Mitsubishi L200 (2018 year). Instruction

Troubleshooting

E00738401235

Please check these items if a message appears on the display, or if you think something is not working properly.

If This Message Appears...

A message is displayed on this product according to the situation.

Mode

Message

Cause

Response

CHECK DISC

The disc is inserted upside down.

Insert with the label side up.

The disc has condensation on it.

Wait a while before inserting again.

DISC ERROR

The disc is damaged.

Clean the read surface of the disc.

The disc is dirty.

INTERNAL E

The drive has malfunctioned for some reason.

Check that there is no problem with the disc, and
insert the disc again. If the problem persists,
consult a MITSUBISHI MOTORS Authorized
Service Point.

HEAT ERROR

The temperature inside the product is high.

Remove the disc, and wait for the internal tem-
perature to return to normal.

USB

FILE ERROR

Files that cannot be played are selected.

Select files that can be played.
→ “Audio Files (MP3/WMA/AAC)” (P.7-43)

USB BUS PWR

There is high or low electrical current or volt-
age.

Turn the power OFF and wait a short while. If the
problem persists, consult a MITSUBISHI
MOTORS Authorized Service Point.

LSI ERROR

There is an internal malfunction for some rea-
son.

UNSUPPORTED

FORMAT

Unsupported audio files have been played.

Confirm audio files that can be played.
→ “Audio Files (MP3/WMA/AAC)” (P.7-43)

Troubleshooting

7-72

OKTE18E1

For pleasant driving

Mode

Message

Cause

Response

USB

UNSUPPORTED DE-

VICE

An unsupported USB device has been connec-
ted.

Please connect a USB memory device.

iPod

NO SONG

An iPod/iPhone not containing any tracks has
been connected.

Connect an iPod/iPhone containing tracks.

VER ERROR

This iPod/iPhone software version is not suppor-
ted.

Please change to a supported software version.

Other

ERROR DC

An abnormal direct voltage has been sent to the
speakers.

Turn the power OFF and wait a short while. If
the problem persists, consult a MITSUBISHI
MOTORS Authorized Service Point.

Troubleshooting

7-73

OKTE18E1

For pleasant driving

If You Think Something Is Not Working Properly...

Here is a list of symptoms, causes and responses if you think something is not working properly.

Symptoms

Cause

Response

There is no sound or
quiet sound.

The volume is turned to its minimum.

Adjust the volume.
→ “Adjust Volume” (P.7-48)

The balance or fader is turned to one side.

Adjust the balance or fader.
→ “Adjust Audio Quality and Volume Balance” (P.7-36)

The disc cannot be in-
serted.

A disc is already in the product.

Eject the disc.
→ “Insert/Eject Discs” (P.7-48)

There is no disc in the product, but the product
says it is loading.

Press the eject button once.
→ “Insert/Eject Discs” (P.7-48)

The disc cannot be
played.

The disc is inserted upside down.

Insert with the label side up.

The disc has condensation on it.

Wait a while before inserting.

The disc is dirty.

Clean the read surface of the disc.

The sound skips in the
same place.

The disc is damaged or dirty.

Check the disc.

There is no sound,
even if the disc is in-
serted.

Damage to or dirt on the disc means that its
data cannot be read.

Check the disc. Additionally, if using CD-R/RW discs, their character-
istics may render them unable to be played.

Troubleshooting

7-74

OKTE18E1

For pleasant driving

Antenna

E00710500022

Pillar antenna*

E00710701151

When listening to the radio, fully extend the
antenna.

NOTE

Be sure to retract the pillar antenna in the
following cases:

•

When entering a place with low clear-
ance.

•

When using an automatic car wash.

•

When placing a car cover over the vehi-
cle.

Roof antenna*

E00710901209

When listening to the radio, raise the antenna
up until you hear it click.

Type 1

Type 2

To remove

Turn the pole (A) anticlockwise.

To install

Screw the pole (A) clockwise into the base
(B) until it is securely retained.

Type 1

Type 2

NOTE

Be sure to remove the roof antenna in the
following cases:

•

When using an automatic car wash.

•

When placing a car cover over the vehi-
cle.

•

When driving into a structure that has a
low ceiling.

Antenna

7-75

OKTE18E1

For pleasant driving

Link System*

E00764501787

The Link System takes overall control of the
devices connected via the USB input terminal
or the Bluetooth

2.0 interface allowing the

connected devices to be operated by using the
switches in the vehicle or voice commands.
See the following section for details on how
to operate.
Refer to “Bluetooth® 2.0 interface*” on page
7-76.
Refer to “USB input terminal” on page
7-95.
Refer to “Listening to an iPod” on page 7-31.
Refer to “Listen to Audio Files on a USB De-
vice” on page 7-58.
Refer to “To play iPod/USB memory device
tracks via voice operation” on page 7-60.
Refer to “Listening to Bluetooth Audio” on
page 7-63.
Bluetooth

is a registered trademark of

BLUETOOTH SIG, INC.

Link System End User Licence

Agreement

E00764600013

You have acquired a device that includes
software

licensed

MITSUBISHI

MOTORS CORPORATION from Visteon
Corporation, and their subsequent 3

party

suppliers. For a complete list of these 3

par-

ty products and their end user licence agree-
ments, please go to the following website.
http://www.jciblueconnect.com/faq/fulldi-
sclosure. pdf

Bluetooth

2.0 interface*

E00726002462

The Bluetooth

2.0 interface allows for mak-

ing/receiving hands-free calls in the vehicle
using a Bluetooth

compatible cellular phone

based on the wireless communication tech-
nology commonly known as Bluetooth

. It

also allows the user to play music, saved in a
Bluetooth

music player, from the vehicle’s

speakers.
The system is equipped with a voice recogni-
tion  function,  which  allows  you  to  make
hands-free  calls  by  simple  switch  operations
and  voice  command  operations  using  a  de-
fined voice tree.

The Bluetooth

2.0 interface can be used

when the ignition switch or the operation
mode is in ON or ACC.

Before you can use the Bluetooth

2.0 inter-

face, you must pair the Bluetooth

device

and Bluetooth

2.0 interface. Refer to “Con-

necting the Bluetooth® 2.0 interface and
Bluetooth® device” on page 7-82.

Bluetooth

is a registered trademark of

BLUETOOTH SIG, INC.

WARNING

Although the Bluetooth

2.0 interface al-

lows  you  to  make  hands-free  calls,  if  you
choose  to  use  the  cellular  phone  while
driving, you must not allow yourself to be
distracted from the safe operation of your
vehicle.  Anything,  including  cellular
phone  usage,  that  distracts  you  from  the
safe  operation  of  your  vehicle  increases
your risk of an accident.

Refer to and comply with all state and lo-
cal laws in your area regarding cellular
phone usage while driving.

Link System*

7-76

OKTE18E1

For pleasant driving

NOTE

For  vehicles  equipped  with  the  Keyless  op-
eration system, if the operation mode is left
in ACC, the accessory power will automati-
cally  turn  off  after  a  certain  period  of  time
and you will no longer be able to use the au-
dio  system.  The  accessory  power  comes  on
again if the engine switch is operated with it
in the “ACC” position. Refer to “ACC pow-
er auto-cutout function” on page 6-15.

The Bluetooth

2.0 interface cannot be used

if the Bluetooth

device has a flat battery or

the device power is turned off.

Hands-free calls will not be possible if your
phone does not have service available.

Some Bluetooth

devices are not compatible

with the Bluetooth

2.0 interface.

You can confirm the Link System software
version by pressing the HANG-UP button 3
times (press and hold 2 times and then press
briefly) within 10 seconds.

In some countries, for details of the
Bluetooth

2.0 interface, you can see them

by accessing via the MITSUBISHI
MOTORS web site.
Please read and agree on the “Warning about
Links to the Web Sites of Other Companies”
because it connects to other than
MITSUBISHI MOTORS website.
http://www.mitsubishi-motors.com/en/prod-
ucts/ index.html

Software updates by cellular phone/digital
audio device manufacturers may change/
alter device connectivity.

NOTE

For vehicles equipped with the ERA-GLO-
NASS, the Bluetooth

2.0 interface cannot

be used while an emergency call is activated.

Steering control switch and microphone

® p. 7-77
Voice recognition function

® p. 7-78

Useful voice commands

® p. 7-79

Speaker enrollment function

® p. 7-81

Connecting the Bluetooth® 2.0 interface and
Bluetooth® device

® p. 7-82

Operating a music player connected via Blue-
tooth®

® p. 7-86

How to make or receive hands-free calls

® p. 7-86
Phone book function

® p. 7-89

Steering control switch and mi-

crophone

E00727201578

Type 1

Type 2

1- Volume up button/switch
2- Volume down button/switch
3- SPEECH button
4- PICK-UP button
5- HANG-UP button
6- Microphone

Volume up button/switch

Used to increase the volume.

Bluetooth

2.0 interface*

7-77

OKTE18E1

For pleasant driving

Volume down button/switch

Used to decrease the volume.

SPEECH button

Press this button to change to voice rec-
ognition mode.
While the system is in voice recognition
mode, “Listening” will appear on the au-
dio display.

If you press the button briefly while in
voice recognition mode, it will interrupt
prompting and allow voice command in-
put.
Pressing the button longer will deacti-
vate the voice recognition mode.

Pressing this button briefly during a call
will enable voice recognition and allow
voice command input.

PICK-UP button

Press this button when an incoming call
is received to answer the telephone.

When another call is received during a
call, press this button to put the first call-
er on hold and talk to the new caller.

• In such circumstances, you can press

the  button  briefly  to  switch  between
callers.  You  will  switch  to  the  first
caller  and  the  other  caller  will  be  put
on hold.

• To establish a three-way call in such

situations, press the SPEECH button
to enter voice recognition mode and
then say “Join calls”.

HANG-UP button

Press this button when an incoming call
is received to refuse the call.

Press this button during a call to end the
current call.
When another call is on hold, you will
switch to that call.

If this button is pressed in the voice rec-
ognition mode, the voice recognition
mode will be deactivated.

NOTE

When you press the SPEECH button to enter
voice recognition mode with a cellular
phone paired to the system, current informa-
tion on the cellular phone, such as “remain-
ing battery life”, “signal strength” or “roam-
ing”, will be displayed on the audio display.

Call waiting and three-way calls can be used
by the Bluetooth

2.0 interface, only if it is

possible to use those services with your cel-
lular phone.

Some cellular phones will not send this informa-

tion to the Bluetooth

2.0 interface.

Microphone

Your voice will be recognized by a micro-
phone in the overhead console, allowing you
to make hands-free calls with voice com-
mands.

NOTE

If a cellular phone is brought close to the mi-
crophone, it may create noise in the voice on
the phone. In such a case, take the cellular
phone at a place as far as possible from the
microphone.

Voice recognition function

E00727300514

The Bluetooth

2.0 interface is equipped

with a voice recognition function.
Simply say voice commands and you can
perform various operations and make or re-
ceive hands-free calls.

With the Bluetooth

2.0 interface, voice rec-

ognition is possible for English, French,
Spanish, Italian, German, Dutch, Portuguese
and Russian. The factory setting is “English”
or “Russian.”

Bluetooth

2.0 interface*

7-78

OKTE18E1

For pleasant driving

NOTE

If  the  voice  command  that  you  say  differs
from  the  predefined  command  or  cannot  be
recognised  due  to  ambient  noise  or  some
other  reason,  the  Bluetooth

2.0 interface

will ask you for the voice command again up
to 3 times.

For best performance and further reduction
of ambient noise, close the vehicle windows,
lower the blower speed and refrain from
conversation with your passengers while en-
gaging the voice recognition function.

Some voice commands have alternative
commands.

Depending on the selected language, some
functions may not be available.

Selecting the Language

1. Press the SPEECH button.
2. Say “Setup”.
3. Say “Language”.
4. The voice guide will say “Select a lan-

guage: English, French, Spanish, Italian,
German, Dutch, Portuguese or Russian”
Say the desired language. (Example:
“English”)

5. The voice guide will say “English

(French,  Spanish,  Italian,  German,
Dutch,  Portuguese  or  Russian)  selected.
Is this correct?” Say “Yes”.
If  you  say  “No,”  the  system  will  return
to Step 4.

NOTE

The voice guide will repeat the same mes-
sage twice. The first message is in the cur-
rent language, and the second message is in
the selected language.

If many entries are registered in the vehicle
phone book, changing the language will take
longer.

Changing the language deletes the mobile
phone book imported to the Bluetooth

2.0

interface. If you wish to use it, you will have
to import it again.

6. When the voice guide says “English

(French, Spanish, Italian, German,
Dutch, Portuguese or Russian) selected”,
the language change process will be
completed and the system will return to
the main menu.

Useful voice commands

E00760000019

Help function

E00760100010

The Bluetooth

2.0 interface is equipped

with a help function.
If you say “Help” when the system is waiting
for a voice command input, the system will
tell you a list of the commands that can be
used under the circumstances.

Cancelling

E00760201148

There are two cancel functions.
If you are at the main menu, say “Cancel” to
exit from the Bluetooth

2.0 interface.

If you are anywhere else within the system,
say “Cancel” to return to the main menu.

NOTE

You can return to the previous menu by say-
ing “Go Back.”

Confirmation function setting

E00760400013

The Bluetooth

2.0 interface is equipped

with a confirmation function.
With the confirmation function activated, you
are given more opportunities than normal to
confirm a command when making various
settings to the Bluetooth

2.0 interface. This

allows you to decrease the possibility that a
setting is accidentally changed.
The confirmation function can be turned on
or off by following the steps below.

1. Press the SPEECH button.
2. Say “Setup”.
3. Say “Confirmation prompts”.
4. The voice guide will say “Confirmation

prompts are <on/off>. Would you like to
turn confirmation prompts <off/on>.”
Answer “Yes” to change the setting or
answer “No” to keep the current setting.

Bluetooth

2.0 interface*

7-79

OKTE18E1

For pleasant driving

5. The voice guide will say “Confirmation

prompts are <off/on>” and then the sys-
tem will return to the main menu.

Security function

E00760501369

It is possible to use a password as a security
function by setting a password of your choice
for the Bluetooth

2.0 interface.

When the security function is turned on, it is
necessary to make a voice input of a 4-digit
password in order to use all functions of the
Bluetooth

2.0 interface, except for recep-

tion.

Setting the password
Use the following procedure to turn on the
security function by setting a password.

1. Press the SPEECH button.
2. Say “Setup”.
3. Say “Password.”
4. The voice guide will say “Password is

disabled. Would you like to enable it?”
Answer “Yes.”
Answer “No” to cancel the setting of the
password and return to the main menu.

5. The voice guide will say “Please say a 4-

digit password. Remember this pass-
word. It will be required to use this sys-
tem.”
Say a 4-digit number which you want to
set as a password.

6. For confirmation purposes, the voice

guide will say “Password <4-digit pass-
word>. Is this correct?” Answer “Yes.”
Answer “No” to return to the password
input in Step 5.

7. When the registration of the password is

completed, the voice guide will say
“Password is enabled” and the system
will return to the main menu.

NOTE

Password will be required to access the sys-
tem after the next ignition cycle.

It is required for a little time after engine
stop that the entered password is actually re-
corded in the system.
If the ignition switch or the operation mode
is made to ACC or ON or the engine is star-
ted immediately after engine stop, there is a
case when the entered password is not recor-
ded in the system. At this time, please try to
enter the password again.

Entering the password
If a password has been set and the security
function is enabled, the voice guide will say
“Hands-free system is locked. State the pass-
word to continue” when the SPEECH button
is pressed to enter voice recognition mode.
Say the 4-digit password number to enter the
password.

If the entered password is wrong, the voice
guide will say “<4-digit password>, Incorrect
password. Please try again.” Enter the correct
password.

NOTE

You can re-enter the password as many
times as you want.

If  you  have  forgotten  your  password,  say
“Cancel”  to  quit  the  voice  input  mode  and
then  check  with  a  MITSUBISHI  MOTORS
Authorized Service Point.

Disabling the password
Use the following procedure to turn off the
security function by disabling the password.

NOTE

System must be unlocked to disable the
password.

1. Press the SPEECH button.
2. Say “Setup”.
3. Say “Password.”
4. The voice guide will say “Password is

enabled.  Would  you  like  to  disable  it?”
Answer “Yes.”
Answer  “No”  to  cancel  the  disabling  of
the  password  and  return  to  the  main
menu.

Bluetooth

2.0 interface*

7-80

OKTE18E1

For pleasant driving

5. When the disabling of the password is

completed, the voice guide will say
“Password is disabled” and the system
will return to the main menu.

Speaker enrollment function

E00727401264

The Bluetooth

2.0 interface can use the

speaker enrollment function to create a voice
model for one person per language.
This makes it easier for the Bluetooth

2.0

interface  to  recognise  voice  commands  said
by you.
You  can  turn  a  voice  model  registered  with
the  speaker  enrollment  function  on  and  off
whenever you want.

Speaker enrollment

E00727501340

It takes about 2 to 3 minutes to complete the
speaker enrollment process.
To  ensure  the  best  results,  run  through  the
process while in the driver’s seat, in an envi-
ronment  that  is  as  quiet  as  possible  (when
there is no rain or strong winds and the vehi-
cle windows are closed). Please turn off your
phone while in speaker enrollment to prevent
interruption of the process.
Use  the  following  procedure  for  speaker  en-
rollment.

1. Stop your vehicle in a safe area, put the

gearshift lever (M/T) in the “N” (Neu-
tral) position, or the selector lever (A/T)

in the “P” (PARK) position, and pull the
parking brake lever.

NOTE

Speaker enrollment is not possible unless the
vehicle is parked. Make sure you park the
vehicle in a safe area before attempting
speaker enrollment.

2. Press the SPEECH button.
3. Say “Voice training”.
4. The voice guide will say “This operation

must  be  performed  in  a  quiet  environ-
ment  while  the  vehicle  is  stopped.  See
the  owner’s  manual  for  the  list  of  re-
quired  training  phrases.  Press  and  re-
lease the SPEECH button when you are
ready to begin. Press the HANG-UP but-
ton to cancel at any time”.
Press  the  SPEECH  button  to  start  the
speaker enrollment process.

NOTE

If  you  do  not  start  the  speaker  enrollment
process  within  3  minutes  of  pressing  the
SPEECH  button,  the  speaker  enrollment
function will time out.
The  voice  guide  will  say  “Speaker  enroll-
ment  has  timed  out.”  The  system  will  then
beep and the voice recognition mode will be
deactivated.

5. The voice guide will prompt for phrase

1.  Repeat  the  corresponding  phrase  lis-
ted  in  table  “Enrollment  commands”  on
page 7-95.
The system will register your voice and
then  move  on  to  the  registration  of  the
next command. Continue the process un-
til all phrases have been registered.

NOTE

To repeat the most recent voice training
command, press and release the SPEECH
button.

If you press the HANG-UP button anytime
during the process, the system will beep and
stop the speaker enrollment process.

6. When all enrollment commands have

been  read  out,  the  voice  guide  will  say
“Speaker  enrollment  is  complete.”  The
system will then end the speaker enroll-
ment  process  and  return  to  the  main
menu.

NOTE

Completing the speaker enrollment process
will turn on the voice model automatically.

The commands “Help” and “Cancel” will
not work in this mode.

Bluetooth

2.0 interface*

7-81

OKTE18E1

For pleasant driving

Enabling and disabling the
voice model and retraining

E00727601149

You can turn a voice model registered with
the speaker enrollment function on and off
whenever you want.
You can also retrain the system.
Use the following procedure to perform these
actions.

1. Press the SPEECH button.
2. Say “Voice training”.
3. If you have completed a speaker enroll-

ment  process  once  already,  the  voice
guide will say either “Enrollment is ena-
bled.  Would  you  like  to  disable  or  re-
train?”  or  “Enrollment  is  disabled.
Would you like to enable or retrain?”

4. When enrollment is “enabled,” the voice

model  is  on;  when  enrollment  is  “disa-
bled,”  the  voice  model  is  off.  Say  the
command that fits your needs.
Say “Retrain” to start the speaker enroll-
ment  process  and  recreate  a  new  voice
model.  (Refer  to  “Speaker  enrollment”
on page 7-81.)

Connecting the Bluetooth

2.0

interface and Bluetooth

de-

vice

E00760601777

Before you can make or receive hands-free
calls or play music using the Bluetooth

2.0

interface function, you must pair the Blue-
tooth

device and Bluetooth

2.0 interface.

NOTE

Pairing  is  required  only  when  the  device  is
used  for  the  first  time.  Once  the  device  has
been  paired  with  the  Bluetooth

2.0 inter-

face, all you need is to bring the device into
the vehicle next time and the device will
connect to the Bluetooth

2.0 interface auto-

matically (if supported by the device). The
device must have Bluetooth

turned ON to

connect.

Up to 7 Bluetooth

devices can be paired

with the Bluetooth

2.0 interface.

If multiple paired Bluetooth

devices are

available in the vehicle, the cellular phone or
music player most recently connected is auto-
matically connected to the Bluetooth

2.0 in-

terface.

You can also change a Bluetooth

device to

be connected.

To pair

To pair a Bluetooth

device with the Blue-

tooth

2.0 interface, follow the steps below.

1. Stop your vehicle in a safe area, put the

gearshift lever in the “N” (Neutral) posi-
tion (M/T), or the selector lever in the
“P” (PARK) position (A/T), and pull the
parking brake lever.

NOTE

You cannot pair any Bluetooth

device with

the Bluetooth

2.0 interface unless the vehi-

cle is parked. Before pairing a Bluetooth

device with the Bluetooth

2.0 interface,

confirm that the vehicle is parked in a safe
location.

2. Press the SPEECH button.
3. Say “Pair Device.”

Bluetooth

2.0 interface*

7-82

OKTE18E1

For pleasant driving

NOTE

The following procedure (

) can also

be used instead of saying “Pair Device.”
Replace this step 3 with the following proce-
dure if you prefer.

Say “Setup.”
Say “Pairing Options.”
The voice guide will say “Select one of

the following: pair, edit, delete, list or set
code.”
Say “Pair.”

If  7  devices  have  already  been  paired,  the
voice  guide  will  say  “Maximum  devices
paired”  and  then  the  system  will  end  the
pairing  process.  To  register  a  new  device,
delete one device and then repeat the pairing
process.
(Refer to “Selecting a device: Deleting a de-
vice” on page 7-84.)

4. The voice guide will say “Start pairing

procedure on the device. See the device
manual for instructions.” and then will
say “The pairing code is <pairing
code>.”

NOTE

Some Bluetooth

devices require a specific

pairing code. Please refer to the device man-
ual  for  pairing  code  requirements  and  read
the  next  section  “If  your  device  requires  a
specific  pairing  code”  on  page  7-83  to  set
the pairing code.

NOTE

The pairing code entered here is only used
for the Bluetooth

connection certification.

Depending on the connection settings of the
Bluetooth

device, this code may have to be

entered each time you connect the Blue-
tooth

device to the Bluetooth

2.0 inter-

face. For the default connection settings, re-
fer to the instructions for the device.

5. Enter in the Bluetooth

device the 4-dig-

it number that has been read out in Step
4.

NOTE

According to the corresponding device to
Bluetooth

, it might take a few minute to

pair the Bluetooth

device with the Blue-

tooth

2.0 interface.

If the Bluetooth

2.0 interface cannot recog-

nise the Bluetooth

device, the voice guide

will say “Pairing has timed out” and the
pairing process will be cancelled.
Confirm that the device you are pairing sup-
ports Bluetooth

, and try pairing it again.

NOTE

If  you  enter  the  wrong  number,  the  voice
guide will say “Pairing failed” and the pair-
ing process will be cancelled.
Confirm the number is right, and try pairing
it again.
If  your  device  requires  a  specific  pairing
code, you need to set the pairing code. Refer
to  the  device  manual  for  pairing  code  re-
quirements  and  read  the  next  section  “If
your device requires a specific pairing code”
on page 7-83.

6. The voice guide will say “Please say the

name of the device after the beep.” You
can assign a desired name for the Blue-
tooth

device and register it as a device

tag. Say the name you want to register
after the beep.

NOTE

When  the  confirmation  function  is  on,  after
repeating  the  device  tag  you  have  said,  the
voice  guide  will  ask  “Is  this  correct?”  An-
swer “Yes.”
To change the device tag, answer “No” and
then say the device tag again.

Bluetooth

2.0 interface*

7-83

OKTE18E1

For pleasant driving

7. The voice guide will say “Pairing Com-

plete. Would you like to import the con-
tacts  from  your  mobile  device  now?”
Answer “Yes,” and the voice guide will
say  “Please  wait  while  the  contacts  are
imported.  This  may  take  several  mi-
nutes.”  Answer  “No”  to  end  the  pairing
process.

If  your  device  requires  a  specific  pairing
code
If  your  device  requires  a  specific  pairing
code,  you  need  to  set  the  pairing  code.  Fol-
low the procedures below.

1. Press the SPEECH button.
2. Say “Setup.”
3. Say “Pairing Options.”
4. Say “Set Code.”
5. The voice guide will say “Do you want

the pairing code to be random or fixed?”
Say “Fixed.”

6. The voice guide will say “Please say a 4-

digit pairing code.” Say a 4-digit num-
ber.

7. The voice guide will say “Pairing code

set to <pairing code>.”
When  the  confirmation  function  is  on,
the  system  will  confirm  whether  the
number  said  is  acceptable.  Answer
“Yes.”
Answer “No” to return to Step 6.

8. The voice guide will say “Do you want

to pair a device now?” Answer “Yes,”
the system will proceed to Step 3 in the
pairing process. Refer to the section “To
pair”.

Selecting a device

E00760700104

If multiple paired Bluetooth

devices are

available in the vehicle, the cellular phone or
music player most recently connected is auto-
matically connected to the Bluetooth

2.0 in-

terface.
You can connect to the other paired cellular
phone or music player by following setting
change procedures.

To select a cellular phone

1. Press the SPEECH button.
2. Say “Setup”.
3. Say “Select phone.”
4. After the voice guide says “Please say,”

the  numbers  of  the  cellular  phones  and
device  tags  of  corresponding  cellular
phones will be read out in order, starting
with  the  cellular  phone  that  has  been
most recently connected.
Say  the  number  of  the  cellular  phone
that you want to connect to.
When  the  confirmation  function  is  on,
the  system  will  ask  you  again  whether
the phone that you want to connect to is

correct. Answer “Yes” to continue and
connect to the cellular phone.
Answer “No,” and the voice guide will
say “Please say.” Say the number of the
phone that you want to connect to.

NOTE

You can connect to a phone at any time by
pressing the SPEECH button and saying the
number, even before all of the paired num-
bers and device tags of corresponding cellu-
lar phones are read out by the system.

5. The selected phone will be connected to

the Bluetooth

2.0 interface. The voice

guide will say “<device tag> selected”
and then the system will return to the
main menu.

To select a music player

1. Press the SPEECH button.
2. Say “Setup”.
3. Say “Select music player.”
4. After the voice guide says “Please say,”

the numbers of the music players and de-
vice tags of corresponding music players
will be read out in order, starting with
the music player that has been most re-
cently connected.
Say the number of the music player that
you want to connect to.

Bluetooth

2.0 interface*

7-84

OKTE18E1

For pleasant driving

When  the  confirmation  function  is  on,
the  system  will  ask  you  again  whether
the  music  player  that  you  want  to  con-
nect to is correct. Answer “Yes” to con-
tinue and connect to the music player.
Answer  “No,”  and  the  voice  guide  will
say “Please say.” Say the number of the
music  player  that  you  want  to  connect
to.

NOTE

You  can  connect  to  a  music  player  at  any
time  by  pressing  the  SPEECH  button  and
saying  the  number,  even  before  all  of  the
paired  numbers  and  device  tags  of  corre-
sponding  music  players  are  read  out  by  the
system.

5. The selected music player will be con-

nected to the Bluetooth

2.0 interface.

The voice guide will say “<device tag>
selected” and then the system will return
to the main menu.

Deleting a device
Use the following procedure to delete a
paired Bluetooth

device from the Bluetooth

2.0 interface.

1. Press the SPEECH button.
2. Say “Setup.”
3. Say “Pairing Options.”

4. The voice guide will say “Select one of

the following: pair, edit, delete, or list.”
Say “Delete.”

5. After the voice guide says “Please say,”

the  numbers  of  the  devices  and  device
tags  of  corresponding  devices  will  be
read  out  in  order,  starting  with  the  de-
vice that has been most recently connec-
ted. After it completes reading all pairs,
the voice guide will say “or all.”
Say  the  number  of  the  device  that  you
want to delete from the system.
If  you  want  to  delete  all  paired  phones
from the system, say “All.”

6. For confirmation purposes, the voice

guide will say “Deleting <device tag>
<number>. Is this correct?” or “Deleting
all devices. Is this correct?”
Answer “Yes” to delete the phone(s).
Answer “No” to return to Step 4.

7. The voice guide will say “Deleted,” and

then the system will end the device dele-
tion process.

NOTE

If the device deletion process fails for some
reason, the voice guide will say “Delete
failed” and then the system will cancel delet-
ing the device.

To check a paired Bluetooth

device

E00760800017

You can check a paired Bluetooth

device by

following the steps below.

1. Press the SPEECH button.
2. Say “Setup”.
3. Say “Pairing options”.
4. The voice guide will say “Select one of

the following: pair, edit, delete, or list.”
Say “List”.

5. The voice guide will read out device tags

of corresponding devices in order, start-
ing with the Bluetooth

device that has

been most recently connected.

6. After the device tags of all paired Blue-

tooth

devices have been read, the sys-

tem will say “End of list, would you like
to start from the beginning?”
To hear the list again from the begin-
ning, answer “Yes”.
When you are done, answer “No” to re-
turn to the main menu.

Bluetooth

2.0 interface*

7-85

OKTE18E1

For pleasant driving

NOTE

If you press and release the SPEECH button
and say “Continue” or “Previous” while the
list is being read, the system will advance or
rewind the list.
Say  “Continue”  to  proceed  to  the  device
with  the  next  highest  number  or  “Previous”
to  return  to  the  phone  with  the  previous
number.

You can change the device tag by pressing
and releasing the SPEECH button and then
saying “Edit” while the list is being read.

You can change the phone to be connected
by pressing and releasing the SPEECH but-
ton and then saying “Select phone” while the
list is being read.

You can change the music player to be con-
nected by pressing and releasing the
SPEECH button and then saying “Select mu-
sic player” while the list is being read.

Changing a device tag

E00760900018

You can change the device tag of a paired
cellular phone or music player.
Follow the steps below to change a device
tag.

1. Press the SPEECH button.
2. Say “Setup”.
3. Say “Pairing options”.
4. The voice guide will say “Select one of

the following: pair, edit, delete, or list.”
Say “Edit”.

5. The voice guide will say “Please say,”

and read out the numbers of the Blue-
tooth

devices and device tags of corre-

sponding devices in order, starting with
the Bluetooth

that has been most re-

cently connected.
After  all  paired  device  tags  have  been
read,  the  voice  guide  will  say  “Which
device,  please?”  Say  the  number  of  the
device tag you want to change.

NOTE

You can press and release the SPEECH but-
ton while the list is being read, and immedi-
ately say the number of the device tag you
want to change.

6. The voice guide will say “New name,

please”. Say the name you want to regis-
ter as a new device tag.
When the confirmation function is on,
the voice guide will say “<New device
tag>. Is this correct?” Answer “Yes”.
Answer “No”, to say the new device tag
you want to register again.

7. The device tag is changed.

When the change is complete, the voice
guide will say “New name saved” and
then the system will return to the main
menu.

Operating a music player con-
nected via Bluetooth

E00761001505

For the operation of a music player connected
via Bluetooth

, refer to “Listen to Bluetooth

Audio”  on  page  7-63.  On  vehicles  equipped
with  the  MITSUBISHI  Multi-Communica-
tion System (MMCS), Smartphone Link Dis-
play  Audio  or  DISPLAY  AUDIO,  refer  to
the separate owner’s manual.

How to make or receive hands-

free calls

E00761100059

You can make or receive hands-free calls us-
ing a Bluetooth

compatible cellular phone

connected to the Bluetooth

2.0 interface.

You can also use the phone books in the
Bluetooth

2.0 interface to make calls with-

out dialling telephone numbers.

“To make a call” on page 7-87
“SEND function” on page 7-88
“Receiving calls” on page 7-88
“MUTE function” on page 7-88
“Switching between hands-free mode and
private mode” on page 7-89

Bluetooth

2.0 interface*

7-86

OKTE18E1

For pleasant driving

NOTE

The hands-free calls might not be operated
correctly when it makes calling or receiving
by operating the cellular phone directly.

To make a call

E00761200148

You can make a call in the following 3 ways
using the Bluetooth

2.0 interface:

Making a call by saying a telephone number,
making a call using the Bluetooth

2.0 inter-

face’s phone book, and making a call by re-
dialing.

Making a call by using the telephone num-
ber
You can make a call by saying the telephone
number.

1. Press the SPEECH button.
2. Say “Dial.”
3. After the voice guide says “Number

please”, say the telephone number.

4. The voice guide will say “Dialing <num-

ber recognised>”.
The Bluetooth

2.0 interface will then

make the call.
When  the  confirmation  function  is  on,
the  system  will  confirm  again  the  tele-
phone  number.  To  continue  with  that
number, answer “Yes”.
To change the telephone number, answer
“No”.  The  system  will  say  “Number

please” then say the telephone number
again.

NOTE

In the case of English, the system will recog-
nise both “zero” and “oh” (Letter “o”) for
the number “0”.

The Bluetooth

2.0 interface supports num-

bers (0 to 9) and characters (+, # and *).

The maximum supported telephone number
length is as follows:

•

International telephone number: + and tel-
ephone numbers (to 18 digits).

•

Except for international telephone num-
ber: telephone numbers (to 19 digits).

Making a call using a phone book
You can make calls using the vehicle phone
book or mobile phone book of the Blue-
tooth

2.0 interface.

For details on the phone books, refer to
“Phone book function” on page 7-89.

1. Press the SPEECH button.
2. Say “Call”.

NOTE

If you say “Call” when the vehicle phone
book and the mobile phone book are empty,
the voice guide will say “The vehicle phone
book is empty. Would you like to add a new
entry now?”
Answer “Yes”, and the voice guide will say
“Entering the phone book - new entry
menu”. You can now create data in the vehi-
cle phone book.
Answer “No”, to return to the main menu.

3. After the voice guide says “Name

please”, say the name you want to call,
from those registered in the phone book.

4. If there is only one match, the system

proceeds to step 5.
If  there  are  two  or  more  matches,  the
voice  guide  will  say  “More  than  one
match was found, would you like to call
<returned  name>”.  If  that  person  is  the
one you want to call, answer “Yes”.
Answer “No”, and the name of the next
matching  person  will  be  uttered  by  the
voice guide.

NOTE

If you say “No” to all names read by the sys-
tem, the voice guide will say “Name not
found, returning to main menu” and the sys-
tem will return to the main menu.

Bluetooth

2.0 interface*

7-87

OKTE18E1

For pleasant driving

Mitsubishi L200 (2018 year). Instruction - part 18
