REPAIR FOR COMPONENT PARTS TM-259 < DISASSEMBLY AND ASSEMBLY > [TYPE 1 (4AT: RE4F03B)] C E F G H I J K L M A B TM N O P 1. Check operation of reverse clutch a. Install seal rings to drum support of oil pump assembly, and set b. Apply compressed air into the oil hole at the location as shown. c. Check to see that retaining plate moves to snap ring. d. If retaining plate does not contact snap ring: 2. Remove snap ring (1) using suitable tool (A). 3. Remove retaining plate, drive plates, driven plates and dish 4. Set Tool on spring retainer assembly, and remove snap ring CAUTION: Set Tool directly over return springs. 5. Remove spring retainer assembly from reverse clutch drum. CAUTION: Do not remove return springs from spring retainer. 6. Install seal rings to drum support of oil pump assembly (1), and CAUTION: Do not flow air in too quickly or reverse clutch piston (3) 7. Remove D-ring (1) and seal ring (2) from reverse clutch piston SAT155D SCIA7024J SAT157D SCIA5999J SCIA5998J |
