EM-124

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR16DE]

SERVICE DATA AND SPECIFICATIONS (SDS)

*: Total indicator reading

VALVE LIFTER

Unit: mm (in)

VALVE CLEARANCE

Unit: mm (in)

*: Approximately 80

°

C (176

°

F)

AVAILABLE VALVE LIFTER

Camshaft end play

0.075 - 0.153 (0.0030 - 0.0060)

0.2 (0.008)

Camshaft sprocket runout [TIR*]

0.15 (0.0059)

Items

Standard

Limit

Items

Standard

Valve lifter outer diameter

29.977 - 29.987 (1.1802 - 1.1806)

Valve lifter hole diameter

30.000 - 30.021 (1.1811 - 1.1819)

Valve lifter clearance

0.013 - 0.044 (0.0005 - 0.0017)

Items

Cold

Hot* (reference data)

Intake

0.26 - 0.34 (0.010 - 0.013)

0.304 - 0.416 (0.012 - 0.016)

Exhaust

0.29 - 0.37 (0.011 - 0.015)

0.308 - 0.432 (0.012 - 0.017)

Thickness

mm (in)

Identification mark

3.00 (0.1181)

300

3.02 (0.1189)

302

3.04 (0.1197)

304

3.06 (0.1205)

306

3.08 (0.1213)

308

3.10 (0.1220)

310

3.12 (0.1228)

312

3.14 (0.1236)

314

3.16 (0.1244)

316

3.18 (0.1252)

318

3.20 (0.1260)

320

3.22 (0.1268)

322

3.24 (0.1276)

324

3.26 (0.1283)

326

3.28 (0.1291)

328

3.30 (0.1299)

330

3.32 (0.1307)

332

KBIA0119E

SERVICE DATA AND SPECIFICATIONS (SDS)

EM-125

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR16DE]

C

D

E

F

G

H

I

J

K

L

M

A

EM

N

P

O

Cylinder Head

INFOID:0000000001381444

CYLINDER HEAD

Unit: mm (in)

VALVE DIMENSIONS

Unit: mm (in)

3.34 (0.1315)

334

3.36 (0.1323)

336

3.38 (0.1331)

338

3.40 (0.1339)

340

3.42 (0.1346)

342

3.44 (0.1354)

344

3.46 (0.1362)

346

3.48 (0.1370)

348

3.50 (0.1378)

350

Thickness

mm (in)

Identification mark

Items

Standard

Limit

Head surface distortion

0.1 (0.004)

Normal cylinder head height “H”

125.0 (4.92)

PBIC0924E

Valve head diameter “D”

Intake

31.0 - 31.3 (1.220 - 1.232)

Exhaust

25.3 - 25.6 (0.996 - 1.008)

Valve length “a”

Intake

101.65 (4.002)

Exhaust

102.46 (4.034)

“b”

Intake

1.0 (0.039)

Exhaust

PBIC3878E

EM-126

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR16DE]

SERVICE DATA AND SPECIFICATIONS (SDS)

VALVE GUIDE

Unit: mm (in)

VALVE SEAT

Unit: mm (in)

“c”

Intake

2.1 - 2.8 (0.083 - 0.110)

Exhaust

2.3 - 3.0 (0.091 - 0.118)

“c

Intake

3.0 (0.118)

Exhaust

Valve stem diameter “d ”

Intake

4.965 - 4.980 (0.1955 - 0.1961)

Exhaust

4.955 - 4.970 (0.1951 - 0.1957)

Valve seat angle “

α

Intake

45

°

15

 - 45

°

45

Exhaust

Items

Standard

Oversize (service) [0.2 (0.008)]

Valve guide

Outer diameter

9.023 - 9.034 (0.3552 - 0.3557)

9.223 - 9.234 (0.3631 - 0.3635)

Inner diameter (Finished size)

5.000 - 5.018 (0.1969 - 0.1976)

Cylinder head valve guide hole diameter

8.975 - 8.996 (0.3533 - 0.3542)

9.175 - 9.196 (0.3612 - 0.3620)

Interference fit of valve guide

0.027 - 0.059 (0.0011 - 0.0023)

Items

Standard

Limit

Valve guide clearance

Intake

0.020 - 0.053 (0.0008 - 0.0021)

0.1 (0.004)

Exhaust

0.030 - 0.063 (0.0012 - 0.0025)

Projection length “H”

11.4 - 11.8 (0.449 - 0.465)

PBIC2187E

Items

Standard

Oversize (service) [0.5 (0.02)]

Cylinder head seat recess diameter “D”

Intake

31.400 - 31.416 (1.2362 - 1.2368)

31.900 - 31.916 (1.2559 - 1.2565)

Exhaust

25.900 - 25.916 (1.0197 - 1.0203)

26.400 - 26.416 (1.0394 - 1.0400)

Valve seat outer diameter “d”

Intake

31.497 - 31.513 (1.2400 - 1.2407)

31.997 - 32.013 (1.2597 - 1.2604)

Exhaust

25.997 - 26.013 (1.0235 - 1.0241)

26.497 - 26.513 (1.0432 - 1.0438)

PBIC2745E

SERVICE DATA AND SPECIFICATIONS (SDS)

EM-127

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR16DE]

C

D

E

F

G

H

I

J

K

L

M

A

EM

N

P

O

*

1

  : Diameter made by intersection point of conic angles

α

1 and

α

*

2

  : Diameter made by intersection point of conic angles

α

2 and

α

*

3

  : Machining data

VALVE SPRING

Cylinder Block

INFOID:0000000001381445

CYLINDER BLOCK

Unit: mm (in)

Valve seat interference fit

Intake

0.081 - 0.113 (0.0032 - 0.0044)

Exhaust

Diameter “d1”*

1

Intake

29.0 (1.142)

Exhaust

23.0 (0.906)

Diameter “d2”*

2

Intake

30.6 - 30.8 (1.205 - 1.213)

Exhaust

24.9 - 25.1 (0.980 - 0.988)

Angle “

α

1”

Intake

60

°

Exhaust

45

°

Angle “

α

2”

Intake

89

°

45

 - 90

°

15

Exhaust

Angle “

α

3”

Intake

120

°

Exhaust

Contacting width “W”*

3

Intake

1.05 - 1.35 (0.0413 - 0.0531)

Exhaust

1.25 - 1.55 (0.0492 - 0.0610)

Height “h”

Intake

6.0 (0.236)

5.45 (0.215)

Exhaust

5.43 (0.214)

Depth “H”

6.0 (0.236)

Items

Standard

Free height

42.26 mm (1.6638 in)

Installation height

32.40 mm (1.2756 in)

Installation load

136 - 154 N (13.9 - 15.7 kg, 31 - 35 lb)

Height during valve open

23.96 mm (0.9433 in)

Load with valve open

262 - 296 N (26.7 - 30.2 kg, 59 - 67 lb)

Items

Limit

Valve spring squareness

1.8 mm (0.071 in)

Cylinder block top surface distortion

Limit

0.1 (0.004)

PBIC3924E
