Nissan Juke F15. Manual - part 978

MA-4

< PREPARATION >

PREPARATION

PREPARATION

Special Service Tool

INFOID:0000000012200174

The actual shapes of TechMate tools may differ from those of special service tools illustrated here.

Commercial Service Tool

INFOID:0000000012200175

Tool number
(TechMate No.)
Tool name

Description

KV10115801
(J 38956)
Oil filter wrench

Removing and installing oil filter
a: 64.3 mm (2.531 in)

S-NT375

Tool name

Description

Power tool

Loosening nuts and bolts

Spark plug wrench

Removing and installing spark plug
a : 14 mm (0.55 in)

Radiator cap tester

Checking radiator and radiator cap

Radiator cap tester adapter

Adapting radiator cap tester to radiator cap
and radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c:41.3 (1.626) dia.
Unit: mm (in)

PBIC0190E

JPBIA0399ZZ

PBIC1982E

S-NT564

GENERAL MAINTENANCE

MA-5

< PERIODIC MAINTENANCE >

PERIODIC MAINTENANCE

GENERAL MAINTENANCE

Explanation of General Maintenance

INFOID:0000000012200176

General maintenance includes those items which should be checked during the normal day-to-day operation

of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform

checks and inspections themselves or have their NISSAN dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle,

etc.

Item

Reference page

Tires

Check the pressure with a gauge often and always prior to long distance trips. Adjust
the pressure in all tires, including the spare, to the specified pressure. Check carefully
for damage, cuts or excessive wear.

WT-47

Wheel nuts

When checking the tires, make sure no nuts are missing, and check for any loose nuts.
Tighten if necessary.

—

Tire rotation

Tires should be rotated every 5,000 miles (8,000 km).

MA-43

Tire Pressure Monitor-
ing System (TPMS)
transmitter compo-
nents

Replace the TPMS transmitter grommet seal, valve core and cap when the tires are
replaced due to wear or age.

WT-40

Wheel alignment and
balance

If the vehicle should pull to either side while driving on a straight and level road, or if
you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If
the steering wheel or seat vibrates at normal highway speeds, wheel balancing may
be needed. For additional information regarding tires, refer to “lmportant Tire Safety
Information” (US) or “Tire Safety Information” (Canada) in the NISSAN Warranty Infor-
mation Booklet.

(2WD)

(AWD)

Windshield

Clean the windshield on a regular basis. Check the windshield at least every six
months for cracks or other damage. Repair as necessary.

—

Windshield wiper
blades

Check for cracks or wear if they do not wipe properly.

—

Doors and engine
hood

Check that all doors and the engine hood operate smoothly as well as the back door,
trunk lid and back hatch. Also make sure that all latches lock securely. Lubricate if nec-
essary. Make sure that the secondary latch keeps the hood from opening when the pri-
mary latch is released.
When driving in areas using road salt or other corrosive materials, check lubrication
frequently.

MA-47

Lamps

Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other
lamps are all operating properly and installed securely. Also check headlamp aim.
Clean the headlamps on a regular basis.

—

Item

Reference page

Warning lamps and
chimes

Make sure that all warning lamps and chimes are operating properly.

—

Windshield wiper and
washer

Check that the wipers and washer operate properly and that the wipers do not streak.

—

Windshield defroster

Check that the air comes out of the defroster outlets properly and in sufficient quantity
when operating the heater or air conditioning.

—

Steering wheel

Check that it has the specified play. Check for changes in the steering condition, such
as excessive play, hard steering or strange noises.
Free play: Less than 35 mm (1.38 in)

—

MA-6

< PERIODIC MAINTENANCE >

GENERAL MAINTENANCE

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

Seats

Check seat position controls such as seat adjusters, seatback recliner, etc. to make
sure they operate smoothly and that all latches lock securely in every position. Check
that the head restraints move up and down smoothly and that the locks (if equipped)
hold securely in all latched positions. Check that the latches lock securely for folding-
down rear seatbacks.

—

Seat belts

Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and re-
tractors) operate properly and smoothly and are installed securely. Check the belt
webbing for cuts, fraying, wear or damage.

MA-47

Accelerator pedal

Check the pedal for smooth operation and make sure the pedal does not catch or re-
quire uneven effort. Keep the floor mats away from the pedal.

—

Brakes

Check that the brake does not pull the vehicle to one side when applied.

—

Brake pedal and
booster

Check the pedal for smooth operation and make sure it has the proper distance under
it when depressed fully. Check the brake booster function. Be sure to keep floor mats
away from the pedal.

BR-9

BR-15

Clutch pedal

Make sure the pedal operates smoothly and check that it has the proper free play.

CL-6

Parking brake

Check that the lever or pedal has the proper travel and make sure that the vehicle is
held securely on a fairly steep hill when only the parking brake is applied.

PB-4

CVT P (Park) position
mechanism

On a fairly steep hill check that the vehicle is held securely with the selector lever in
the “P” position without applying any brakes.

—

Item

Reference page

Item

Reference page

Windshield washer
fluid

Check that there is adequate fluid in the tank.

—

Engine coolant level

Check the coolant level when the engine is cold.

MA-16
MA-26

Radiator and hoses

Check the front of the radiator and clean off any dirt, insects, leaves, etc., that may
have accumulated. Make sure the radiator hoses have no cracks, deformation, dete-
rioration or loose connections.

MA-20

Brake and clutch fluid
levels

Make sure that the brake and clutch fluid level(s) are(is) between the “MAX” and “MIN”
lines on the reservoir(s).

MA-43
MA-38

Battery

Check the fluid level in each cell. It should be between the “MAX” and “MIN” lines. Ve-
hicles operated in high temperatures or under severe conditions require frequent
checks of the battery fluid level.

PG-97

Engine drive belts

Make sure that no belt is frayed, worn, cracked or oily.

MA-15
MA-25

Engine oil level

Check the level on the oil level gauge after parking the vehicle on a level spot and turn-
ing off the engine.

LU-9

LU-28

Exhaust system

Make sure there are no loose supports, cracks or holes. If the sound of the exhaust
seems unusual or there is a smell of exhaust fumes, immediately locate the trouble
and correct it.

MA-35

Underbody

The underbody is frequently exposed to corrosive substances such as those used on
icy roads or to control dust. It is very important to remove these substances, otherwise
rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the
end of winter, the underbody should be thoroughly flushed with plain water, being
careful to clean those areas where mud and dirt can easily accumulate.

—

Fluid leaks

Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has
been parked for a while. Water dripping from the air conditioner after use is normal. If
you should notice any leaks or gasoline fumes are evident, check for the cause and
correct it immediately.

—

PERIODIC MAINTENANCE

MA-7

< PERIODIC MAINTENANCE >

PERIODIC MAINTENANCE

Introduction of Periodic Maintenance

INFOID:0000000012200177

The following tables show the normal maintenance schedule. Depending upon weather and atmospheric con-

ditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent mainte-

nance may be required.

Periodic maintenance beyond the last period shown on the tables requires similar maintenance.

Emission Control System Maintenance

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Perform at number of miles, kilometers
or months, whichever comes first.

Miles x 1,000

(km x 1,000)

Months

(8)

(16)

(24)

(32)

(40)

(48)

(56)

(64)

(72)

Drive belt

NOTE (1)

Air cleaner filter

NOTE (2)

EVAP vapor lines

Fuel lines

Fuel filter

NOTE (3)

Engine coolant*

NOTE (4)(5)

Engine oil

Engine oil filter (Use genuine NISSAN
engine oil filter or equivalent)

Spark plugs (Iridium/platinum-tipped
type)

NOTE (6)

Replace every 105,000 miles (168,000 km)

Intake and exhaust valve clearance*

NOTE (7)

MAINTENANCE OPERATION

MAINTENANCE INTERVAL

Perform at number of miles, kilometers
or months, whichever comes first.

Miles x 1,000

(km x 1,000)

Months

(80)

(88)

(96)

(104)

(112)

(120)

(128)

(136)

102

(144)

108

Drive belt

NOTE (1)

Air cleaner filter

NOTE (2)

EVAP vapor lines

Fuel lines

Fuel filter

NOTE (3)

Engine coolant*

NOTE (4)(5)

Engine oil

Engine oil filter (Use genuine NISSAN
engine oil filter or equivalent)

Spark plugs (Iridium/platinum-tipped
type)

NOTE (6)

Replace every 105,000 miles (168,000 km)

Intake and exhaust valve clearance*

NOTE (7)
