Nissan Tiida C11. Manual - part 1444
WCS-58
< ECU DIAGNOSIS >
BCM (BODY CONTROL MODULE)
1: With Intelligent Key
2: With remote keyless entry system
3: Hatchback
KEYLESS LOCK
2
LOCK button of key fob is not pressed
OFF
LOCK button of key fob is pressed
ON
KEYLESS UNLOCK
2
UNLOCK button of key fob is not pressed
OFF
UNLOCK button of key fob is pressed
ON
LIT-SEN FAIL
Light & rain sensor is in normal condition
OK
Light & rain sensor is with internal error
NOTOK
OIL PRESS SW
• Ignition switch OFF or ACC
• Engine running
OFF
Ignition switch ON
ON
OUT SIDE TEMP
NOTE:
Diesel engine models
Ignition switch ON
Approximately the same as outside
air temperature
PASSING SW
Other than lighting switch PASS
OFF
Lighting switch PASS
ON
PUSH SW
1
Return to ignition switch to LOCK position
OFF
Press ignition switch
ON
REAR DEF SW
Rear window defogger switch OFF
OFF
Rear window defogger switch ON
ON
RKE LOCK AND
UNLOCK
2
NOTE:
The item is indicated, but not monitored
OFF
ON
RR FOG SW
Rear fog lamp switch OFF
OFF
Rear fog lamp switch ON
ON
RR WASHER SW
3
Rear washer switch OFF
OFF
Rear washer switch ON
ON
RR WIPER INT
3
Rear wiper switch OFF
OFF
Rear wiper switch INT
ON
RR WIPER ON
3
Rear wiper switch OFF
OFF
Rear wiper switch ON
ON
RR WIPER STOP
3
Rear wiper stop position
OFF
Other than rear wiper stop position
ON
TAIL LAMP SW
Lighting switch OFF
OFF
Lighting switch 1ST
ON
TRNK OPNR SW
When back door opener switch is not pressed
OFF
When back door opener switch is pressed
ON
TURN SIGNAL L
Turn signal switch OFF
OFF
Turn signal switch LH
ON
TURN SIGNAL R
Turn signal switch OFF
OFF
Turn signal switch RH
ON
UNLOCK WITH DR
NOTE:
The item is indicated, but not monitored
OFF
ON
VEHICLE SPEED
While driving
Equivalent to speedometer reading
Monitor Item
Condition
Value/Status
