Mitsubishi L200 (2018 year). Instruction

The wipers will operate once if the lever is
moved to the “AUTO” position and the knob
(C) is turned in the “+” direction when the ig-
nition switch is in the “ON” position or the
operation mode is in ON.

Windscreen washer

E00507202421

The  washer  fluid  will  be  sprayed  onto  the
windscreen by pulling the lever towards you.
The  wipers  operate  automatically  several
times while the washer fluid is being sprayed.
On vehicles equipped with a headlamp wash-
er, while the headlamps are on, the headlamp
washer  will  operate  once  together  with  the
windscreen washer.

CAUTION

If  the  washer  is  used  in  cold  weather,  the
washer  fluid  sprayed  against  the  glass  may
freeze  resulting  in  poor  visibility.  Heat  the
glass  with  the  defroster  or  demister  before
using the washer.

Headlamp washer switch*

E00510101629

The headlamp washer can be operated with
the ignition switch or the operation mode in
ON or ACC and the lamp switch at the “

”

position.

Push the button once and the washer fluid
will be sprayed on to the headlamps.

NOTE

If the ignition switch or the operation mode
is in ON or ACC and the headlamps are on,
the headlamp washer operates together with
the windscreen washer the first time the
windscreen washer lever is pulled.

Wiper and washer switch

5-26

OKTE18E1

Instruments and controls

Precautions to observe when

using wipers and washers

E00507601473

If  the  moving  wipers  become  blocked
partway through a sweep by ice or other
deposits  on  the  glass,  the  wipers  may
temporarily stop operating to prevent the
motor  from  overheating.  In  this  case,
park the vehicle in a safe place, turn the
ignition  switch  to  the  “LOCK”  position
or  put  the  operation  mode  in  OFF,  and
then  remove  the  ice  or  other  deposits.
The wipers will start operating again af-
ter  the  wiper  motor  cools  down,  so
check that the wipers operate before us-
ing them.

Do not use the wipers when the glass is
dry.
They may scratch the glass surface and
the blades wear out prematurely.

Before using the wipers in cold weather,
check that the wiper blades are not fro-
zen onto the glass. The motor may burn
out if the wipers are used with the blades
frozen onto the glass.

Avoid using the washer continuously for
more than 20 seconds. Do not operate
the washer when the fluid reservoir is
empty.
Otherwise, the motor may burn out.

Periodically  check  the  level  of  washer
fluid  in  the  reservoir  and  refill  if  re-
quired.
During  cold  weather,  add  a  recommen-
ded  washer  solution  that  will  not  freeze
in the washer reservoir. Failure to do so
could  result  in  loss  of  washer  function
and  frost  damage  to  the  system  compo-
nents.

Rear window demister
switch

E00507902604

The rear window demister switch can be op-
erated when the engine is running.
Push  the  switch  to  turn  on  the  rear  window
demister.  It  will  be  turned  off  automatically
in about 20 minutes. To turn off the demister
within  about  20  minutes,  push  the  switch
again.

The indication lamp (A) will illuminate while
the demister is on.

Type 1

Type 2

Rear window demister switch

5-27

OKTE18E1

Instruments and controls

NOTE

On  vehicles  equipped  with  heated  mirrors,
when  the  rear  window  demister  switch  is
pressed,  the  outside  rear-view  mirrors  are
defogged or defrosted. Refer to “Heated mir-
ror*” on page 6-12.

The demister switch is not to melt snow but
to clear mist. Remove snow before use of
the demister switch.

To  avoid  unnecessary  discharge  of  the  bat-
tery,  do  not  use  the  rear  window  demister
during starting of the engine or when the en-
gine  is  not  running.  Turn  the  demister  off
immediately after the window is clear.

When cleaning the inside of the rear win-
dow, use a soft cloth and wipe gently along
the heater wires, being careful not to damage
the wires.

Do not allow objects to touch the inside of
the rear window glass, damaged or broken
wires may result.

Customizing the automatic

rear window demister (Vehi-

cles equipped with the rear

window demister switch - Type

Function can be changed as desired, as stated
below.

Enable  automatic  rear  window  demister
If  the  outside  air  temperature  drops  be-
low  approx.  3  °C  (37  °F),  the  rear  win-
dow demister operates once automatical-
ly after the engine starts.
The  heated  mirrors  will  also  operate
once automatically at the same time.

Disable automatic rear window demister
The rear window demister does not op-
erate automatically.
The heated mirrors will not operate auto-
matically as well.

Setting change method
Hold down the rear window demister
switch for about 10 seconds or more.

• When the setting is changed from ena-

ble to disable:
3 sounds are emitted and the indica-
tion lamp flashes 3 times.

• When the setting is changed from dis-

able to enable:
2 sounds are emitted and the indica-
tion lamp flashes 3 times.

NOTE

The factory setting is “Disable automatic
rear window demister”.

Horn switch

E00508001823

Press the steering wheel on or around the
“ ” mark.

Type 1

Type 2

Horn switch

5-28

OKTE18E1

Instruments and controls

Economical driving

E00600102608

For economical driving, there are some tech-
nical  requirements  that  have  to  be  met.  The
prerequisite  for  low  fuel  consumption  is  a
properly adjusted engine. In order to achieve
longer  life  of  the  vehicle  and  the  most  eco-
nomical  operation,  we  recommend  you  to
have the vehicle checked at regular intervals
in accordance with the service standards.
Fuel economy and generation of exhaust gas
and  noise  are  highly  influenced  by  personal
driving habits as well as the particular operat-
ing  conditions.  The  following  points  should
be  observed  in  order  to  minimize  wear  of
brakes, tyres and engine as well as to reduce
environmental pollution.

Accelerating and decelerating

Drive according to the traffic conditions and
avoid sudden starts, sudden acceleration and
sudden braking, as they will increase fuel
consumption.

Shifting

Shift only at an appropriate speed and engine
speed. Always use the highest shift position
possible.

The transfer shift lever or the drive mode-se-
lector should be set to “2H” when driving
4WD vehicles on normal roads and express
ways to obtain best possible fuel economy.

City traffic

Frequent  starting  and  stopping  increases  the
average  fuel  consumption.  Use  roads  with
smooth traffic flow whenever possible. When
driving  on  congested  roads,  avoid  use  of  a
low shift position at high engine speeds.

Idling

The vehicle consumes fuel even during
idling. Avoid extended idling whenever pos-
sible.

Speed

At  higher  vehicle  speed,  more  fuel  is  con-
sumed.  Avoid  driving  at  full  speed.  Even  a
slight  release  of  the  accelerator  pedal  will
save a significant amount of fuel.

Tyre inflation pressure

Check  the  tyre  inflation  pressures  at  regular
intervals. Low tyre inflation pressure increa-
ses  road  resistance  and  fuel  consumption.  In
addition,  low  tyre  pressures  adversely  affect
tyre wear and driving stability.

Cargo loads

Do not drive with unnecessary articles in the
luggage compartment. Especially during city
driving where frequent starting and stopping
is necessary, the increased weight of the ve-
hicle will greatly affect fuel consumption. Al-
so avoid driving with unnecessary luggage or
carriers, etc., on the roof; the increased air re-
sistance will increase fuel consumption.

Cold engine starting

Starting of a cold engine consumes more
fuel. Unnecessary fuel consumption is also
caused by keeping a hot engine running. Af-
ter the engine is started, commence driving as
soon as possible.

Cooler or air conditioning

The use of the air conditioner will increase
the fuel consumption.

Driving, alcohol and drugs

E00600200070

Driving after drinking alcohol is one of the
most frequent causes of accidents.

Economical driving

6-02

OKTE18E1

Starting and driving

Your  driving  ability  can  be  seriously  im-
paired even with blood alcohol levels far be-
low  the  legal  minimum.  If  you  have  been
drinking, don’t drive. Ride with a designated
non-drinking driver, call a cab or a friend, or
use public transportation. Drinking coffee or
taking  a  cold  shower  will  not  make  you  so-
ber.
Similarly,  prescription  and  nonprescription
drugs affect your alertness, perception and re-
action  time.  Consult  with  your  doctor  or
pharmacist before driving while under the in-
fluence of any of these medications.

WARNING

NEVER DRINK AND DRIVE.
Your perceptions are less accurate, your
reflexes are slower and your judgment is
impaired.

Safe driving techniques

E00600300446

Driving safety and protection against injury
cannot be fully ensured. However, we recom-
mend that you pay extra attention to the fol-
lowing:

Seat belts

Before starting the vehicle, make sure that
you and your passengers have fastened your
seat belts.

Floor mats

WARNING

Keep floor mats clear of the pedals by
correctly laying floor mats that are suita-
ble for the vehicle.
To prevent the floor mats from slipping
out of position, securely retain them using
the hook etc.
Note that laying a floor mat over a pedal
or laying one floor mat on top of another
can obstruct pedal operation and lead to a
serious accident.

Carrying children in the vehi-

cle

Never leave your vehicle unattended
with the key and children inside the ve-
hicle. Children may play with the driv-
ing controls and this could lead to an ac-
cident.

Make  sure  that  infants  and  small  chil-
dren  are  properly  restrained  in  accord-
ance  with  the  laws  and  regulations,  and
for  maximum  protection  in  case  of  an
accident.

Prevent children from playing in the lug-
gage compartment. It is quite dangerous
to allow them to play there while the ve-
hicle is moving.

Loading luggage

When loading luggage, be careful not to load
above the height of seats. This is dangerous
not only because rearward vision will be ob-
structed, but also the luggage may be projec-
ted into the passenger compartment under
hard braking.

Safe driving techniques

6-03

OKTE18E1

Starting and driving

Running-in recommendations

E00600404315

During the running-in period for the first 1,000 km (620 miles), it is advisable to drive your new vehicle using the following precautions as a
guideline to aid long life as well as future economy and performance.

Do not race the engine at high speeds.

Avoid rapid starting, accelerating, braking and prolonged high-speed running.

Keep to the running-in speed limit shown below.
Please note that the legal speed limits displayed must be adhered to.

Do not exceed loading limits.

Refrain from towing a trailer.

Vehicles with M/T

Shift point

Speed limit

2WD

Vehicles with Easy Select 4WD

Vehicles with Super Select 4WD II

2H, 4H

2H, 4H, 4HLc

4LLc

gear

20 km/h (12 mph)

5 km/h (3 mph)

20 km/h (12 mph)

5 km/h (3 mph)

gear

40 km/h (25 mph)

15 km/h (9 mph)

40 km/h (25 mph)

15 km/h (9 mph)

gear

65 km/h (40 mph)

25 km/h (16 mph)

65 km/h (40 mph)

25 km/h (16 mph)

gear

95 km/h (59 mph)

35 km/h (22 mph)

95 km/h (59 mph)

35 km/h (22 mph)

gear

110 km/h (68 mph)

45 km/h (28 mph)

115 km/h (71 mph)

45 km/h (28 mph)

gear

55 km/h (34 mph)

Running-in recommendations

6-04

OKTE18E1

Starting and driving

Vehicles with A/T

Shift point

Speed limit

2WD

Vehicles with Easy Select 4WD

Vehicles with Super Select 4WD II

2H, 4H

2H, 4H, 4HLc

4LLc

gear

15 km/h (9 mph)

5 km/h (3 mph)

20 km/h (12 mph)

5 km/h (3 mph)

gear

35 km/h (22 mph)

15 km/h (9 mph)

40 km/h (25 mph)

15 km/h (9 mph)

gear

55 km/h (34 mph)

20 km/h (12 mph)

60 km/h (37 mph)

20 km/h (12 mph)

gear

85 km/h (53 mph)

30 km/h (19 mph)

85 km/h (53 mph)

30 km/h (19 mph)

gear

110 km/h (68 mph)

45 km/h (28 mph)

115 km/h (71 mph)

45 km/h (28 mph)

CAUTION

On 4WD vehicles, the “4L” (Easy Select 4WD), “4LLc” (Super Select 4WD II) range gives maximum torque for low-speed driving on steep slopes, as well
as sandy, muddy, and other difficult surfaces. On vehicles with A/T, do not exceed speeds of approximately 70 km/h in “4L” (Easy Select 4WD), “4LLc”
(Super Select 4WD II) range.

Parking brake

E00600502817

To park the vehicle, first bring it to a com-
plete stop, fully apply the parking brake suf-
ficiently to hold the vehicle.

Parking brake

6-05

OKTE18E1

Starting and driving

To apply

1- Firmly depress and hold the brake pedal,

then pull the lever up without pushing
the button at the end of hand grip.

CAUTION

When you intend to apply the parking brake,
firmly press the brake pedal to bring the ve-
hicle  to  a  complete  stop  before  pulling  the
parking brake lever.
Pulling the parking brake lever with the ve-
hicle  moving  could  make  the  rear  wheels
lock  up,  thereby  making  the  vehicle  unsta-
ble.  It  could  also  make  the  parking  brake
malfunction.

NOTE

Apply sufficient force to the parking brake
lever to hold the vehicle stationary after the
foot brake is released.

NOTE

If the parking brake does not hold the vehi-
cle stationary after the foot brake is released,
have your vehicle checked immediately.

To release

1- Firmly depress and hold the brake pedal,

then pull the lever up slightly.

2- Push the button at the end of hand grip.
3- Lower the lever fully.

CAUTION

Before  driving,  be  sure  that  the  parking
brake  is  fully  released  and  brake  warning
lamp is off.
If  a  vehicle  is  driven  without  releasing  the
parking brake, the brake will be overheated,
resulting in ineffective braking and possible
brake failure.

CAUTION

If  the  brake  warning  lamp  does  not  extin-
guish  when  the  parking  brake  is  fully  re-
leased, the brake system may be abnormal.
Have your vehicle checked immediately.
For  details,  refer  to  “Brake  warning  lamp”
on page 5-15.

NOTE

To prevent the parking brake from being re-
leased  unintentionally,  the  lever  must  be
pulled  up  slightly  before  it  can  be  pushed
down.  Simply  pressing  the  button  does  not
enable the lever to be pushed down.

Parking

E00600602704

To park the vehicle, fully engage the parking
brake, and then move the gearshift lever to 1

or “R” (Reverse) position for vehicles equip-
ped with M/T, or set the selector lever to “P”
(PARK) position for vehicles equipped with
A/T.

Parking on a hill

To prevent the vehicle from rolling, follow
these procedures:

Parking

6-06

OKTE18E1

Starting and driving

Parking on a downhill slope

Turn  the  front  wheels  towards  the  kerb  and
move the vehicle forward until the kerb side
wheel gently touches the kerb.
On  vehicles  equipped  with  M/T,  apply  the
parking  brake  and  place  the  gearshift  lever
into the “R” (Reverse) position.
On  vehicles  equipped  with  A/T,  apply  the
parking brake and place the selector lever in-
to the “P” (PARK) position.
If necessary, apply chocks to wheels.

Parking on an uphill slope

Turn  the  front  wheels  away  from  the  kerb
and move the vehicle back until the kerb side
wheel gently touches the kerb.
On  vehicles  equipped  with  M/T,  apply  the
parking  brake  and  place  the  gearshift  lever
into the 1

position.

On vehicles equipped with A/T, apply the
parking brake and place the selector lever in-
to the “P” (PARK) position.
If necessary, apply chocks to wheels.

NOTE

If your vehicle is equipped with A/T, be sure
to apply the parking brake before moving se-
lector  lever  to  the  “P”  (PARK)  position.  If
you move selector lever to the “P” (PARK)
position  before  applying  the  parking  brake,
it may be difficult to disengage selector lev-
er from the “P” (PARK) position when next
you  drive  the  vehicle,  requiring  application
of  a  strong  force  the  selector  lever  to  move
from the “P” (PARK) position.

Parking with the engine run-

ning

Never leave the engine running while you
take a short sleep/rest. Also, never leave the
engine running in a closed or poorly ventila-
ted place.

WARNING

Leaving  the  engine  running  risks  injury
or  death  from  accidentally  moving  the
gearshift  lever  (with  M/T)  or  the  selector
lever  (with  A/T)  or  the  accumulation  of
toxic  exhaust  fumes  on  the  passenger
compartment.

Where you park

WARNING

Do  not  park  your  vehicle  in  areas  where
combustible  materials  such  as  dry  grass
or  leaves  can  come  in  contact  with  a  hot
exhaust, since a fire could occur.

When leaving the vehicle

Always carry the key and lock all doors when
leaving the vehicle unattended.
Always try to park your vehicle in a well lit
area.

Steering wheel height and
reach adjustment

E00600701708

1. Release the lever while holding the

steering wheel up.

2. Adjust the steering wheel to the desired

position.

3. Securely lock the steering wheel by pull-

ing the lever fully upward.

Steering wheel height and reach adjustment

6-07

OKTE18E1

Starting and driving

Type 1

Type 2

A- Locked

B- Release

*: Vehicles equipped with the reach adjust-
ment

WARNING

Do not attempt to adjust the steering
wheel while you are driving the vehicle.

Inside rear-view mirror

E00600802126

Adjust the rear-view mirror only after mak-
ing any seat adjustments so you have a clear
view to the rear of the vehicle.

Type 2

Type 1

WARNING

Do not attempt to adjust the rear-view
mirror while driving. This can be danger-
ous.
Always adjust the mirror before driving.

Adjust the rear-view mirror to maximize the
view through the rear window.

To adjust the vertical mirror

position

It is possible to move the mirror up and down
to adjust its position.

To adjust the mirror position

It is possible to move the mirror up/down and
left/right to adjust its position.

Inside rear-view mirror

6-08

OKTE18E1

Starting and driving

To reduce the glare

Type 1
The lever (A) at the bottom of the mirror can
be used to adjust the mirror to reduce the
glare from the headlamps of vehicles behind
you during night driving.

1- Normal
2- Anti-glare

Type 2

When the headlamps of the vehicles behind
you are very bright, the reflection factor of
the rear-view mirror is automatically changed
to reduce the glare.

When the ignition switch is turned to the
“ON” position or the operation mode is put in
ON, the reflection factor of the mirror is au-
tomatically changed.

NOTE

Do not hang items on, or spray glass cleaner
on the sensor (1), as reduced sensitivity
could result.

Outside rear-view mirrors

E00600900628

To adjust the mirror position

E00601001971

WARNING

Do not attempt to adjust the rear-view
mirrors while driving. This can be dan-
gerous.
Always adjust the mirrors before driving.

Your vehicle is equipped with convex type
mirrors.
Please  take  into  consideration,  that  ob-
jects you see in the mirror will look small-
er  and  farther  away  compared  to  a  nor-
mal flat mirror.
Do  not  use  this  mirror  to  estimate  dis-
tance of following vehicles when changing
lanes.

Outside rear-view mirrors

6-09

OKTE18E1

Starting and driving

Manual outside rear-view mir-

rors*

Adjust the mirror surface by hands as indica-
ted by the arrows.

Electric remote-controlled out-

side rear-view mirrors*

The electric remote-controlled outside rear-
view mirrors can be operated when the igni-
tion switch is in the “ON” or “ACC” position
or the operation mode is put in ON or ACC.

1. Place the lever (A) to the same side as

the mirror whose adjustment is desired.

Except for vehicles
equipped with the mirror
retractor switch

Vehicles equipped with
the mirror retractor switch

L- Left outside mirror adjustment
R- Right outside mirror adjustment

2. Press the switch (B) to the left, right, up

or down to adjust the mirror position.

1- Up
2- Down
3- Right
4- Left

3. Return the lever (A) back to the middle

position (•).

Retracting and extending the

outside mirrors

E00601101930

The outside mirror can be folded in towards
the side window to prevent damage when
parking in narrow areas.

CAUTION

Do not drive the vehicle with the mirror fol-
ded in.
The lack of rearward visibility normally pro-
vided by the mirror could lead to an acci-
dent.

Outside rear-view mirrors

6-10

OKTE18E1

Starting and driving

Except for vehicles equipped

with the mirror retractor switch

Push the mirror towards the back of the vehi-
cle with your hand to retract it in. When ex-
tending the mirror, pull it out towards the
front of the vehicle until it clicks to lock in
place.

For vehicles equipped with the mirror re-
tractor switch

Retracting and extending the

mirrors using the mirror re-

tractor switch

With the ignition switch or the operation
mode in ON or ACC, push the mirror retrac-
tor switch to retract the mirrors.
Push it again to extend the mirrors to their
original positions.

After  turning  the  ignition  switch  to  the
“LOCK”  position  or  putting  the  operation
mode in OFF, it is possible to retract and ex-
tend  the  mirrors  using  the  mirror  retractor
switch for about 30 seconds.

CAUTION

It  is  possible  to  retract  and  extend  the  mir-
rors by hand. After retracting a mirror using
the  mirror  retractor  switch,  however,  you
should  extend  it  by  using  the  switch  again,
not  by  hand.  If  you  extended  the  mirror  by
hand  after  retracting  it  using  the  switch,  it
would not properly lock in position. As a re-
sult,  it  could  move  because  of  the  wind  or
vibration while you are driving, taking away
your rearward visibility.

NOTE

Be careful not to get your hands trapped
while a mirror is moving.

NOTE

If you move a mirror by hand or it moves af-
ter hitting a person or object, you may not be
able to return it to its original position using
the mirror retractor switch. If this happens,
push the mirror retractor switch to place the
mirror in its retracted position and then push
the switch again to return the mirror to its
original position.

When freezing has occurred and mirrors fail
to operate as intended, please refrain from
repeated pushing of the retractor switch as
this action can result in burn-out of the mir-
ror motor circuits.

Retracting and extending the

mirrors without using the mir-

ror retractor switch

[Except  for  vehicles  equipped  with  the  key-
less entry key or the keyless operation key]
The  mirrors  automatically  extend  when  the
vehicle speed reaches 30 km/h (19 mph).
[Vehicles equipped with keyless entry key]
The  mirrors  automatically  retract  or  extend
when the doors are locked or unlocked using
the key switches of the keyless entry system.
Refer  to  “Keyless  entry  system”  on  page
3-04.
[Vehicles  equipped  with  the  keyless  opera-
tion key]

Outside rear-view mirrors

6-11

OKTE18E1

Starting and driving

The  mirrors  automatically  retract  or  extend
when the doors are locked or unlocked using
the  key  switches  or  the  keyless  operation
function of the keyless operation system.
Refer  to  “Keyless  entry  system”  on  page
3-04.
Refer to “Keyless operation system: To oper-
ate  using  the  keyless  operation  function”  on
page 3-10.

NOTE

Functions can be modified as stated below.
Please consult a MITSUBISHI MOTORS
Authorized Service Point.

•

Automatically  extend  when  the  driver’s
door is closed, and then the following op-
eration is performed.
[Except  vehicles  equipped  with  keyless
operation system]
Turn  the  ignition  switch  to  the  “ON”  or
“ACC” position.
[Vehicles equipped with keyless operation
system]
Put the operation mode in ON or ACC.

•

Automatically retract when the ignition
switch is turned to the “LOCK” position
or the operation mode is put in OFF, and
the driver’s door is then opened.

•

Automatically  extend  when  the  vehicle
speed  reaches  30  km/h  (19  mph).  (vehi-
cles  equipped  with  the  keyless  entry  key
or the keyless operation key)

NOTE

•

Deactivate the automatic extension func-
tion.

The outside rear-view mirrors can be folded
or  extended  by  the  following  operations,
even if changing to any of the above.
After  pressing  the  “LOCK”  switch  to  lock
the  doors,  if  the  “LOCK”  switch  is  pressed
again  twice  in  a  row  within  about  30  sec-
onds,  the  outside  rear-view  mirrors  will  re-
tract.
After pressing the “UNLOCK” switch to un-
lock the doors, if the “UNLOCK” switch is
pressed again twice in a row within about 30
seconds,  the  outside  rear-view  mirrors  will
extend again.

Heated mirror*

E00601201641

To demist or defrost the outside rear-view
mirrors, press the rear window demister
switch.
The indication lamp (A) will illuminate while
the demister is on.

The heater will be turned off automatically in
about 20 minutes depending on the outside
temperature.

Type 1

Type 2

Outside rear-view mirrors

6-12

OKTE18E1

Starting and driving

NOTE

The heater mirrors can be turned on auto-
matically.
For further information, we recommend you
to consult a MITSUBISHI MOTORS Au-
thorized Service Point.

Ignition switch*

E00601403302

LOCK

The engine is stopped and the steering wheel
locked. The key can only be inserted and re-
moved in this position.

ACC

The engine is stopped, but the audio system
and other electric devices can be operated.

All the vehicle’s electrical devices can be op-
erated.

START

The starter motor operates. After the engine
has started, release the key and it will auto-
matically return to the “ON” position.

NOTE

If your vehicle is equipped with an electron-
ic immobilizer.
To start the engine, the ID code transmitted
by the transponder inside the key must
match the code registered in the immobilizer
computer.
Refer to “Electronic immobilizer (Anti-theft
starting system)” on page 3-03.

To remove the key

E00620401538

For vehicles equipped with a M/T, when re-
moving the key, push the key in at the
“ACC” position and keep it depressed until it
is turned to the “LOCK” position and remove
it.

For vehicles equipped with A/T, when re-
moving the key, first set the selector lever to
the “P” (PARK) position, and push the key in
at the “ACC” position and keep it depressed
until it is turned to the “LOCK” position, and
remove it.

CAUTION

Do not remove the ignition key from the ig-
nition switch while driving. The steering
wheel will be locked, causing loss of con-
trol.

If  the  engine  is  stopped  while  driving,  the
brake servomechanism will cease to function
and braking efficiency will deteriorate. Also,
the  power  steering  system  will  not  function
and  it  will  require  greater  manual  effort  to
operate the steering.

Ignition switch*

6-13

OKTE18E1

Starting and driving

Mitsubishi L200 (2018 year). Instruction - part 8
