FRONT DOOR LOCK DLK-365 < REMOVAL AND INSTALLATION > [TYPE 2] C D E F G H I J L M A B DLK N O P 4. Remove door lock assembly screws, and then remove door lock assembly. INSTALLATION Note the following items, and install in the reverse order of removal. CAUTION: • Never reuse door lock assembly screw. Always replace it with a new one when it is removed. DLK-365, "DOOR LOCK : Inspection" • Check door open/close, lock/unlock operation after installation. DOOR LOCK : Inspection INFOID:0000000010478277 Check door lock assembly for poor lubrication. Apply body grease if INSIDE HANDLE INSIDE HANDLE : Removal and Installation INFOID:0000000010478278 REMOVAL 1. Remove front door finisher. Refer to INT-12, "FRONT DOOR FINISHER : Removal and Installation" . 2. Remove inside handle mounting bolt. 3. Disengage inside handle from door panel while sliding inside handle toward vehicle rear, and then sepa- 4. Disconnect inside handle cable, and then remove inside handle. INSTALLATION Note the following item, and install in the reverse order of removal. CAUTION: Check door open/close, lock/unlock operation after installation. OUTSIDE HANDLE OUTSIDE HANDLE : Removal and Installation INFOID:0000000010478279 REMOVAL 1. Fully close the front door glass. 2. Remove front door finisher. Refer to INT-12, "FRONT DOOR FINISHER : Removal and Installation" . 3. Remove sealing screen. 4. Remove front door glass rear run. Refer to GW-23, "Removal and Installation" . 5. Disengage outside handle cable from cable clip. 6. Disengage rod holder, and then disconnect key rod from door lock assembly. (Driver side only) 7. Disconnect outside handle harness connector. : Body grease JMKIA8534ZZ |
