Nissan Tiida C11. Manual - part 694

EM-128

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR16DE]

SERVICE DATA AND SPECIFICATIONS (SDS)

AVAILABLE PISTON

Unit: mm (in)

PISTON RING

Unit: mm (in)

PISTON PIN

Cylinder bore inner diameter

Standard

78.000 - 78.015 (3.0709 - 3.0715)

Out-of-round

Limit

0.015 (0.0006)

Taper

0.010 (0.0004)

Cylinder block main bearing housing inner diameter grade

Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W

51.997 - 51.998 (2.0471 - 2.0472)
51.998 - 51.999 (2.0472 - 2.0472)
51.999 - 52.000 (2.0472 - 2.0472)
52.000 - 52.001 (2.0472 - 2.0473)
52.001 - 52.002 (2.0473 - 2.0473)
52.002 - 52.003 (2.0473 - 2.0474)
52.003 - 52.004 (2.0474 - 2.0474)
52.004 - 52.005 (2.0474 - 2.0474)
52.005 - 52.006 (2.0474 - 2.0475)
52.006 - 52.007 (2.0475 - 2.0475)
52.007 - 52.008 (2.0475 - 2.0476)
52.008 - 52.009 (2.0476 - 2.0476)
52.009 - 52.010 (2.0476 - 2.0476)

52.010 - 52.011 (2.0476 - 2.0477)
52.011 - 52.012 (2.0477 - 2.0477)

52.012 - 52.013 (2.0477 - 2.0478)
52.013 - 52.014 (2.0478 - 2.0478)
52.014 - 52.015 (2.0478 - 2.0478)
52.015 - 52.016 (2.0478 - 2.0479)
52.016 - 52.017 (2.0479 - 2.0479)

Difference in inner diameter between cylinders

Standard

Less than 0.015 (0.0006)

Item

Standard

Limit

Piston skirt diameter “A”

77.965 - 77.980 (3.0695 - 3.0701)

—

Measure point “H”

37.1 (1.461)

—

Piston pin hole diameter

19.006 - 19.012 (0.7483 - 0.7485)

—

Piston to cylinder bore clearance

0.020 - 0.050 (0.0008 - 0.0020)

0.09 (0.0035)

PBIC0188E

Items

Standard

Limit

Piston ring side clearance

Top

0.040 - 0.080 (0.0016 - 0.0031)

0.11 (0.0043)

2nd

0.030 - 0.070 (0.0012 - 0.0028)

0.10 (0.0039)

Oil (rail ring)

0.045 - 0.125 (0.0018 - 0.0049)

—

Piston ring end gap

Top

0.20- 0.30 (0.0079 - 0.0118)

0.50 (0.0197)

2nd

0.35 - 0.50 (0.0138 - 0.0197)

0.66 (0.0260)

Oil (rail ring)

0.20 - 0.60 (0.0079 - 0.0236)

0.92 (0.0362)

SERVICE DATA AND SPECIFICATIONS (SDS)

EM-129

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR16DE]

Unit: mm (in)

CONNECTING ROD

Unit: mm (in)

CRANKSHAFT

Unit: mm (in)

Piston pin outer diameter

18.996 - 19.002 (0.7479 - 0.7481)

Piston to piston pin oil clearance

Standard

0.008 - 0.012 (0.0003 - 0.0005)

Center distance

129.84 - 129.94 (5.11 - 5.12)

Bend [per 100 (3.94)]

Limit

0.15 (0.0059)

Torsion [per 100 (3.94)]

Limit

0.30 (0.0118)

Connecting rod small end clearance

Standard

–0.018 - –0.044 (–0.0007 - –0.0017)

Connecting rod small end inner diameter

Standard

18.958 - 18.978 (0.7464 - 0.7472)

Connecting rod side clearance

Standard

0.200 - 0.352 (0.0079 - 0.0139)

Connecting rod big end diameter

Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N

43.000 - 43.001 (1.6929 - 1.6929)
43.001 - 43.002 (1.6929 - 1.6930)
43.002 - 43.003 (1.6930 - 1.6930)
43.003 - 43.004 (1 6930 - 1.6931)
43.004 - 43.005 (1.6931 - 1.6931)
43.005 - 43.006 (1.6931 - 1.6931)
43.006 - 43.007 (1.6931 - 1.6932)
43.007 - 43.008 (1.6932 - 1.6932)
43.008 - 43.009 (1.6932 - 1.6933)
43.009 - 43.010 (1.6933 - 1.6933)

43.010 - 43.011 (1.6933 - 1.6933)
43.011 - 43.012 (1.6933 - 1.6934)

43.012 - 43.013 (1.6934 - 1.6934)

Center distance “r”

41.68 - 41.76 (1.6409 - 1.6441)

Out-of-round

Limit

0.003 (0.0001)

Taper

Limit

0.004 (0.0002)

Runout [TIR*]

Limit

0.10 (0.0039)

Crankshaft end play

Standard

0.098 - 0.260 (0.0039 - 0.0102)

Limit

0.35 (0.0138)

SEM645

PBIC3459J

EM-130

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR16DE]

SERVICE DATA AND SPECIFICATIONS (SDS)

*: Total indicator reading

Connecting Rod Bearing

INFOID:0000000001381446

CONNECTING ROD BEARING GRADE TABLE

Unit: mm (in)

Crankshaft pin journal diameter grade. “Dp”

39.971 - 39.970 (1.5737 - 1.5736)
39.970 - 39.969 (1.5736 - 1.5736)
39.969 - 39.968 (1.5736 - 1.5735)
39.968 - 39.967 (1.5735 - 1.5735)
39.967 - 39.966 (1.5735 - 1.5735)
39.966 - 39.965 (1.5735 - 1.5734)
39.965 - 39.964 (1.5734 - 1.5734)
39.964 - 39.963 (1.5734 - 1.5733)
39.963 - 39.962 (1.5733 - 1.5733)
39.962 - 39.961 (1.5733 - 1.5733)
39.961 - 39.960 (1.5733 - 1.5732)
39.960 - 39.959 (1.5732 - 1.5732)
39.959 - 39.958 (1.5732 - 1.5731)
39.958 - 39.957 (1.5731 - 1.5731)
39.957 - 39.956 (1.5731 - 1.5731)
39.956 - 39.955 (1.5731 - 1.5730)
39.955 - 39.954 (1.5730 - 1.5730)
39.954 - 39.953 (1.5730 - 1.5729)

Crankshaft main journal diameter grade. “Dm”

47.979 - 47.978 (1.8889 - 1.8889)
47.978 - 47.977 (1.8889 - 1.8889)
47.977 - 47.976 (1.8889 - 1.8888)
47.976 - 47.975 (1.8888 - 1.8888)
47.975 - 47.974 (1.8888 - 1.8887)
47.974 - 47.973 (1.8887 - 1.8887)
47.973 - 47.972 (1.8887 - 1.8887)
47.972 - 47.971 (1.8887 - 1.8886)
47.971 - 47.970 (1.8886 - 1.8886)
47.970 - 47.969 (1.8886 - 1.8885)
47.969 - 47.968 (1.8885 - 1.8885)
47.968 - 47.967 (1.8885 - 1.8885)
47.967 - 47.966 (1.8885 - 1.8884)
47.966 - 47.965 (1.8884 - 1.8884)
47.995 - 47.964 (1.8884 - 1.8883)
47.994 - 47.963 (1.8883 - 1.8883)
47.963 - 47.962 (1.8883 - 1.8883)
47.962 - 47.961 (1.8883 - 1.8882)
47.961 - 47.960 (1.8882 - 1.8882)
47.960 - 47.959 (1.8882 - 1.8881)

Grade number

Thickness

Identification color

Remarks

1.498 - 1.501 (0.0590 - 0.0591)

Black

Grade and color are the same
for upper and lower bearings.

1.501 - 1.504 (0.0591 - 0.0592)

Brown

1.504 - 1.507 (0.0592 - 0.0593)

Green

1.507 - 1.510 (0.0593 - 0.0594)

Yellow

1.510 - 1.513 (0.0594 - 0.0596)

Blue

UPR

1.498 - 1.501 (0.0590 - 0.0591)

Black

Grade and color are different
for upper and lower bearings.

LWR

1.501 - 1.504 (0.0591 - 0.0592)

Brown

UPR

1.501 - 1.504 (0.0591 - 0.0592)

Brown

LWR

1.504 - 1.507 (0.0592 - 0.0593)

Green

UPR

1.504 - 1.507 (0.0592 - 0.0593)

Green

LWR

1.507 - 1.510 (0.0593 - 0.0594)

Yellow

UPR

1.507 - 1.510 (0.0593 - 0.0594)

Yellow

LWR

1.510 - 1.513 (0.0594 - 0.0596)

Blue

SERVICE DATA AND SPECIFICATIONS (SDS)

EM-131

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR16DE]

UNDERSIZE TABLE

Unit: mm (in)

CONNECTING ROD BEARING OIL CLEARANCE

Unit: mm (in)

Main Bearing

INFOID:0000000001381447

MAIN BEARING GRADE TABLE

Unit: mm (in)

UNDERSIZE TABLE

Unit: mm (in)

MAIN BEARING OIL CLEARANCE

Unit: mm (in)

Item

Thickness

Crankshaft pin journal diameter

US 0.25 (0.0098)

1.627 - 1.635 (0.0641 - 0.0644)

Grind so that bearing clearance is the specified value.

Connecting rod bearing oil clearance

Standard

0.029 - 0.039 (0.0011 - 0.0015)

Limit

0.10 (0.0039)

Grade number

Thickness

Identification color

Remarks

1.996 - 1.999 (0.0786 - 0.0787)

Black

Grade and color are the same
for upper and lower bearings.

1.999 - 2.002 (0.0787 - 0.0788)

Brown

2.002 - 2.005 (0.0788 - 0.0789)

Green

2.005 - 2.008 (0.0789 - 0.0791)

Yellow

2.008 - 2.011 (0.0791 - 0.0792)

Blue

2.011 - 2.014 (0.0792 - 0.0793)

Pink

UPR

1.996 - 1.999 (0.0786 - 0.0787)

Black

Grade and color are different
for upper and lower bearings.

LWR

1.999 - 2.002 (0.0787 - 0.0788)

Brown

UPR

1.999 - 2.002 (0.0787 - 0.0788)

Brown

LWR

2.002 - 2.005 (0.0788 - 0.0789)

Green

UPR

2.002 - 2.005 (0.0788 - 0.0789)

Green

LWR

2.005 - 2.008 (0.0789 - 0.0791)

Yellow

UPR

2.005 - 2.008 (0.0789 - 0.0791)

Yellow

LWR

2.008 - 2.011 (0.0791 - 0.0792)

Blue

UPR

2.008 - 2.011 (0.0791 - 0.0792)

Blue

LWR

2.011 - 2.014 (0.0792 - 0.0793)

Pink

SEM685D

Items

Thickness

Main journal diameter

0.25 (0.0098)

2.126 - 2.134 (0.0837 - 0.0840)

Grind so that bearing clearance is the specified value.

Main bearing oil clearance

Standard

0.024 - 0.034 (0.0009 - 0.0013)
