EC-1250

< ECU DIAGNOSIS >

[K9K]

ECM

ALBIA0433GB

ECM

EC-1251

< ECU DIAGNOSIS >

[K9K]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

ALBIA0434GB

EC-1252

< ECU DIAGNOSIS >

[K9K]

ECM

DTC Index

INFOID:0000000001162697

X: Applicable —: Not applicable

ALBIA0435GB

DTC*

Items

(CONSULT-III screen item)

Trip

MI lighting up

Reference page

Yellow

Red

P0001

FUEL SYSTEM

3

–

×

EC-1109

P0002

FUEL SYSTEM

3

–

–

EC-1111

ECM

EC-1253

< ECU DIAGNOSIS >

[K9K]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

P0016

COHERENCE CMSFT/SN

3

–

–

EC-1113

P0045

TURBO ACT CIRC

3

–

×

EC-1116

P0069

PRESSURE COHERENCE

3

–

×

EC-1118

P0087

LOW FUEL PRESS

3

–

–

EC-1120

P0090

FUEL SYSTEM

3

–

×

EC-1122

P0100

AIR FLOW SEN CIRC

3

–

–

EC-1124

P0101

AIR FLOW SEN CIRC

3

–

–

EC-1127

P0110

IN-AIR TMP SEN CIR

3

–

–

EC-1130

P0115

WATER TMP SEN

1 or 3

–

–

EC-1132

P0120

TP SEN CIRC

3

–

–

EC-1134

P0180

FUEL TEMP SEN CIRC

1 or 3

–

–

EC-1136

P0190

RAIL/PRESS SEN CIR

3

–

×

EC-1138

P0200

INJECTOR CTRL CIRC

3

–

×

EC-1140

P0201

CYL 1 INJ CTRL CIR

3

×

×

EC-1142

P0202

CYL 2 INJ CTRL CIR

3

×

×

EC-1142

P0203

CYL 3 INJ CTRL CIR

3

×

×

EC-1142

P0204

CYL 4 INJ CTRL CIR

3

×

×

EC-1142

P0225

PDL POTEN CIRC TK1

3

–

×

EC-1144

P0235

IN-MANI PRES CIRC

3

–

×

EC-1147

P0335

ENGNE SPD SEN CIRC

1

–

×

 or –

EC-1149

P0340

CAMSHAFT SEN CIRC

3

–

–

EC-1151

P0380

PRHT UNIT CTRL CIR

3

–

–

EC-1154

P0381

PRHT DGNSTC CNECT

3

–

–

EC-1156

P0409

EGR POSITN OFFSET

3

×

–

EC-1158

P0487

EGR COMMAND CIRC

3

–

–

EC-1160

P0488

EGR/V POSITN CTRL

3

–

×

 or –

EC-1162

P0500

VEHL/SPD INF CIRC

1

–

–

EC-1165

P0530

REFRIGERNT SEN CIR

1

–

–

EC-1166

P0560

CPU SUPPLY VOLTAGE

1

–

–

EC-1168

P0571

BRAKE SWITCH CIRC

1

–

–

EC-1171

P0575

SPD LIM/CRS CTRL

1

–

–

EC-1174

P0606

COMPUTER(C/U)

1 or 3

×

 or –

×

EC-1178

P0641

SEN SUPPLY N-1 VOL

3

–

×

EC-1180

P0651

SEN SUPPLY N-2 VOL

3

–

×

EC-1182

P0685

MAIN RLY CTRL CIRC

3

–

×

EC-1184

P1089

RAIL PRESS REGULTN

3

–

×

 or –

EC-1186

P2101

ETC FUNCTION/CIRC

3

–

–

EC-1188

P2120

PDL POTEN CIRC TK2

3

–

×

EC-1191

P2226

ATMOS PRES SE CIR

3

–

–

EC-1194

P2263

T/C SYSTEM

3

–

×

EC-1195

P2299

BRK/ACCEL PDL PSTN

3

–

×

EC-1198

P2413

EGR SYSTEM

3

×

×

EC-1202

DTC*

Items

(CONSULT-III screen item)

Trip

MI lighting up

Reference page

Yellow

Red
