TIRE PRESSURE MONITORING SYSTEM (TPMS)

CIRCUIT DIAGRAMS

90-265

LCD (TIRE PRESSURE)

CAN DRIVE
CIRCUIT

CAN
TRANSCEIVER
CIRCUIT

INTERFACE
CIRCUIT

COMBINATION
METER

INPUT SIGNAL

OUTPUT SHAFT
SPEED SENSOR

12

(FUSE     )

ETACS-ECU

ETACS-ECU

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

CPU

FRONT SIDE

TRANSMISSION
CONTROL
MODULE

SUNROOF

CIRCUIT DIAGRAMS

90-266

SUNROOF

CPU

ETACS-ECU

(LIN DRIVE CIRCUIT)

SUNROOF
SWITCH

INPUT CIRCUIT

INPUT CIRCUIT

DRIVE CIRCUIT

SUNROOF MOTOR

HALL SENSOR

SUNROOF
MOTOR
ASSEMBLY

FRONT SIDE

ETACS-ECU

(FUSE     )

12

(FUSE     )

15

SUNROOF

CIRCUIT DIAGRAMS

90-267

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

LIN DRIVE
CIRCUIT

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

FRONT
DOOR
SWITCH
(LH)

ETACS-ECU

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE

DATA LINK
CONNECTOR

SUNROOF

CIRCUIT DIAGRAMS

90-268

SUNROOF (CONTINUED)

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ETACS-
ECU

FUSIBLE
LINK

36

FUSIBLE LINK

34

IGNITION
SWITCH (IG1)

IG1
RELAY

<VEHICLES
 WITHOUT KOS>

KEYLESS
ENTRY
RECEIVER

KEYLESS
ENTRY
TRANSMITTER

WIRELESS CONTROL MODULE

ENGINE
COMPARTMENT

RELAY BOX
