GW-30
< REMOVAL AND INSTALLATION >
REAR REGULATOR
6.
Raise the rear door glass and hold in place with suitable tool (A).
7.
Remove the bolts and nuts from the rear door glass regulator.
8.
Disconnect the harness connector from the rear door regulator.
9.
Remove rear door regulator.
INSPECTION AFTER REMOVAL
Check the rear door glass regulator for the following items:
• Gear wear
• Rear door glass regulator deformation
• Spring damage
• Grease condition for each sliding part
If a malfunction is detected, replace or grease it.
INSTALLATION
Installation is in reverse order of removal.
Disassembly and Assembly
INFOID:0000000010502004
DISASSEMBLY
1.
Remove screws from rear door glass regulator.
2.
Remove rear door power window motor.
INSPECTION AFTER REMOVAL
Check the regulator assembly for the following items. Replace or grease it if a malfunction is detected.
• Wire wear
• Regulator deformation
ASSEMBLY
Assemble in the reverse order of disassembly.
Inspection and Adjustment
INFOID:0000000010502005
SYSTEM INITIALIZATION
Initialize the system if any of the following work is complete. Refer to
FITTING INSPECTION
• Check that the glass is fit securely into the sash groove.
• Lower the glass slightly [approximately 10 to 20 mm (0.394 to 0.787 in)], and check that the clearance to the
sash is parallel. Loosen the regulator mounting bolts, guide rail mounting bolts, and glass and guide rail
mounting bolts to correct the glass position if the clearance between the glass and sash is not parallel.
PIIB3511J
