ZC500483
Tires
without
wheels
Seat belt
Deployment
wires
0000
6.
Pull the seat belt out to the outside of the tire, and then place
one tire without a wheel on top.
ZC500488
Deployment wires
Vehicle battery
0000
⦆
Before operation, check carefully to be sure that no one
is nearby.
⦆
The inflator will be quite hot immediately following the
operation, so wait at least 30 minutes to allow it to cool
before attempting to handle it. Although not poisonous,
do not inhale gas from seat belt pre-tensioner operation.
See Deployed Air Bag Module and Operated Seat Belt pre-
tensioner Disposal (Refer to P.52B-371) for post-
operation handling instructions.
⦆
If the seat belt pre-tensioner fails to operate, do not go
near the seat belt pre-tensioner.
7.
At a location as far away from the air bag module as possible,
and from a shielded position, disconnect the two connected
wires from each other, and connect them to the two terminals
of the battery (which has been removed from the vehicle) to
operate the seat belt pre-tensioner.
8.
Discard the operated seat belt pre-tensioner as specified in
Deployed Air Bag Module and Seat Belt pre-tensioner
Disposal (Refer to P.52B-371).
DEPLOYED AIR BAG MODULE AND OPERATED
SEAT BELT PRE-TENSIONER DISPOSAL
After deployment and operation, the air bag module and seat
belt pre-tensioner should be disposed of in the same manner as
any other scrap parts, adhering to local laws and/or legislation.
Observe the following precautions during air bag or seat belt pre-
tensioner disposal:
1.
The inflator will be quite hot immediately following
deployment, so wait at least 30 minutes to allow it cool before
attempting to handle it.
2.
Do not put water or oil on the air bag after deployment or on
the seat belt pre-tensioner after operation.
If after following these precautions, any material does get
into the eyes or on the skin, immediately rinse the affected
area with a large amount of clean water. If any irritation
develops, seek medical attention.
SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
52B-371
AIR BAG MODULE AND SEAT BELT PRE-TENSIONER DISPOSAL PROCEDURES
