DLK-442 < REMOVAL AND INSTALLATION > [WITH I-KEY & SUPER LOCK] HOOD REMOVAL AND INSTALLATION HOOD Fitting Adjustment INFOID:0000000001732017 FRONT END HEIGHT ADJUSTMENT AND LATERAL/LONGITUDINAL CLEARANCE ADJUST- 1. Remove the front grille. Refer to EXT-19, "Removal and Installation" 2. Remove hood lock. Rotate bumper rubber to adjust height until 3. Position hood lock and engage striker. Check hood lock and 4. Install the front grille. Refer to EXT-19, "Removal and Installa- CAUTION: Adjust the clearance between hood and other parts so that the SURFACE MISMATCH ADJUSTMENT 1. Remove the front grille. Refer to EXT-19, "Removal and Installation" 2. Release hood lock, and adjust surface level difference of hood, fender, and headlamp according to the fit- 3. Install and align the hood lock until the center of the striker and the hood lock are vertically aligned. PIIB6508E Hood and headlamp (B - B) : Less than 2.0 mm (0.08 in) Hood and fender (C - C) : Less than 1.5 mm (0.06 in) Hood and fender (D - D) : Less than 1.5 mm (0.06 in) PIIB2526J Hood and front bumper (A - A) : -1.3 - 2.7 mm (-0.05 - 0.11 in) Hood and fender (D - D) : -0.4 - 1.7 mm (-0.16 - 0.07 in) |
