Nissan Qashqai J11. Manual - part 1660

DIAGNOSIS SYSTEM (BCM)

MIR-15

< SYSTEM DESCRIPTION >

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY) (Type 2)

INFOID:0000000011405206

WORK SUPPORT

IGN CONT2

This test is able to operate the blower relay in fuse block (J/B)
• On: Operates
• Off: Non-operation

MIRROR +5

NOTE:
This item is displayed, but cannot be used

ENGINE SW ILLUMI

This test is able to check push-ignition switch illumination operation
Push-ignition switch illumination illuminates when “ON” on CONSULT screen is touched

PUSH SWITCH INDICATOR

This test is able to check LOCK indicator in push-ignition switch operation
LOCK indicator in push-ignition switch illuminates when “ON” on CONSULT screen is touched

ENGINE START REQUEST

This test is able to check BCM sends starter request signal to IPDM E/R via CAN communi-
cation
• MODE 1: IGN ON, START request OFF
• MODE 2: IGN OFF, START request ON
• MODE 3: IGN ON, START request ON
• Off: Non-operation

IGNITION RELAY

NOTE:
This item is displayed, but cannot be used

STARTER CUT RELAY

This test is able to operate the starter control relay
• On: Operates
• Off: Non-operation

ENGINE START

NOTE:
This item is displayed, but cannot be used

TRUNK/BACK DOOR

This test is able to check back door opener actuator open operation
Back door opener actuator opens when “Open” on CONSULT screen is touched

RETRACTABLE MIRROR

NOTE:
This item is displayed, but cannot be used

REVERSE LAMP TEST

NOTE:
This item is displayed, but cannot be used

KEYFOB P/W TEST

NOTE:
This item is displayed, but cannot be used

AUTO ACC 2

This test is able to check BCM sends power supply to audio unit or NAVI control unit
• On: Operate
• Off: Non-operation

AUTOMATIC BACK DOOR

NOTE:
This item is displayed, but cannot be used

AUTO ACC 1

This test is able to check BCM sends power supply to ignition relay
• On: Operate
• Off: Non-operation

TRUNK/LUGGAGE LAMP
TEST

This test is able to check trunk room lamp operation
• On: Operates
• Off: Non-operation

Test item

Description

Monitor item

Description

INSIDE ANT DIAGNOSIS

This function allows inside key antenna self-diagnosis

LOCK/UNLOCK BY I-KEY

Door lock/unlock function by door request switch mode can be changed to operation in this
mode
• On: Operate
• Off: Non-operation

MIR-16

< SYSTEM DESCRIPTION >

DIAGNOSIS SYSTEM (BCM)

SELF-DIAG RESULT

Refer to

BCS-89, "DTC Index"

.

DATA MONITOR

NOTE:
The following table includes information (items) inapplicable to this vehicle. For information (items) applicable
to this vehicle, refer to CONSULT display items.

ENGINE START BY I-KEY

Engine start function mode can be changed to operation with this mode
• On: Operate
• Off: Non-operation

TRUNK/GLASS HATCH OPEN

NOTE:
This item is displayed, but cannot be monitored

AUTO LOCK SET

Auto door lock operation time can be changed in this mode
• MODE 1: OFF
• MODE 2: 30 sec
• MODE 3: 1 minute
• MODE 4: 2 minutes
• MODE 5: 3 minutes
• MODE 6: 4 minutes
• MODE 7: 5 minutes

SHORT CRANKING OUTPUT

NOTE:
This item is displayed, but cannot be monitored

IGN/ACC BATTERY SAVER

Ignition battery saver system mode can be changed to operation with this mode
• On: Operate
• Off: Non-operation

ANSWER BACK

NOTE:
This item is displayed, but cannot be used

ANSWER BACK I-KEY LOCK UN-
LOCK

Reminder function (door request switch) mode can be selected from the following with this
mode
• On: hazard warning lamp operate
• Off: hazard warning lamp operate

ANSWER BACK KEYLESS LOCK
UNLOCK

Reminder function (Intelligent Key) mode can be selected from the following with this mode
• On: hazard warning lamp operate
• Off: hazard warning lamp operate

WELCOME LIGHT OP SET

NOTE:
This item is indicated, but not used

Monitor item

Description

Monitor Item

Condition

REQ SW -DR

Indicates [On/Off] condition of door request switch (driver side)

REQ SW -AS

Indicates [On/Off] condition of door request switch (passenger side)

REQ SW -BD/TR

Indicates [On/Off] condition of back door request switch

PUSH SW

Indicates [On/Off] condition of push-button ignition switch

CLUTCH SW*

1

Indicates [On/Off] condition of clutch interlock switch

BRAKE SW 1

Indicates [On/Off]*

2

 condition of stop lamp switch power supply

BRAKE SW 2

Indicates [On/Off] condition of stop lamp switch

DETE/CANCL SW

Indicates [On/Off] condition of P position

START CLUTCH SW

Indicates [On/Off] condition of clutch pedal position switch

PUSH SW -IPDM

Indicates [On/Off] condition of push-button ignition switch

IGN RLY1 -F/B

Indicates [On/Off] condition of ignition relay 1

NEUTRAL SW - IPDM

Indicates [On/Off] condition of park/neutral position switch

SFT PN -IPDM

Indicates [On/Off] condition of P or N position

STARTER RELAY - IPDM

Indicates [On/Off] condition of starter relay

DIAGNOSIS SYSTEM (BCM)

MIR-17

< SYSTEM DESCRIPTION >

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

ENGINE STATE

Indicates [Stop/Stall/Crank/Run] condition of engine states

ST/INHIRELAY-IPDM

Display the starter relay/starter control relay status signal from IPDM E/R via CAN communica-
tion

REVERSE SIGNAL - IPDM

Indicates [On/Off] condition of R position

CRANKING PERMIT - ECM

Display the engine cranking permit signal from ECM via CAN communication

IS STATUS - ECM

Indicates [On/Off] condition of stop/start system

STARTER CUT RELAY - ECM

Indicates [On/Off] condition of starter control relay signal from ECM via CAN communication

VEH SPEED 1

Display the vehicle speed signal received from combination meter by numerical value [Km/h]

VEH SPEED 2

Display the vehicle speed signal received from ABS or VDC or TCM by numerical value [Km/h]

IGN REQ - IPDM

Display the ignition request signal from IPDM E/R via CAN communication

STARTER REQ - IPDM

Display the starter request signal from IPDM E/R via CAN communication

DOOR STAT-DR

Indicates [LOCK/READY/UNLK] condition of driver door status

DOOR STAT-AS

Indicates [LOCK/READY/UNLK] condition of passenger door status

DOOR STAT-RR

Indicates [LOCK/READY/UNLK] condition of rear door RH status

DOOR STAT-RL

Indicates [LOCK/READY/UNLK] condition of rear door LH status

BK DOOR STATE

NOTE:
This item is displayed, but cannot be monitored

ID OK FLAG

Indicates [Set/Reset] condition of Intelligent Key ID

PRMT ENG STRT

Indicates [Set/Reset] condition of engine start possible

PRMT RKE STRT

NOTE:
This item is displayed, but cannot be monitored

I-KEY OK FLAG

Indicates [KEY On/NOT On] condition of Intelligent Key ID and Intelligent Key is detected inside
vehicle

PRBT ENG STRT

Indicates whether or not the engine is in start prohibited status

ID AUTHENT CANCEL TIMER

Indicates whether or not it is in engine start possible status when Intelligent Key verification is
unnecessary

ACC BATTERY SAVER

Indicates [On/Off] whether or not ignition battery saver is in operation

CRNK PRBT TMR

Indicates [On/Off] whether or not in cranking prohibited status due to starter motor protection
function operation

AUT CRANK TMR

Indicates [On/Off] whether or not in AUTO CRANKING MODE status

CRNK PRBT TME

Indicates the time for changing from cranking prohibited status to cranking possible status

AUT CRANK TMR

Indicates the time that AUTO CRANKING MODE operates

CRANKING TME

Indicates the cranking operation time

SHORT CRANK

NOTE:
This item is displayed, but not used

RKE OPE COUN1

When remote keyless entry receiver receives the signal transmitted while operating on Intelli-
gent Key, the numerical value start changing

RKE OPE COUN2

NOTE:
This item is displayed, but cannot be monitored

S/L IGN OFF POSITION

Indicates [On/Off] condition of Ignition OFF signal

S/L SENSOR CIRCUIT 1

Indicates [Gnd/Off] condition of steering lock unit sensor circuit

S/L SENSOR CIRCUIT 2

Indicates [On/Off] condition of steering lock unit sensor circuit

S/L POWER OUTPUT

Indicates [On/Off] condition of steering lock unit power supply

S/L POWER CHECK

Indicates [On/Off] condition of steering lock unit power supply

ANTICIPATED POWER

Indicates [On/Off] condition of anticipated power supply

S/L LOCK REQ

Indicates [On/Off] condition of steering lock unit lock request signal

S/L - BCM (CAN)

Indicates [On/Off] condition of CAN communication

Monitor Item

Condition

MIR-18

< WIRING DIAGRAM >

AUTO ANTI-DAZZLING MIRROR SYSTEM

AUTO ANTI-DAZZLING MIRROR SYSTEM

Wiring Diagram

INFOID:0000000010502665

JRLWD2029GB
