BR-40 < REMOVAL AND INSTALLATION > BRAKE MASTER CYLINDER • Temporarily tighten the brake tube flare nut to the master cylinder assembly by hand. Then tighten it to the specified torque with a crowfoot and torque wrench (A). Refer to . • Perform the air bleeding. Refer to BR-13, "Bleeding Brake System" • Perform inspection after installation. Refer to Disassembly and Assembly INFOID:0000000012200289 DISASSEMBLY CAUTION: • Never disassemble the master cylinder. • Remove the reservoir tank only when necessary. CAUTION: • Always set copper plates or cloth between vise grips when fixing the master cylinder to a vise. • Never overtighten the vise. 2. Remove the reservoir tank mounting pin with a pin punch (A) [4 mm (0.157 in)]. 3. Remove the reservoir tank and grommet from the master cylin- der. ASSEMBLY CAUTION: • Never use mineral oils such as kerosene or gasoline and rubber grease during the cleaning and assembly process. • Never allow foreign matter (e.g. dust) and oils other than brake fluid to enter the reservoir tank. • Never drop the when installing. The parts must not be reused if they are dropped. CAUTION: Never reuse the grommets. 2. Install the reservoir tank to the master cylinder. CAUTION: • Place the reservoir tank with the chamfered pin hole ( ) facing up. • Always set copper plates or cloth between vise grips when fixing the master cylinder to a vise. • Never overtighten the vise. JPFIA0844ZZ JPFIA0825ZZ JPFIA0826ZZ |
