ECM

EC-685

< ECU DIAGNOSIS INFORMATION >

[MR EXCEPT FOR NISMO RS MODELS]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

*1: Accelerator pedal position sensor 2 signal and throttle position sensor 2 signal are converted by ECM internally. Thus, they differ
from ECM terminals voltage signal.
*2: Before measuring the terminal voltage, confirm that the battery is fully charged. Refer to

PG-97, "How to Handle Battery"

.

TERMINAL LAYOUT

PHYSICAL VALUES

NOTE:

• ECM is located in the engine room left side near battery.

• Specification data are reference values and are measured between each terminal and ground.

• Pulse signal is measured by CONSULT.

SYSTEM 1 DIAG-
NOSIS A B1

DTC P219A self-diagnosis is incomplete.

INCMP

DTC P219A self-diagnosis is complete.

CMPLT

SYSTEM 1 DIAG-
NOSIS B B1

DTC P219A self-diagnosis is on standby.

ABSENT

DTC P219A self-diagnosis is under diagnosis.

PRSENT

Monitor Item

Condition

Values/Status

JSBIA4335ZZ

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output

1

(GR)

10

(B)

Fuel injector No. 1, 4 (HI)

Output

[Engine is running]
• Warm-up condition
• Idle speed

NOTE:
The pulse cycle changes depending
on rpm at idle

2.7 V

2

(SB)

10

(B)

Fuel injector No. 2 (LO)

Output

[Engine is running]
• Warm-up condition
• Idle speed

NOTE:
The pulse cycle changes depending
on rpm at idle

2.7 V

3

(W)

10

(B)

Fuel injector No. 3 (LO)

Output

[Engine is running]
• Engine speed is 2,000 rpm

3 V

JPBIA4718ZZ

JPBIA4720ZZ

JPBIA4721ZZ

EC-686

< ECU DIAGNOSIS INFORMATION >

[MR EXCEPT FOR NISMO RS MODELS]

ECM

4

(G)

10

(B)

Fuel injector driver power
supply 1

Input

[Engine is running]
• Warm-up condition
• Idle speed

BATTERY VOLTAGE

(11 - 14 V)

5

(BR)

10

(B)

Fuel injector driver power
supply 2

Input

[Engine is running]
• Warm-up condition
• Idle speed

BATTERY VOLTAGE

(11 - 14 V)

6

(R)

10

(B)

Fuel injector No. 4 (LO)

Output

[Engine is running]
• Engine speed is 2,000 rpm

3 V

7

(LG)

10

(B)

Fuel injector No. 2, 3 (HI)

Output

[Engine is running]
• Engine speed is 2,000 rpm

3 V

8

(BR)

10

(B)

Fuel injector No. 1 (LO)

Output

[Engine is running]
• Warm-up condition
• Idle speed

NOTE:
The pulse cycle changes depending
on rpm at idle

2.7 V

9

(GR)

ECM ground

10

(B)

ECM ground

11

(W)

13

(V)

Turbocharger boost sen-
sor

Input

[Engine is running]
• Warm-up condition
• Idle speed

1.9 V

[Engine is running]
• Warm-up condition
• Engine speed is 2,000 rpm

2.0 V

12

(P)

13

(V)

Refrigerant pressure sen-
sor

Input

[Engine is running]
• Warm-up condition
• Both A/C switch and blower fan mo-

tor switch: ON (Compressor oper-
ates)

1.0 - 4.0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output

JPBIA4721ZZ

JPBIA4719ZZ

JPBIA4720ZZ

ECM

EC-687

< ECU DIAGNOSIS INFORMATION >

[MR EXCEPT FOR NISMO RS MODELS]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

13

(V)

Sensor ground
• G sensor
• Refrigerant pressure

sensor

• Fuel rail pressure sen-

sor

• Engine oil pressure

sensor

• Intake air temperature

sensor 2

• Turbocharger boost

sensor

14

(—)

Shield

15

(W)

20

(B)

Knock sensor

Input

[Engine is running]
• Idle speed

2.5 V

20

(B)

Sensor ground
(Knock sensor)

22

(Y)

45

(P)

Engine oil temperature
sensor

Input

[Engine is running]

0 - 4.8 V

Output voltage varies with engine

oil temperature.

23

(G)

13

(V)

Engine oil pressure sen-
sor

Input

[Engine is running]
• Warm-up condition
• Idle speed

1.3 V

[Engine is running]
• Warm-up condition
• Engine speed is 2,000 rpm

2.7 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output

JPBIA3359ZZ

JPBIA3360ZZ

EC-688

< ECU DIAGNOSIS INFORMATION >

[MR EXCEPT FOR NISMO RS MODELS]

ECM

24

(G)

43

(BR)

EGR pressure sensor

Input

[Engine is running]
• Warm-up condition
• Idle speed

1.3 V

[Engine is running]
• Warm-up condition
• Engine speed is 2,000 rpm

2.7 V

[Engine is running]
• Warm-up condition
• Engine speed is 4,000 rpm

1 V

25

(GR)

13

(V)

Fuel rail pressure sensor

Input

[Engine is running]
• Warm-up condition
• Idle speed

1.14 - 1.46 V

[Engine is running]
• Warm-up condition
• Revving engine from idle to 4,000

rpm quickly

1.3 - 2.9 V

26

(R)

42

(W)

Sensor power supply
(Mass air flow sensor)

[Ignition switch: ON]

5 V

27

(G)

44

(W)

Sensor power supply
(Crankshaft position sen-
sor)

[Ignition switch: ON]

5 V

29

(L)

13

(V)

Sensor power supply
• G sensor
• Refrigerant pressure

sensor

• Fuel rail pressure sen-

sor

• Engine oil pressure

sensor

• Turbocharger boost

sensor

[Ignition switch: ON]

5 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output

JPBIA3359ZZ

JPBIA3360ZZ

JSBIA5611ZZ
