FL-10 < REMOVAL AND INSTALLATION > [MR16DDT ] FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY 2WD : Inspection INFOID:0000000012197586 INSPECTION AFTER INSTALLATION Use the following procedure to check for fuel leakage. sure to fuel piping. 2. Start engine and let it idle and check there are no fuel leakage at the fuel system connections. AWD INFOID:0000000012197587 REMOVAL DISASSEMBLY 1. Lock ring 2. Fuel level sensor unit, fuel filter and fuel pump 3. O-ring 4. Sub fuel level sensor assembly A. Right side B. Left side : Always replace after every disassembly. JPBIA4325GB JPBIA4470ZZ |
