LU-10
< PERIODIC MAINTENANCE >
[MR FOR NISMO RS MODELS]
ENGINE OIL
2. Disconnect harness connector at oil pressure sensor (1), and
remove oil pressure sensor using a deep socket (commercial
service tool).
CAUTION:
Never drop or shock oil pressure sensor.
3. Install oil pressure gauge [SST: ST25051001 (J-25695-1)] (A)
and hose [SST: ST25052000 (J-25695-2)] (B).
4. Start engine and warm it up to normal operating temperature.
5. Check oil pressure with engine running under no-load.
NOTE:
When engine oil temperature is low, engine oil pressure becomes high.
If difference is extreme, check oil passage and oil pump for oil leakage.
6. After the inspections, install oil pressure sensor as follows:
a. Remove old liquid gasket adhering to oil pressure sensor and engine.
b. Apply liquid gasket and tighten oil pressure sensor to specification.
Use Genuine RTV Silicon Sealant or equivalent.
c.
Check engine oil level.
d. After warming up engine, check that there is no leakage of engine oil with running engine.
Draining
INFOID:0000000012197473
WARNING:
• Be careful not to get burned, as engine oil may be hot.
• Prolonged and repeated contact with used engine oil may cause skin cancer. Try to avoid direct skin
contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand cleaner as
soon as possible.
1. Warm up the engine, and check for engine oil leakage from engine components. Refer to
2. Stop the engine and wait for 10 minutes.
3. Loosen oil filler cap.
4. Remove drain plug and then drain engine oil.
2
: Starter motor
: Engine front
JPBIA4449ZZ
JPBIA0074ZZ
Engine oil pressure
: Refer to
Tightening torque
: Refer to
.
