DLK-438

< PRECAUTION >

[WITH I-KEY & SUPER LOCK]

PRECAUTIONS

5.

When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn
the push-button ignition switch from ACC position to ON position, then to LOCK position. (The steering
wheel will lock when the push-button ignition switch is turned to LOCK position.)

6.

Perform self-diagnosis check of all control units using CONSULT-III.

Work

INFOID:0000000001396897

• After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check their

operational.

• Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.

PREPARATION

DLK-439

< PREPARATION >

[WITH I-KEY & SUPER LOCK]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

PREPARATION

PREPARATION

Commercial Service Tools

INFOID:0000000001396898

Tool name

Description

Engine ear

Locating the noise

Remover tool

Remove the clips, pawls, and metal clips

Power tool

Removing nuts and bolts

SIIA0995E

PIIB7923J

PIIB1407E

DLK-440

< ON-VEHICLE MAINTENANCE >

[WITH I-KEY & SUPER LOCK]

PRE-INSPECTION FOR DIAGNOSTIC

ON-VEHICLE MAINTENANCE

PRE-INSPECTION FOR DIAGNOSTIC

Basic Inspection

INFOID:0000000001396899

BASIC INSPECTION

1.

CHECK POWER DOOR LOCK AND UNLOCK SWITCH OPERATION

Check door lock and unlock operation by operating door lock and unlock switch.
Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Refer to

XX-XX, "*****"

.

2.

CHECK INTELLIGENT KEY OPERATION

Check door lock and unlock operation by operating the Intelligent Key remote control button.
Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Refer to

XX-XX, "*****"

.

3.

CHECK DOOR REQUEST SWITCH OPERATION

Check door lock and unlock operation by operating door request switch.

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Refer to

XX-XX, "*****"

.

4.

CHECK KEY REMINDER OPERATION

Check key reminder operation. Refer to

DLK-255, "KEY REMINDER : System Description"

.

Is the inspection result normal?

YES

>> GO TO 5.

NO

>> Refer to

XX-XX, "*****"

.

5.

CHECK AUTO DOOR LOCK OPERATION

Check auto door lock operation. Refer to

XX-XX, "*****"

.

Is the inspection result normal?

YES

>> GO TO 6.

NO

>> Refer to

XX-XX, "*****"

.

6.

CHECK VEHICLE SPEED SENSING AUTO DOOR LOCK OPERATION

Check vehicle speed sensing auto door lock operation. Refer to

XX-XX, "*****"

.

Is the inspection result normal?

YES

>> GO TO 7.

NO

>> Refer to

XX-XX, "*****"

.

7.

CHECK BACK DOOR OPENER OPERATION

Check back door opener operation by operating the back door opener switch.

Is the inspection result normal?

YES

>> GO TO 8.

NO

>> Refer to

XX-XX, "*****"

.

8.

CHECK WARNING FUNCTION

Check warning function. Refer to

DLK-264, "System Description"

.

Is the inspection result normal?

YES

>> GO TO 9.

NO [Buzzer (combination meter)]>> Refer to

XX-XX, "*****"

.

NO (Intelligent Key warning buzzer)>> Refer to

XX-XX, "*****"

.

PRE-INSPECTION FOR DIAGNOSTIC

DLK-441

< ON-VEHICLE MAINTENANCE >

[WITH I-KEY & SUPER LOCK]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

NO (Warning lamp)>> Refer to

XX-XX, "*****"

.

NO (Back door open warning)>> Refer to

XX-XX, "*****"

.

9.

CHECK HAZARD AND BUZZER REMINDER FUNCTION

Check hazard and buzzer reminder function by Intelligent Key or request switch. Refer to

DLK-270, "System

Description"

.

Is the inspection result normal?

YES

>> GO TO 10.

NO (Hazard warning lamp)>> Refer to

XX-XX, "*****"

.

NO (Intelligent Key warning buzzer)>> Refer to

XX-XX, "*****"

.

10.

CHECK OUT

CHECK OUT.

>> INSPECTION END
