BODY ALIGNMENT

2WD : Rear Body

INFOID:0000000010498844

MEASUREMENT

Dimensions marked with

″

*

″

 indicate symmetrically identical dimensions on both the right and left hand of the

vehicle.

«The others»

Unit: mm (in)

MEASUREMENT POINTS



Outer side body indent



Rear seat crossmember hole center

:

φ

16 (0.63)

: 18

×

16 (0.71

×

0.63)







Front pillar indent















Door hinge installing hole center







:

φ

12 (0.47)







:

φ

9 (0.35)

Point

Material

Point

Material

Unit: mm (in)

JSKIA3915GB

Point

Dimension

Memo

Point

Dimension

Memo

Point

Dimension

Memo

 –

987 (38.86)*

 –

688 (27.09)*

 –

578 (22.76)*

BODY ALIGNMENT

BRM-221

< SERVICE DATA AND SPECIFICATIONS (SDS)

[FOR EUROPE (RHD)]

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Unit: mm (in)

4WD

4WD : Body Center Marks (Without Sunroof Models)

INFOID:0000000010499774

A mark is placed on each part of the body to indicate the vehicle center. When repairing the vehicle frame
(members, pillars, etc.) damaged by an accident which it enables more accurate and effective repair by using
these marks together with body alignment specifications.

: Vehicle front

JSKIA3916ZZ

Point

Material

Point

Material

Roof flange end of center positioning mark



Lower rear pillar reinforcement joggle



Rear fender extension joggle



Back door lock support hole center

φ

14 (0.55)



Lower back pillar main joggle

BRM-222

< SERVICE DATA AND SPECIFICATIONS (SDS)

[FOR EUROPE (RHD)]

BODY ALIGNMENT

Unit: mm (in)

4WD : Body Center Marks (With Sunroof Models)

INFOID:0000000010499775

A mark is placed on each part of the body to indicate the vehicle center. When repairing the vehicle frame
(members, pillars, etc.) damaged by an accident which it enables more accurate and effective repair by using
these marks together with body alignment specifications.

: Vehicle front

Points

Portion

Marks

A

Front roof

Embossment

B

Cowl top

indent

C

Cowl top

Hole

φ

8 (0.31)

D

Trans control reinforcement

Hole 12

×

14 (0.47

×

0.55)

E

Rear roof

Embossment

JSKIA3956ZZ

BODY ALIGNMENT

BRM-223

< SERVICE DATA AND SPECIFICATIONS (SDS)

[FOR EUROPE (RHD)]

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Unit: mm (in)

4WD : Description

INFOID:0000000010499776

• All dimensions indicated in the figures are actual.
• When using a tracking gauge, adjust both pointers to equal length. Then check the pointers and gauge itself

to make sure there is no free play.

• When a measuring tape is used, check to be sure there is no elongation, twisting or bending.
• Measurements should be taken at the center of the mounting holes.

: Vehicle front

Points

Portion

Marks

A

Upper front roof rail

Embossment

B

Cowl top

indent

C

Cowl top

Hole

φ

8 (0.31)

D

Trans control reinforcement

Hole 12

×

14 (0.47

×

0.55)

E

Rear roof

Embossment

JSKIA3957ZZ
