< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

28

(R)

Ground

Combination switch
INPUT 2

Input

Combination
switch
(Wiper intermit-
tent dial 4)

All switch OFF

1.4V

Lighting switch PASS

1.3V

Lighting switch 2ND

1.3V

Front wiper switch INT

1.3V

Front wiper switch HI

1.3V

29

(BR)

Ground

Driver door switch

Input

Driver door
switch

OFF (When driver door
closed)

Battery voltage

ON (When driver door
opened)

0V

30

(SB)

Ground

Passenger door
switch

Input

Passenger door
switch

OFF (When passenger
door closed)

Battery voltage

ON (When passenger
door opened)

0V

31

3

(SB)

Ground

A/C indicator

Output

A/C switch

OFF

Battery voltage

ON

0V

Terminal No.

(Wire color)

Description

Condition

Reference Value

(Approx.)

Signal name

Input/

Output

+

−

JPMIA0165GB

JPMIA0167GB

JPMIA0166GB

JPMIA0168GB

JPMIA0196GB

MWI

BCM (BODY CONTROL MODULE)

MWI-67

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

32

4

(LG)

Ground

Door lock status indi-
cator

Output

Door lock status
indicator

ON

Battery voltage

OFF

0V

33

(G)

Ground

Combination switch
OUTPUT 2

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

0V

Front washer switch ON
(Wiper intermittent dial 4)

Rear wiper switch ON
(Wiper intermittent dial 4)

Rear washer switch ON
(Wiper intermittent dial 4)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 5
• Wiper intermittent dial 6

34

(GR)

Ground

Combination switch
OUTPUT 4

Output

Combination
switch
(Wiper intermit-
tent dial 4)

All switch OFF

0V

Lighting switch 2ND

Lighting switch PASS

Front fog lamp switch ON

Turn signal switch LH

35

3, 7

(BR)

Ground

Sensor ground

Output

Ignition switch

ON

0V

→

 5V

OFF

0V

36

7

(V)

Ground

Ambient sensor sig-
nal

Input

Ignition switch

ON

0V

→

 5V

OFF

0V

38

5

(V)

Ground

NATS antenna amp.

Input/

Output

Insert mechanical key into ignition key cylin-
der

Just after Insert mechanical key
into ignition key cylinder. Pointer
of tester should move

39

(P)

—

CAN-L

Input/

Output

—

—

45

3

(GR)

Ground

Intake sensor

Input

Ignition switch

ON

0V

OFF

Battery voltage

47

5

(GR)

Ground

Security indicator

Output

Security indica-
tor

ON

0V

Blinking
(every 2.4 seconds)

Battery voltage

→

 0V

OFF

Battery voltage

48

(W)

Ground

Start power supply

Input

Ignition switch START

Battery voltage

Other than above

0V

49

(R)

Ground

Front demist vent
switch

Input

Front demist
vent switch

ON

0V

→

 5V

OFF

0V

50

(P)

Ground

Fan switch

Output

Fan switch

Not pressed

Battery voltage

Pressed

0

51

7

(L)

Ground

PTC relay 3 control

Output

Ignition ON

PTC heater 3 ON

0V

PTC heater 3 OFF

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Reference Value

(Approx.)

Signal name

Input/

Output

+

−

SKIA2167J

SKIA2167J

MWI-68

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

52

7

(GR)

Ground

PTC relay 2 control

Output

Ignition ON

PTC heater 2 ON

0V

PTC heater 2 OFF

Battery voltage

58

(Y)

Ground

Door unlock sensor

Input

Driver door

Lock

Battery voltage

Unlock

0V

59

(O)

Ground

Rear door switch LH

Input

Rear door
switch LH

OFF (When rear door LH
closed)

Battery voltage

ON (When rear door LH
opened)

0V

60

(GR)

Ground

Rear door switch RH

Input

Rear door
switch RH

OFF (When rear door RH
closed)

Battery voltage

ON (When rear door RH
opened)

0V

61

3

(O)

Ground

A/C switch

Output

A/C switch

Not pressed

Battery voltage

Pressed

0V

63

(R)

Ground

Light & rain sensor
serial link

Output

Ignition switch OFF

Battery voltage

Ignition switch ON

64

7

(O)

Ground

PTC relay 1 control

Output

Ignition ON

PTC heater 1 ON

0V

PTC heater 1 OFF

Battery voltage

65

(V)

Ground

Turn signal LH

Output

Ignition switch
ON

Turn signal switch OFF

0V

Turn signal switch LH

66

(W)

Ground

Turn signal RH

Output

Ignition switch
ON

Turn signal switch OFF

0V

Turn signal switch RH

67

(G)

Ground

Door unlock (pas-
senger and rear
doors)

Output

Door lock/un-
lock switch

Pressed to the unlock side

Battery voltage

Pressed to the lock side

0V

68

1

(R)

Ground

Back door lock actu-
ator

Output

Back door
opener switch

Pressed

Battery voltage

Not pressed

0V

68

2

(R)

Ground

Trunk release sole-
noid

Output

Trunk lid opener
switch

Pressed

Battery voltage

Not pressed

0V

Terminal No.

(Wire color)

Description

Condition

Reference Value

(Approx.)

Signal name

Input/

Output

+

−

MKIB0173E

SKIA1120J

SKIA1120J

MWI

BCM (BODY CONTROL MODULE)

MWI-69

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

1: Hatchback

2: Sedan

3: Manual A/C

4: Superlock

5: Remote keyless entry

6: Intelligent Key

7: LHD diesel

69

(G)

Ground

Rear fog lamp

Output

Lighting switch
1ST and front
fog lamp switch
ON

Rear fog lamp switch OFF

0V

Rear fog lamp switch ON

Battery voltage

70

(B)

Ground

Ground

—

—

0V

71

1

(V)

Ground

Rear wiper motor

Output

Rear wiper switch OFF

0V

Rear wiper switch ON

Battery voltage

72

(LG)

Ground

Battery power sup-
ply

Input

—

Battery voltage

73

(R)

Ground

Interior room lamp
power supply

Output

After passing the interior room lamp battery
saver operation time

0V

Any other time after passing the interior room
lamp battery saver operation time

Battery voltage

74

(Y)

Ground

Battery power sup-
ply

Input

—

Battery voltage

75

4

(V)

Ground

Super lock

Output

When lock button of keyfob or Intelligent Key
is not pressed

0V

When lock button of keyfob or Intelligent Key
is pressed

Battery voltage

76

(G)

Ground

Driver door unlock

Output

Door lock/un-
lock switch

Pressed to the unlock side

Battery voltage

Pressed to the lock side

0V

77

(SB)

Ground

Door lock (All)

Output

Door lock/un-
lock switch

Pressed to the unlock side

0V

Pressed to the lock side

Battery voltage

78

(L)

Ground

Power window pow-
er supply

Output

Ignition switch

OFF or ACC

0V

ON

Battery voltage

79

(Y)

Ground

Battery power sup-
ply

Input

—

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Reference Value

(Approx.)

Signal name

Input/

Output

+

−
