF

JSOIA1422ZZ

JSOIA1367ZZ

JSOIA1422ZZ

JMOIA0072GB

No.

Switch name

Description

1.

BSW setting display
(Combination meter setting display)

Turns BSW system ON/OFF

DAS

OPERATION

DAS-29

< SYSTEM DESCRIPTION >

[DRIVER ASSISTANCE SYSTEM]

C

D

E

F

G

H

I

J

K

L

M

B

N

P

A

BSW : System Display and Warning

INFOID:0000000010416793

INDICATOR AND WARNING LAMP

DISPLAY AND WARNING OPERATION

NOTE:

• If vehicle speed exceeds approximately 32 km/h (20 MPH), BSW function operates until the vehicle speed becomes lower than

approximately 29 km/h (18 MPH).

JMOIA0073GB

No.

Display item

Description

1.

BSW ON indicator

Indicates that the BSW system is ON

2.

BSW display “Blind spot”
(Speaker icon)

Indicates that the BSW system is ON

3.

BSW indicator

• Illuminates when detect other vehicles beside vehicle in an adjacent lane
• Blinks when BSW system is warning to driver

Vehicle condition/ Driver's operation

Action

BSW ON

indicator

Vehicle speed

(Approx.)

[km/h (MPH)]

Turn signal

condition

Status of ve-

hicle detec-

tion within

detection

area

Indication on the BSW indicator

Buzzer

OFF

—

—

—

OFF

OFF

ON

Less than ap-

prox.

29km/h

(18MPH)

—

—

OFF

OFF

Approx.

32 km/h (20

MPH)

 or more

—

Vehicle is

absent

OFF

OFF

OFF

Vehicle is

detected

ON

OFF

ON

(vehicle de-

tected direc-

tion)

Before turn

signal oper-

ates

Vehicle is

detected

Blink

Short continuous beep

Vehicle is

detected af-

ter turn sig-

nal operates

Blink

OFF

JSOIA0251GB

JSOIA0252GB

JSOIA0251GB
