FRONT DOOR LOCK DLK-957 < REMOVAL AND INSTALLATION > [TYPE 6] C D E F G H I J L M A B DLK N O P 11. Slide outside handle bracket toward rear of vehicle to remove. 12. Disconnect outside handle cable (1) from outside handle bracket (2) according to the numerical order 1 → 2 indicated by arrows as shown in the figure. CAUTION: Never bend the outside handle cable end. INSTALLATION Note the following items, and install in the reverse order of removal. CAUTION: • When installing key rod, rotate key rod holder until a click is felt. : Vehicle front JMKIA5890ZZ JMKIA5891ZZ |
