DIAGNOSIS SYSTEM (BCM) INL-15 < SYSTEM DESCRIPTION > C D E F G H I J K M A B INL N O P ACTIVE TEST CDL UNLOCK SW Indicated [On/Off] condition of unlock signal from door lock unlock switch TRNK/HAT MNTR NOTE: KEY CYL LK-SW Indicated [On/Off] condition of lock signal from door key cylinder KEY CYL UN-SW Indicated [On/Off] condition of unlock signal from door key cylinder RKE-LOCK Indicates [On/Off] condition of LOCK signal from Intelligent Key RKE-UNLOCK Indicates [On/Off] condition of UNLOCK signal from Intelligent Key Monitor item [Unit] Description Test item Operation Description BATTERY SAVER Off Cuts the interior room lamp power supply. On Outputs the interior room lamp power supply. |
