5. If only one telephone number is regis-

tered  under  the  name  you  just  said,  the
voice guide proceeds to step 6.
If  two  or  more  telephone  numbers  are
registered  that  match  the  name  you  just
said,  the  voice  guide  will  say  “Would
you  like  to  call  <name>  at  [home],
[work], [mobile], or [other]?” Select the
location to call.

NOTE

If the name you selected has matching data
in the vehicle phone book but no telephone
number is registered under the selected loca-
tion, the voice guide will say “{home/work/
mobile/other} not found for <name>. Would
you like to add location or try again?”
Say “Try again”, and the system will return
to step 3.
Say “Add location” and you can register an
additional telephone number under the selec-
ted location.

If the name you selected has matching data
in the mobile phone book but no telephone
number is registered under the selected loca-
tion, the voice guide will say “{home/work/
mobile/other} not found for <name>. Would
you like to try again?”
Answer “Yes” and the system will return to
step 3.
Answer “No” and the call will be cancelled.
Start over again from step 1.

6. The voice guide will say “Calling

<name> <location>” and then the sys-
tem will dial the telephone number.

NOTE

When  the  confirmation  function  is  on,  the
system  will  ask  if  the  name  and  location  of
the  receiver  are  correct.  If  the  name  is  cor-
rect, answer “Yes”.
To  change  the  name  or  location  to  call,  an-
swer “No”. The system will return to Step 3.

Redialing
You can redial the last number called, based
on the history of dialed calls in the paired cel-
lular phone.
Use the following procedure to redial.

1. Press the SPEECH button.
2. Say “Redial”.

SEND function

E00761300035

During  a  call,  press  the  SPEECH  button  to
enter  voice  recognition  mode,  then  say
“<numbers>  SEND”  to  generate  DTMF
tones.
For example, if during a call you need to sim-
ulate the pressing of a phone button as a re-
sponse  to  an  automated  system,  press  the
SPEECH  button  and  speak  “1  2  3  4  pound
send” and the 1234# will be sent via your cel-
lular phone.

Receiving calls

E00761600054

If  an  incoming  phone  call  is  received  while
the  ignition  switch  or  the  operation  mode  is
in ON or ACC, the audio system will be au-
tomatically turned on and switched to the in-
coming call, even when the audio system was
originally off.
The  voice  guide  announcement  for  the  in-
coming call will be output from the front pas-
senger’s seat speaker.
If  the  CD  player  or  radio  was  playing  when
the  incoming  call  was  received,  the  audio
system  will  mute  the  sound  from  the  CD
player or radio and output only the incoming
call.
To  receive  the  call,  press  the  PICK-UP  but-
ton on the steering wheel control switch.
When the call is over, the audio system will
return to its previous state.

MUTE function

E00760300041

At any time during a call, you can mute the
vehicle microphone.
Pressing the SPEECH button and then saying
“Mute” during a call will turn ON the mute
function and mute the microphone.
Saying “Mute off” in the same way will turn
off the mute function and cancel the mute on
the microphone.

Bluetooth

2.0 interface*

7-88

OKTE18E1

For pleasant driving

Switching between hands-free
mode and private mode

E00761400036

The Bluetooth

2.0 interface can switch be-

tween hands-free mode (hands-free calls) and
private mode (calls using cellular phone).
If  you  press  the  SPEECH  button  and  say
“Transfer  call”  during  a  hands-free  call,  you
can stop the hands-free mode and talk in pri-
vate mode.
To  return  to  hands-free  mode,  press  the
SPEECH  button  again  and  say  “Transfer
call.”

Phone book function

E00763700017

The Bluetooth

2.0 interface has 2 types of

unique  phone  books  that  are  different  from
the  phone  book  stored  in  the  cellular  phone.
They are the vehicle phone book and the mo-
bile phone book.
These  phone  books  are  used  to  register  tele-
phone  numbers  and  to  make  calls  to  desired
numbers via the voice recognition function.

NOTE

Disconnecting the battery cable will not de-
lete information registered in the phone
book.

Vehicle phone book

E00763801347

This  phone  book  is  used  when  making  calls
with the voice recognition function.
Up to 32 names can be registered in the vehi-
cle phone book per language.
Also,  each  entry  has  4  locations  associated
with: home, work, mobile and other. You can
register one telephone number for each loca-
tion.

You  can  register  a  desired  name  as  a  name
for any phone book entry registered in the ve-
hicle phone book.
Names  and  telephone  numbers  can  be
changed later on.

The vehicle phone book can be used with all
paired cellular phones.

To register a telephone number in the ve-
hicle phone book
You  can  register  a  telephone  number  in  the
vehicle phone book in the following 2 ways:
Reading out a telephone number, or selecting
and transferring 1 phone book entry from the
phone book of the cellular phone.

To  register  by  reading  out  a  telephone
number

1. Press the SPEECH button.
2. Say “Phone book”.

3. The voice guide will say “Select one of

the following: new entry, edit number,
edit name, list names, delete, erase all, or
import contact.” Say “New entry”.

4. The voice guide will say “Name please.”

Say your preferred name to register it.

NOTE

If  the  maximum  number  of  entries  are  al-
ready  registered,  the  voice  guide  will  say
“The phone book is full. Would you like to
delete  a  name?”  Say  “Yes”  if  you  want  to
delete a registered name.
Say “No”, to return to the main menu.

5. When the name has been registered, the

voice  guide  will  say  “home,  work,  mo-
bile,  or  other?”  Say  the  location  for
which  you  want  to  register  a  telephone
number.

NOTE

When  the  confirmation  function  is  on,  the
voice  guide  will  say  “<Location>.  Is  this
correct?” Answer “Yes”.
If  a  telephone  number  has  been  registered
for the selected location, the voice guide will
say “The current number is <telephone num-
ber>, number please.”
If  you  do  not  want  to  change  the  telephone
number, say “cancel” or the original number
to keep it registered.

Bluetooth

2.0 interface*

7-89

OKTE18E1

For pleasant driving

6. The voice guide will say “Number

please”. Say the telephone number to
register it.

NOTE

In the case of English, the system will recog-
nise both “zero” and “oh” (Letter “o”) for
the number “0.”

7. The voice guide will repeat the tele-

phone  number  you  have  just  read,  and
then register the number.
When  the  telephone  number  has  been
registered,  the  voice  guide  will  say
“Number  saved.  Would  you  like  to  add
another number for this entry?”
To  add  another  telephone  number  for  a
new  location  for  the  current  entry,  an-
swer  “Yes”.  The  system  will  return  to
location selection in Step 5.
Answer  “No”  to  end  the  registration
process and return to the main menu.

NOTE

When  the  confirmation  function  is  on,  after
repeating  the  telephone  number  you  have
read,  the  voice  guide  will  ask  “Is  this  cor-
rect?” Answer “Yes”.
Answer “No” to return to telephone number
registration in step 6.

To select and transfer one phone book en-
try from the phone book of the cellular
phone
You can select 1 phone book entry from the
phone book of the cellular phone and register
it in the vehicle phone book.

NOTE

Transfer is not permitted unless the vehicle
is parked. Before transferring, make sure
that the vehicle is parked in a safe location.

All or part of data may not be transferred,
even when the cellular phone supports Blue-
tooth

, depending on the compatibility of

the device.

The maximum supported telephone number
length is 19 digits. Any telephone number of
20 digits or more will be truncated to the
first 19 digits.

If telephone numbers contain characters oth-
er than 0 to 9, *, # or +, these characters are
deleted before the transfer.

For the connection settings on the cellular
phone side, refer to the instructions for the
cellular phone.

1. Press the SPEECH button.
2. Say “Phone book”.
3. The voice guide will say “Select one of

the following: new entry, edit number,
edit name, list names, delete, erase all, or
import contact.” Say “Import contact”.

4. The voice guide will say “Would you

like to import a single entry or all con-
tacts?” Say “Single entry”.
The Bluetooth

2.0 interface will be-

come ready to receive transferred phone
book data.

NOTE

5. After the voice guide says “Ready to re-

ceive a contact from the phone. Only a
home, a work, and a mobile number can
be imported”, the Bluetooth

2.0 inter-

face will receive the phone book data
from the Bluetooth

compatible cellular

phone.

6. Operate the Bluetooth

compatible cel-

lular phone to set it up so that the phone
book entry you want to register in the
vehicle phone book can be transferred to
the Bluetooth

2.0 interface.

Bluetooth

2.0 interface*

7-90

OKTE18E1

For pleasant driving

NOTE

If the Bluetooth

2.0 interface cannot recog-

nise the Bluetooth

compatible cellular

phone  or  the  connection  takes  too  much
time,  the  voice  guide  will  say  “Import  con-
tact has timed out” and then the system will
cancel  the  registration.  In  such  case,  start
over again from Step 1.

Pressing the HANG-UP button or pressing
and holding the SPEECH button will cancel
the registration.

7. When the reception is complete, the

voice  guide  will  say  “<Number  of  tele-
phone  numbers  that  had  been  registered
in  the  import  source>  numbers  have
been  imported.  What  name  would  you
like to use for these numbers?”
Say  the  name  you  want  to  register  for
this phone book entry.

NOTE

If the entered name is already used for other
phone book entry or similar to a name used
for other phone book entry, that name cannot
be registered.

8. The voice guide will say “Adding

<name>”.
When  the  confirmation  function  is  on,
the  system  will  ask  if  the  name  is  cor-
rect. Answer “Yes”.
Answer  “No”,  and  the  voice  guide  will
say  “Name  please”.  Register  a  different
name.

9. The voice guide will say “Numbers

saved”.

10. The voice guide will say “Would you

like to import another contact?”
Answer  “Yes”  if  you  want  to  continue
with  the  registration.  You  can  continue
to register a new phone book entry from
Step 5.
Answer  “No”  to  return  to  the  main
menu.

To change the content registered in the ve-
hicle phone book

E00739800024

You can change or delete a name or tele-
phone number registered in the vehicle phone
book.
You can also listen to the list of names regis-
tered in the vehicle phone book.

NOTE

The system must have at least one entry.

Editing a telephone number

1. Press the SPEECH button.
2. Say “Phone book”.
3. The voice guide will say “Select one of

the following: new entry, edit number,
edit name, list names, delete, erase all, or
import contact.” Say “Edit number”.

4. The voice guide will say “Please say the

name of the entry you would like to edit,
or say list names.” Say the name of the
phone book entry you want to edit.

NOTE

Say “List names,” and the names registered
in the phone book will be read out in order.
Refer to “Listening to the list of registered
names” on page 7-92.

5. The voice guide will say “Home, work,

mobile or other?” Select and say the lo-
cation  where  the  telephone  number  you
want to change or add is registered.
When  the  confirmation  function  is  on,
the  system  will  check  the  target  name
and location again. Answer “Yes” if you
want to continue with the editing.
Answer “No” to return to Step 3.

6. The voice guide will say “Number

please”. Say the telephone number you
want to register.

Bluetooth

2.0 interface*

7-91

OKTE18E1

For pleasant driving

NOTE

If the telephone number is already registered
in the selected location, the voice guide will
say “The current number is <current num-
ber>. New number, please.” Say a new tele-
phone number to change the current number.

7. The voice guide will repeat the tele-

phone number.
When the confirmation function is on,
the system will ask if the number is cor-
rect. Answer “Yes”.
Answer “No”, the system will return to
the Step 3.

8. Once the telephone number is registered,

the voice guide will say “Number saved”
and then the system will return to the
main menu.

NOTE

If the location where a telephone number
was already registered has been overwritten
with a new number, the voice guide will say
“Number changed” and then the system will
return to the main menu.

Editing a name

1. Press the SPEECH button.
2. Say “Phone book”.

3. The voice guide will say “Select one of

the following: new entry, edit number,
edit name, list names, delete, erase all, or
import contact.” Say “Edit name”.

4. The voice guide will say “Please say the

name of the entry you would like to edit,
or say list names.” Say the name you
want to edit.

NOTE

Say “List names” and the names registered
in the phone book will be read out in order.
Refer to “Listening to the list of registered
names” on page 7-92.

5. The voice guide will say “Changing

<name>”.
When  the  confirmation  function  is  on,
the  system  will  ask  if  the  name  is  cor-
rect.  Answer  “Yes”  if  you  want  to  con-
tinue  with  the  editing  based  on  this  in-
formation.  Answer  “No”  to  return  to
Step 4.

6. The voice guide will say “Name please”.

Say the new name you want to register.

7. The registered name will be changed.

When the change is complete, the sys-
tem will return to the main menu.

Listening to the list of registered names

E00739900025

1. Press the SPEECH button.

2. Say “Phone book”.
3. The voice guide will say “Select one of

the following: new entry, edit number,
edit name, list names, delete, erase all, or
import contact.” Say “List names”.

4. Bluetooth

2.0 interface will read out

the entries in the phone book in order.

5. When the voice guide is done reading

the  list,  it  will  say  “End  of  list,  would
you  like  to  start  from  the  beginning?”
When  you  want  to  check  the  list  again
from the beginning, answer “Yes”.
When you are done, answer “No” to re-
turn to the previous or main menu.

NOTE

You can call, edit or delete a name that is
being read out.
Press the SPEECH button and say “Call” to
call the name, “Edit name” to edit it, or “De-
lete” to delete it.
The system will beep and then execute your
command.

If  you  press  the  SPEECH  button  and  say
“Continue”  or  “Previous”  while  the  list  is
being  read,  the  system  will  advance  or  re-
wind  the  list.  Say  “Continue”  to  proceed  to
the next entry or “Previous” to return to the
previous entry.

Deleting a telephone number

E00740000026

1. Press the SPEECH button.

Bluetooth

2.0 interface*

7-92

OKTE18E1

For pleasant driving

2. Say “Phone book”.
3. The voice guide will say “Select one of

the following: new entry, edit number,
edit name, list names, delete, erase all, or
import contact.” Say “Delete”.

4. The voice guide will say “Please say the

name of the entry you would like to de-
lete, or say list names”. Say the name of
the phone book entry in which the tele-
phone number you want to delete is reg-
istered.

NOTE

Say “List names”, and the names registered
in the phone book will be read out in order.
Refer to “Listening to the list of registered
names” on page 7-92.

5. If only one telephone number is regis-

tered  in  the  selected  phone  book  entry,
the  voice  guide  will  say  “Deleting
<name> <location>”.
If multiple telephone numbers are regis-
tered  in  the  selected  phone  book  entry,
the voice guide will say “Would you like
to delete [home], [work], [mobile], [oth-
er], or all?”
Select  the  location  to  delete,  and  the
voice  guide  will  say  “Deleting  <name>
<location>”.

NOTE

To delete the telephone numbers from all lo-
cations, say “All”.

6. The system will ask if you really want to

delete  the  selected  telephone  number(s)
to  go  ahead  with  the  deletion,  answer
“Yes”.  Answer  “No”,  the  system  will
cancel  deleting  the  telephone  number(s)
and then return to step 4.

7. When the deletion of the telephone num-

ber  is  completed,  the  voice  guide  will
say  “<name>  <location>  deleted”  and
then  the  system  will  return  to  the  main
menu.
If  all  locations  are  deleted,  the  system
will  say  “<name>  and  all  locations  de-
leted”  and  the  name  will  be  removed
from the phone book. If numbers still re-
main  under  the  entry,  the  name  will  re-
tain the other associated numbers.

Erasing the phone book

E00740100027

You can delete all registered information
from the vehicle phone book.

1. Press the SPEECH button.
2. Say “Phone book”.
3. The voice guide will say “Select one of

the following: new entry, edit number,
edit name, list names, delete, erase all, or
import contact.” Say “Erase all”.

4. For confirmation purposes, the voice

guide will ask “Are you sure you want to
erase  everything  from  your  hands-free
system phone book?” Answer “Yes.”
Answer  “No”  to  cancel  the  deletion  of
all  registered  information  in  the  phone
book and return to the main menu.

5. The voice guide will say “You are about

to  delete  everything  from  your  hands-
free system phone book. Do you want to
continue?” Answer “Yes” to continue.
Answer  “No”  to  cancel  the  deletion  of
all  registered  information  in  the  phone
book and return to the main menu.

6. The voice guide will say “Please wait,

erasing the handsfree system phone
book” and then the system will delete all
data in the phone book.
When the deletion is complete, the voice
guide will say “Hands-free system phone
book erased” and then the system will
return to the main menu.

Mobile phone book

E00763900080

All entries in the phone book stored in the
cellular phone can be transferred in a batch
and registered in the mobile phone book.
Up to 7 mobile phone books, each containing
up to 1,000 names, can be registered.

Bluetooth

2.0 interface*

7-93

OKTE18E1

For pleasant driving

The Bluetooth

2.0 interface automatically

converts from text to voice the names regis-
tered in the transferred phone book entries,
and creates names.

NOTE

Only the mobile phone book transferred
from the connected cellular phone can be
used with that cellular phone.

You cannot change the names and telephone
numbers in the phone book entries registered
in the mobile phone book. You cannot select
and  delete  specific  phone  book  entries,  ei-
ther.
To  change  or  delete  any  of  the  above,
change  the  applicable  information  in  the
source phone book of the cellular phone and
then transfer the phone book again.

To import a devices phone book
Follow the steps below to transfer to the mo-
bile phone book the phone book stored in the
cellular phone.

NOTE

Transfer should be completed while the ve-
hicle is parked. Before transferring, make
sure that the vehicle is parked in a safe loca-
tion.

The already stored phone book in the mobile
phone book is overwritten by the stored
phone book in the cellular phone.

NOTE

All or part of data may not be transferred,
even when the cellular phone supports Blue-
tooth

, depending on the compatibility of

the device.

Only a home, a work, and a mobile number
can be imported.

The maximum supported telephone number
length is 19 digits. Any telephone number of
20 digits or more will be truncated to the
first 19 digits.

If telephone numbers contain characters oth-
er than 0 to 9, *, # or +, these characters are
deleted before the transfer.

For the connection settings on the cellular
phone side, refer to the instructions for the
cellular phone.

1. Press the SPEECH button.
2. Say “Phone book.”
3. The voice guide will say “Select one of

the following: new entry, edit number,
edit name, list names, delete, erase all, or
import contact.” Say “Import contact.”

4. The voice guide will say “Would you

like to import a single entry or all con-
tacts?” Say “All contacts.”

5. The voice guide will say “Importing the

contact list from the mobile phone book.
This may take several minutes to com-
plete. Would you like to continue?” An-
swer “Yes,” transferring to the mobile
phone book the phone book stored in the
cellular phone will start.

Answer “No,” to return to the main
menu.

NOTE

The transfer may take some time to com-
plete depending on the number of contacts.

If the Bluetooth

2.0 interface could not be

connected to the Bluetooth

compatible cel-

lular phone, the voice guide will say “Un-
able to transfer contact list from phone” and
then the system will return to the main
menu.

If you press the HANG-UP button or press
and hold the SPEECH button during the data
transfer, the transfer will be cancelled and
the system will return to the main menu.

If an error occurs during the data transfer, all
transfer will be cancelled and the voice
guide will say “Unable to complete the
phone book import” and then the system will
return to the main menu.

If there are no contacts in the phone book,
the voice guide will say “There are no con-
tacts on the connected phone.”

6. When the transfer is complete, the voice

guide will say “Import complete” and
then the system will return to the main
menu.

Bluetooth

2.0 interface*

7-94

OKTE18E1

For pleasant driving

Enrollment commands

E00732401451

Phrase

English

French

Spanish

Italian

German

Dutch

Portuguese

Russian

1 0123456789

0123456789

2 888 555 1212

888 555 1212

3 Call

Appeler

Llamar

Chiama

Anrufen

Bellen

Ligar

Вызов

4 Dial

Composer

Marcar

Componi

Wählen

Nummer keuze Marcar

Набор

5 Setup

Configurer

Configuración Configura

Einrichtung

Setup

Configurar

Настройка

6 Cancel

Annuler

Cancelar

Annulla

Abbrechen

Annuleren

Cancelar

Отмена

7 Continue

Continuer

Continuar

Continua

Weiter

Doorgaan

Continuar

Продолжить

8 Help

Aide

Ayuda

Aiuto

Hilfe

Help

Ajuda

Справка

USB input terminal*

E00761901692

You can connect your USB memory device
or iPod

to play music files stored in the USB

memory device or iPod.

“iPod” is a registered trademark of Apple

Inc. in the United States and other coun-
tries.

USB input terminal*

7-95

OKTE18E1

For pleasant driving

The USB input terminal (A) is located in the
indicated position.

Vehicles without Smart-
phone Link Display Audio

Vehicles with Smartphone
Link Display Audio

This section explains how to connect and re-
move a USB memory device or iPod.
See the following section for details on how
to play music files.
Refer to “Listen to an iPod*” on page 7-31.
Refer to “Listen to Audio Files on a USB De-
vice” on page 7-58.
Refer to “To play iPod/USB memory device
tracks via voice operation” on page 7-60.

How to connect a USB memory

device

E00762001616

1. Park your vehicle in a safe place and

turn the ignition switch to the “LOCK”
position or put the operation mode in
OFF.

2. Open the USB input terminal cover (A)

on the centre console.

Vehicles without Smart-
phone Link Display Audio

Vehicles with Smartphone
Link Display Audio

3. Connect a commercially available USB

connector cable (C) to the USB memory
device (B).

4. Connect the USB connector cable to the

USB input terminal.

NOTE

Do not connect the USB memory device to
the USB input terminal directly.
The USB memory device may be damaged.

5. To remove the USB connector cable,

turn  the  ignition  switch  to  the  “LOCK”
position  or  put  the  operation  mode  in
OFF  first  and  perform  the  installation
steps in reverse.

USB input terminal*

7-96

OKTE18E1

For pleasant driving

CAUTION

After removing the USB connector cable, be
sure to close the terminal cover. Entry of
foreign matter into the terminal may cause a
malfunction.

How to connect an iPod

E00762101620

1. Park your vehicle in a safe place and

turn the ignition switch to the “LOCK”
position or put the operation mode in
OFF.

2. Open the USB input terminal cover (A)

on the centre console.

Vehicles without Smart-
phone Link Display Audio

Vehicles with Smartphone
Link Display Audio

3. Connect the connector cable to the iPod.

NOTE

Use a genuine connector cable from Apple
Inc.

4. Connect the connector cable to the USB

input terminal.

5. To remove the connector cable, turn the

ignition  switch  to  the  “LOCK”  position
or  put  the  operation  mode  in  OFF  first
and  perform  the  installation  steps  in  re-
verse.

CAUTION

After removing the connector cable, be sure
to close the terminal cover. Entry of foreign
matter into the terminal may cause a mal-
function.

Types of connectable devices

and supported file specifica-

tions

E00762201533

Except for vehicles equipped

with the Bluetooth

2.0 inter-

face

For details about the types of connectable de-
vices and supported file specifications, refer
to the following pages and manuals.

For vehicles equipped with the AM/FM ra-
dio/CD player with AUX
Refer to “Listen to an iPod” on page 7-31,
“Listen to Audio Files on a USB Device*” on
page 7-33 and “Audio Files (MP3/WMA/
AAC)” on page 7-20.

For

vehicles

equipped

with

the

LW/MW/FM radio/CD player
Refer to the separate owner’s manual.

For vehicles equipped with the DISPLAY
AUDIO
Refer to the separate owner’s manual.

For

vehicles

equipped

with

the

MITSUBISHI Multi-Communication Sys-
tem (MMCS)
Refer to the separate owner’s manual.

For vehicles equipped with the

Bluetooth

2.0 interface

For details about the types of connectable de-
vices and supported file specifications, refer
to the following sections.

Device types

Devices of the following types can be con-
nected.

USB input terminal*

7-97

OKTE18E1

For pleasant driving

Model name

Condition

USB memory device

Storage capacity of
256 Mbytes or more
(File System is
FAT16/32)

Models other than
USB memory devi-
ces and iPods

Digital audio player
supporting mass stor-
age class

In  some  countries,  for  connectable  device
types  for  “iPod*,”  “iPod  classic*,”  “iPod
nano*,” “iPod touch*” and “iPhone*,” access
the MITSUBISHI MOTORS website.
Please read and agree to the “Warning about
Links to the Web Sites of Other Companies”.
The  websites  mentioned  above  may  connect
you to websites other than the MITSUBISHI
MOTORS website.
http://www.mitsubishi-motors.com/en/prod-
ucts/ index.html
*: “iPod,” “iPod classic,” “iPod nano,” “iPod
touch”  and  “iPhone”  are  registered  trade-
marks of Apple Inc. in the United States and
other countries.

NOTE

Depending on the type of the USB memory
device or other device connected, the con-
nected device may not function properly or
the available functions may be limited.

It is recommended to use an iPod with firm-
ware updated to the latest version.

NOTE

You can charge your iPod by connecting it
to the USB input terminal when the ignition
switch or the operation mode is in ON or
ACC.

Do not keep your USB memory device or
iPod in your vehicle.

It is recommended that you back up files in
case of data damage.

Do  not  connect  to  the  USB  input  terminal
any  device  (hard  disk,  card  reader,  memory
reader, etc.) other than the connectable devi-
ces specified in the previous section. The de-
vice and/or data may be damaged. If any of
these devices was connected by mistake, re-
move  it  after  turning  the  ignition  switch  to
the  “LOCK”  position  or  putting  the  opera-
tion mode in OFF.

File specifications

You  can  play  music  files  of  the  following
specifications that are saved in a USB memo-
ry  device  or  other  device  supporting  mass
storage  class.  When  you  connect  your  iPod,
playable  file  specifications  depend  on  the
connected iPod.

Item

Condition

File format

MP3, WMA, AAC,
WAV

Maximum number of
levels
(including the root)

Level 8

Item

Condition

Number of folders

700

Number of files

65,535

HDMI terminal*

E00771400127

You can connect a commercially available
HDMI device such as a video camera and a
smart phone to the HDMI terminal (A).

NOTE

For details, refer to the separate owner’s
manual for a Smartphone Link Display Au-
dio.

HDMI terminal*

7-98

OKTE18E1

For pleasant driving

To connect

1. Park your vehicle in a safe place and

turn the ignition switch to the “LOCK”
position or put the operation mode in
OFF.

2. Open the terminal cover (A) on the cen-

tre console.

3. Connect a commercially available

HDMI cable to the HDMI device.

4. Connect a HDMI cable to the HDMI ter-

minal.

5. To remove the HDMI cable, perform the

installation steps in reverse.

CAUTION

After removing the HDMI cable, be sure to
close the terminal cover. Entry of foreign
matter into the terminal may cause a mal-
function.

Sun visors

E00711202479

1- To eliminate front glare
2- To eliminate side glare

Card holder*

Cards can be slipped into the holder (A) on
the back of the sun visor.

Type 1

Type 2

Sun visors

7-99

OKTE18E1

For pleasant driving

Vanity mirror*

E00711301822

A vanity mirror is fitted to the back of the
sun visor on the passenger side.

Ashtray

E00711402279

CAUTION

Put out matches and cigarettes before they
are placed in the ashtray.

Don’t  put  papers  and  other  things  that  burn
into  your  ashtrays.  If  you  do,  cigarettes  or
other  smoking  materials  could  set  them  on
fire, causing damage.

Always close the ashtray. If left open, other
cigarette butts in the ashtray may be rekin-
dled.

To use the moveable ashtray, open the lid.

Mounting position for movea-

ble ashtray

The moveable ashtray can be fitted at the in-
dicated position.

For the front seat

For the rear seat

Cigarette lighter

E00711502603

The cigarette lighter can be used while the ig-
nition switch or the operation mode is in ON
or ACC.

1- Push all the way in.

The cigarette lighter will automatically return
to its original position with a “click” when
ready. Pull it out for use.
After use, insert the cigarette lighter to its
original position in the socket.

NOTE

Do not leave the cigarette lighter removed
from its socket, because the socket might be-
come clogged by foreign material and be
short-circuited.

Vanity mirror*

7-100

OKTE18E1

For pleasant driving

CAUTION

Do not touch the heating element or the cig-
arette lighter housing, hold the knob only to
prevent burns.

Do not allow children to operate or play with
the cigarette lighter as burns may occur.

Something is wrong with the cigarette light-
er if it does not pop back out within approxi-
mately 30 seconds of being pushed in.
Pull it out and have the problem corrected at
MITSUBISHI MOTORS Authorized Serv-
ice Point.

Do not use any electric appliance that is not
approved by MITSUBISHI MOTORS. Do-
ing so could damage the socket. If you used
the cigarette lighter after damaging the sock-
et, the cigarette lighter might pop out or fail
to come out after being pushed in.

When the cigarette lighter socket is used as a
power  source  for  an  electric  appliance,  be
sure  that  the  electric  appliance  operates  at
12 V and has an electric capacity of 120 W
or  less.  In  addition,  long  use  of  the  electric
appliance  without  running  the  engine  may
run down the battery.

Accessory socket

E00711602620

The accessory socket can be used while the
ignition switch or the operation mode is in
ON or ACC.

To use a plug-in type accessory, open the lid,
and insert the plug in the accessory socket.

CAUTION

Be sure to use a “plug-in” type accessory op-
erating at 12 V and at 120 W or less.
When  using  more  than  one  socket  at  the
same  time,  make  sure  that  the  electrical  ac-
cessories  are  12  V  accessories  and  that  the
total  power  consumption  does  not  exceed
120 W.

Long use of the electric appliance without
running the engine may run down the bat-
tery.

When the accessory socket is not in use, be
sure to close the lid, because the socket
might become clogged by foreign material
and be short-circuited.

Digital clock*

E00711801540

The digital clock indicates the time with the
ignition switch or the operation mode is in
ON or ACC.

To set the time

Set the time by pressing the various buttons
as described below.

1- To adjust the hour
2- To adjust the minutes
3- To reset the minutes to zero

10:30 - 11:29...... Changes to 11:00
11:30 - 12:29...... Changes to 12:00

Accessory socket

7-101

OKTE18E1

For pleasant driving

NOTE

If the battery cables are disconnected during
repairs or for any other reason, reset the
clock to the correct time after they are recon-
nected.

Interior lamps

E00712002399

1- Front room & map lamps*
2- Rear room lamp

NOTE

If you leave the lamps on without running
the engine, you will run down the battery.
Before you leave the vehicle, make sure that
all the lamps are off.

Room lamps

E00712102680

Front*

Rear (Type 1)*

Rear (Type 2)*

Position of

lamp switch

On/off control

1-ON

(

)

The lamp illuminates re-
gardless of whether a door
is open or closed.

Interior lamps

7-102

OKTE18E1

For pleasant driving

Position of

lamp switch

On/off control

2-DOOR

( )

Delayed off function
[Vehicles without central
door lock system]
The lamp illuminates when
a door is opened. It goes off
about 7 seconds after all
doors are closed.
However, the lamp goes off
immediately when the igni-
tion switch is turned to the
“ON” position with all
doors closed.
[Vehicles with central door
lock system]
The lamp illuminates when
a door is opened. It goes off
about 15 seconds after the
all doors are closed.
However, the lamp goes off
immediately with all doors
closed in the following ca-
ses:

Position of

lamp switch

On/off control

2-DOOR

( )

When

the

ignition

switch  is  turned  to  the
“ON”  position  or  the
operation  mode  is  put
in ON.

When the central door
lock function is used to
lock the vehicle.

When the keyless entry
key or the keyless oper-
ation key is used to
lock the vehicle.

If  the  vehicle  is  equip-
ped  with  the  keyless
operation system, when
the  keyless  operation
function is used to lock
the vehicle.

Position of

lamp switch

On/off control

2-DOOR

( )

Auto cut-out function
If the lamp is left switched
on with the ignition switch
is in the “LOCK” or “ACC”
position or the operation
mode is in OFF or ACC,
and a door is opened, it goes
off automatically after ap-
proximately 30 minutes.
The lamp will illuminate
again after it automatically
goes off in the following ca-
ses:

When

the

ignition

switch  is  turned  to  the
“ON”  position  or  the
operation  mode  is  put
in ON.

When the keyless entry
system or the keyless
operation system is op-
erated.

When all doors are
closed.

3-OFF

( )

The lamp goes off regard-
less of whether a door is
open or closed.

Interior lamps

7-103

OKTE18E1

For pleasant driving

Mitsubishi L200 (2018 year). Instruction - part 19
