DLK-66 < COMPONENT DIAGNOSIS > [WITH I-KEY, WITHOUT SUPER LOCK] DOOR SWITCH 1. Disconnect BCM and driver door switch connectors. 2. Check continuity between BCM connector (A) M18 terminal 29 3. Check continuity between BCM connector and ground. Is the inspection result normal? YES >> GO TO 3. NO >> Repair or replace harness between BCM and door switch. 3. CHECK DOOR SWITCH Check door switch. DLK-66, "DRIVER SIDE : Component Inspection" . Is the inspection result normal? YES >> GO TO 4. NO >> Replace front door switch (driver side). Refer to XX-XX, "*****" . 4. CHECK INTERMITTENT INCIDENT Refer to @@@. >> INSPECTION END DRIVER SIDE : Component Inspection INFOID:0000000001396539 1. CHECK DOOR SWITCH 1. Turn ignition switch OFF. 2. Check door switch. Is the inspection result normal? YES >> Door switch is OK. NO >> Replace front door switch (driver side). Refer to XX-XX, "*****" . PASSENGER SIDE BCM connector Terminal Door switch connector Terminal Continuity M18 29 B34 2 Yes BCM connector Terminal Ground Continuity M18 29 No ALKIA0746ZZ ALKIA0747ZZ Terminal Door switch condition Continuity Door switch 2 Ground part of door switch Pressed Yes Released No |
