STC-36

< REMOVAL AND INSTALLATION >

EPS CONTROL UNIT

REMOVAL AND INSTALLATION

EPS CONTROL UNIT

Removal and Installation

INFOID:0000000012199954

CAUTION:

Disconnect battery negative terminal before starting operations.

Never remove EPS control unit from steering column assembly. When replacing EPS control unit, replace

steering column assembly. Refer to

ST-11, "Removal and Installation"

.

STR-1

ENGINE

C

D

E

F

G

H

I

J

K

L

M

SECTION

STR

A

STR

N

O

P

CONTENTS

STARTING SYSTEM

PRECAUTION ...............................................

2

PRECAUTIONS ...................................................

2

Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .................................................................
..

2

Precaution for Procedure without Cowl Top Cover

......

2

Precautions For Xenon Headlamp Service  ...............

2

Precautions for Removing Battery Terminal  .............

3

Precautions When Battery Is Discharged  .................

3

PREPARATION ............................................

4

PREPARATION ...................................................

4

Special Service Tools ................................................

4

Commercial Service Tools  ........................................

4

SYSTEM DESCRIPTION  ..............................

5

COMPONENT PARTS  ........................................

5

Component Parts Location ........................................

5

Component Description .............................................

5

SYSTEM ..............................................................

6

System Diagram ........................................................

6

System Description  ...................................................

6

WIRING DIAGRAM .......................................

7

STARTING SYSTEM ...........................................

7

Wiring Diagram (CVT Models)  ..................................

7

Wiring Diagram (M/T Models)  .................................

13

BASIC INSPECTION  ...................................

18

DIAGNOSIS AND REPAIR WORK FLOW  .......

18

Work Flow (With GR8-1200 NI) ...............................

18

Work Flow (Without GR8-1200 NI) ..........................

21

DTC/CIRCUIT DIAGNOSIS  .........................

23

B TERMINAL CIRCUIT  .....................................

23

Description ...............................................................

23

Diagnosis Procedure  ...............................................

23

S TERMINAL CIRCUIT  .....................................

25

Description ...............................................................

25

Diagnosis Procedure  ...............................................

25

SYMPTOM DIAGNOSIS  ..............................

26

STARTING SYSTEM .........................................

26

Symptom Table  .......................................................

26

REMOVAL AND INSTALLATION ...............

27

STARTER MOTOR  ...........................................

27

MR16DDT ...................................................................

27

MR16DDT : Exploded View .....................................

27

MR16DDT : Removal and Installation .....................

28

SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................

30

SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................

30

Starter Motor ............................................................

30

STR-2

< PRECAUTION >

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000012201571

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS

system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front

air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the “SRS AIR BAG” and “SEAT BELT” of this

Service Manual.

WARNING:

Always observe the following items for preventing accidental activation.

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision that would result in air bag inflation, it is recommended that all maintenance

and repair be performed by an authorized NISSAN/INFINITI dealer.

• Improper repair, including incorrect removal and installation of the SRS, can lead to personal injury

caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module,

see “SRS AIR BAG”.

• Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-

vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness

connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

Always observe the following items for preventing accidental activation.

• When working near the Air Bag Diagnosis Sensor Unit or other Air Bag System sensors with the

ignition ON or engine running, never use air or electric power tools or strike near the sensor(s) with

a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing

serious injury.

• When using air or electric power tools or hammers, always switch the ignition OFF, disconnect the

battery or batteries, and wait at least 3 minutes before performing any service.

Precaution for Procedure without Cowl Top Cover

INFOID:0000000012965343

When performing the procedure after removing cowl top cover, cover

the lower end of windshield with urethane, etc to prevent damage to

windshield.

Precautions For Xenon Headlamp Service

INFOID:0000000012965344

WARNING:

Comply with the following warnings to prevent any serious accident.

• Disconnect the battery cable (negative terminal) or the power supply fuse before installing, remov-

ing, or touching the xenon headlamp (bulb included). The xenon headlamp contains high-voltage

generated parts.

• Never work with wet hands.

• Check the xenon headlamp ON-OFF status after assembling it to the vehicle. Never turn the xenon

headlamp ON in other conditions. Connect the power supply to the vehicle-side connector.

PIIB3706J

PRECAUTIONS

STR-3

< PRECAUTION >

C

D

E

F

G

H

I

J

K

L

M

A

STR

N

P

O

(Turning it ON outside the lamp case may cause fire or visual impairments.)

• Never touch the bulb glass immediately after turning it OFF. It is extremely hot.

CAUTION:

Comply with the following cautions to prevent any error and malfunction.

• Install the xenon bulb securely. (Insufficient bulb socket installation may melt the bulb, the connec-

tor, the housing, etc. by high-voltage leakage or corona discharge.)

• Never perform HID circuit inspection with a tester.

• Never touch the xenon bulb glass with hands. Never put oil and grease on it.

• Dispose of the used xenon bulb after packing it in thick vinyl without breaking it.

• Never wipe out dirt and contamination with organic solvent (thinner, gasoline, etc.).

Precautions for Removing Battery Terminal

INFOID:0000000012965342

When disconnecting the battery terminal, pay attention to the following.

• Always use a 12V battery as power source.

• Never disconnect battery terminal while engine is running.

• When removing the 12V battery terminal, turn OFF the ignition
