Nissan Juke F15. Manual - part 141

YAW RATE/SIDE/DECEL G SENSOR

BRC-155

< REMOVAL AND INSTALLATION >

[WITH VDC]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

YAW RATE/SIDE/DECEL G SENSOR

Exploded View

INFOID:0000000012199761

Removal and Installation

INFOID:0000000012199762

REMOVAL

CAUTION:

Never drop or strike yaw rate/side/decel G sensor, because it has little endurance to impact. Never use

a pneumatic tool.
1. Remove front seat (right side). Refer to

SE-21, "Removal and Installation"

.

2. Remove floor carpet. Refer to

INT-24, "Removal and Installation"

.

3. Disconnect yaw rate/side/decel G sensor harness connector.
4. Remove yaw rate/side/decel G sensor.

INSTALLATION

Note the following, and install in the reverse order of removal.

• Never drop or strike yaw rate/transverse/decel G sensor, because it has little endurance to impact. Never

use a power tool.

1.

Yaw rate/side/decel G sensor

2.

Yaw rate/side/decel G sensor har-
ness connector

3.

Bracket

: Vehicle front

: N·m (kg-m, in-lb)

JSFIA0544GB

BRC-156

< REMOVAL AND INSTALLATION >

[WITH VDC]

STEERING ANGLE SENSOR

STEERING ANGLE SENSOR

Removal and Installation

INFOID:0000000012199763

REMOVAL

1. Remove spiral cable assembly. Refer to

SR-15, "Removal and Installation"

.

2. Remove steering angle sensor.

INSTALLATION

Note the following, and install in the reverse order of removal.

• Perform steering angle sensor neutral position adjustment when steering angle sensor is removed and

installed, or replaced. Refer to

BRC-63, "Work Procedure"

.

VDC OFF SWITCH

BRC-157

< REMOVAL AND INSTALLATION >

[WITH VDC]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

VDC OFF SWITCH

Removal and Installation

INFOID:0000000012199764

REMOVAL

1. Remove lower instrument panel. Refer to

IP-13, "Removal and Installation"

.

2. Remove VDC OFF switch.

INSTALLATION

Installation is the reverse order of removal.

BRC-158

< REMOVAL AND INSTALLATION >

[WITH VDC]

VDC OFF SWITCH
