Nissan Tiida C11. Manual - part 1438





WCS-34

< COMPONENT DIAGNOSIS >

WARNING CHIME SYSTEM

ALNIA0870GB

WCS

WARNING CHIME SYSTEM

WCS-35

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ALNIA0871GB

WCS-36

< COMPONENT DIAGNOSIS >

WARNING CHIME SYSTEM

ALNIA0872GB

WCS

COMBINATION METER

WCS-37

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ECU DIAGNOSIS

COMBINATION METER

Reference Value

INFOID:0000000001728308

TERMINAL LAYOUT

PHYSICAL VALUES

LKIA0698E

Ter-

mi-
nal

No.

Wire

color

Item

Condition

Reference value (V)

(Approx.)

Ignition

switch

Operation or condition

1

L

CAN-H

2

P

CAN-L

3

V

Vehicle speed signal output
(2-pulse)

ON

Speedometer operated
[When vehicle speed is approx.
40 km/h (25 MPH)]

NOTE:
Maximum voltage may be 5V due to
specifications (connected units).

4

O

Vehicle speed signal output
(8-pulse)

ON

Speedometer operated
[When vehicle speed is approx.
40 km/h (25 MPH)]

NOTE:
Maximum voltage may be 12V due to
specifications (connected units).

6

BR

Fuel level sensor signal (+)

Refer to

MWI-29, "Description"

.

7

BR

Air bag signal

ON

Air bag warning lamp ON

4

Air bag warning lamp OFF

0

8

P

O/D OFF switch

ON

O/D OFF switch pressed

0

O/D OFF switch released

Battery voltage

9

O

Seat belt buckle switch (driv-
er side)

ON

Unfastened (ON)

0

Fastened (OFF)

Battery voltage

10

SB

Parking Brake switch

ON

Parking brake applied

0

Parking brake released

Battery voltage

PKIC0642E

PKIC0643E
